The GE DS200CPCAG1ABB is a contactor pilot board within the GE Mark V Series of turbine control systems, designed for Level 2 (Control) of the Purdue Model in industrial automation. It resides in turbine control cabinets (mounted on VME racks) and serves as the bridge between Mark V main processor boards (LDCC) and contactors (electromechanical switches that control power to turbines/auxiliary systems).
Upstream Communication
Receives control signals from Mark V main processor boards (LDCC) via the VME backplane. These signals indicate whether the contactor should be opened or closed (e.g., to start/stop a turbine or activate a pump).
Downstream Communication
Transmits drive current to the contactor coil via screw terminals or pre-wired cables. The board uses a 24VDC 15A socket power relay to control power flow and a voltage conversion circuit (rectifiers, capacitors, diodes) to convert 115V AC input to 105V DC output for closing contactors.
Operational Advantages
-
Reliable Contactor Control: The board’s design ensures consistent contactor actuation, even in harsh turbine hall environments (e.g., high temperatures, electromagnetic interference).
-
Voltage Regulation: The voltage conversion circuit stabilizes the output voltage, ensuring the contactor remains closed once activated.
-
Hot-Swappable Design: Enables module replacement without system shutdown, minimizing downtime.
Core Technical Specifications
|
Attribute
|
Specification
|
|---|---|
|
Product Type
|
Contactor Pilot Board
|
|
Part Number
|
DS200CPCAG1ABB
|
|
System Platform
|
GE Mark V Series Turbine Control Systems
|
|
Input Voltage
|
24V DC (nominal)
|
|
Coil Voltage
|
115V DC
|
|
Power Relay
|
24VDC 15A socket power relay
|
|
Voltage Conversion
|
Converts 115V AC to 105V DC
|
|
Connectors
|
1x 12-pin connector; 2x 2-pin connectors; 4x terminal blocks (supports up to 12 signal wires)
|
|
Operating Temperature
|
-40°C to +70°C (-40°F to 158°F)
|
|
Storage Temperature
|
-40°C to +85°C (-40°F to 185°F)
|
|
Humidity
|
5–95% non-condensing
|
|
Dimensions (W×H×D)
|
~100 mm × 100 mm × 50 mm (4 in × 3.5 in × 2 in) (approximate)
|
|
Weight
|
~1.8 kg (4 lbs)
|
|
Certifications
|
CE, UL, ATEX (Ex d IIB T5 Gb) (hazardous location compliant)
|
