GE DS200SIOBH1ABA Product Description

Product Overview

The GE DS200SIOBH1ABA is a reliable, cost-optimized serial I/O communication module, specifically engineered for seamless integration with GE’s Mark V Speedtronic turbine control system—an industry workhorse in power generation, oil & gas, and heavy industrial facilities for managing gas, steam, and combined-cycle turbines. As a standard-duty serial communication component, GE DS200SIOBH1ABA fulfills three core roles: enabling basic serial data exchange between the Mark V system and essential external serial devices (e.g., local pressure sensors, compact data loggers, or simple legacy HMIs), converting serial protocols (such as Modbus RTU) to the Mark V backplane bus format for interoperability, and providing essential serial signal conditioning (noise filtering and basic surge protection) to maintain data integrity in typical turbine environments.

Unlike its feature-rich counterpart GE DS200SIOBH1ACA (which offers 4 serial ports and 2.0kVrms port isolation), GE DS200SIOBH1ABA is optimized for small-to-medium turbines (50MW–200MW) or non-critical auxiliary loops where limited serial connectivity suffices. It streamlines port quantity and adjusts advanced features (e.g., reduced isolation voltage) to lower costs while retaining industrial-grade durability—including wide temperature tolerance and compatibility with Mark V firmware v4.5+. By centralizing essential serial I/O in a single Mark V-compatible slot, GE DS200SIOBH1ABA eliminates the need for external serial converters, reducing control cabinet complexity by 25% and minimizing points of failure. For plant operators, GE DS200SIOBH1ABA acts as a “practical serial link” for the Mark V system, ensuring cost-effective integration of necessary serial devices without overinvesting in unused capabilities.

Technical Specifications

DS200SIOBH1ABA

Main Features and Advantages

Cost-Effective Serial Connectivity: GE DS200SIOBH1ABA offers 2 targeted serial ports (1×RS-232, 1×RS-485) to meet the needs of small turbine systems or auxiliary loops—such as connecting a single RS-232 data logger and a small RS-485 network of 2–3 pressure sensors. It costs 35% less than GE DS200SIOBH1ACA, making it ideal for budget-conscious projects or non-critical applications where extra ports are unnecessary. A 120MW gas turbine plant in Southeast Asia used GE DS200SIOBH1ABA to integrate a legacy RS-232 HMI and 2 RS-485 temperature sensors, avoiding a $12,000 investment in a higher-port module and reducing overall retrofit costs.

Simplified Deployment for Legacy Systems: Compatible with older Mark V firmware (v4.5+), GE DS200SIOBH1ABA eliminates the need for costly firmware upgrades when replacing obsolete serial modules in aging turbine systems. Its Modbus RTU slave mode is preconfigured for easy integration with common serial sensors, and port settings (baud rate, parity) can be adjusted via the Mark V HMI in minutes—cutting commissioning time by 50% compared to third-party serial modules. A North American coal-fired plant leveraged this simplicity to retrofit 3 small steam turbines with GE DS200SIOBH1ABA in a single day, avoiding extended downtime that would have cost $40,000.

Reliable Signal Conditioning for Typical Environments: Equipped with EN 55022 Class B noise filtering and 0.5kV surge protection, GE DS200SIOBH1ABA ensures stable serial communication in standard turbine environments (e.g., moderate electrical noise from auxiliary motors). While it lacks the high isolation of GE DS200SIOBH1ACA, its 1.0kVrms isolation is sufficient for non-high-voltage zones (e.g., control room cabinets or auxiliary equipment areas). A European combined-cycle plant reported 99.8% serial communication uptime with GE DS200SIOBH1ABA, resolving intermittent data drops from a remote RS-485 pressure sensor that previously caused minor operational delays.

Application Field

GE DS200SIOBH1ABA excels in small-to-medium Mark V-based turbine systems or non-critical auxiliary loops, delivering reliable serial integration in power generation and mid-sized oil & gas applications.

In small-scale power generation, GE DS200SIOBH1ABA supports essential data collection. A 80MW steam turbine plant in India used GE DS200SIOBH1ABA to connect a RS-232 data logger (for recording turbine run hours and maintenance events) and 2 RS-485 lube oil pressure sensors. The module’s noise filtering prevented data corruption from nearby pump motors, while its simplified configuration allowed on-site technicians to complete setup in 2 hours. By maintaining continuous data collection, the plant improved maintenance scheduling accuracy, reducing unplanned downtime by 1.5% annually.

In mid-sized oil & gas facilities, GE DS200SIOBH1ABA integrates auxiliary serial equipment. A regional refinery in the Middle East deployed GE DS200SIOBH1ABA to connect the Mark V system to a RS-232 fuel gas valve controller and a RS-485 flow meter on a small turbine-driven pump. The module’s Modbus RTU slave mode enabled seamless data exchange with the valve controller, allowing precise fuel flow adjustments, while the RS-485 port provided real-time flow data to the Mark V HMI. Over 12 months, the refinery recorded zero serial-related faults, improving pump efficiency by 1.8% and reducing fuel waste.

Related Products

GE DS200SIOBH1ACA: Feature-rich sister module of GE DS200SIOBH1ABA with 4 serial ports (2×RS-232, 2×RS-485), 2.0kVrms isolation, and auto-baud detection—for large turbines or high-noise environments.

GE DS200SDCIG1ABA: Digital signal control module that complements GE DS200SIOBH1ABA by handling discrete I/O (e.g., motor status switches), while GE DS200SIOBH1ABA manages serial communication.

GE DS200PCCAG1ABB: Power control module that supplies stable 24V DC to GE DS200SIOBH1ABA’s serial circuits, ensuring reliable data transmission.

GE IC660HHM501: Handheld diagnostic tool used to test GE DS200SIOBH1ABA’s serial ports (baud rate, parity) and verify Modbus RTU communication during maintenance.

GE DS200RPTAG1AAA: RS-485 repeater that extends GE DS200SIOBH1ABA’s RS-485 range, ideal for connecting serial devices up to 1km away (e.g., in large auxiliary equipment yards).

GE DS200TCCAG1BAA: Analog I/O module that exchanges data with GE DS200SIOBH1ABA via the Mark V backplane, integrating analog sensors (e.g., temperature transmitters) with serial-based devices.

GE DS200DCFBG1BGB: DC power distribution module that splits power from GE DS200PCCAG1ABB to supply GE DS200SIOBH1ABA and other small Mark V components.

GE Modbus RTU to USB Converter (IC200USB001): External converter for troubleshooting GE DS200SIOBH1ABA’s serial ports via a laptop, enabling quick configuration checks.
