GE DS200NATOG1ABB | Mark V Series Voltage Feedback Board for Turbine Control

  • Brand: GE (General Electric)
  • Model: DS200NATOG1ABB (variant of DS200NATOG1A)
  • Product Type: Voltage Feedback Board
  • Series: Mark V (Turbine Control Systems)
  • Core Function: Provides real-time voltage feedback for GE Mark V turbine control systems, ensuring precise voltage monitoring and control in industrial applications.
  • Key Specs:
    • Function: Voltage feedback signal processing
    • Operating Temperature: 0°C to 50°C (industrial-grade)
    • Compatibility: Mark V series controllers and I/O cores (R1, R2, R3)
    • Application: Gas/steam turbine control, power generation, industrial automation
Get a Quote
Manufacturer:
Part number: GE DS200NATOG1ABB
Our extensive catalogue, including : GE DS200NATOG1ABB , is available now for dispatch to the worldwide.

Description

DS200NATOG1ABB: Product Overview​
The GE DS200NATOG1ABB​ is a voltage feedback board designed for integration into GE’s Mark V series​ of turbine control systems. As a critical component of the Mark V ecosystem, it enables real-time voltage monitoring and feedback for field devices (e.g., voltage sensors, transducers) and communicates processed signals to the Mark V controller.
Role in Automation Systems:
Positioned as a “voltage feedback interface” in the Mark V architecture, the DS200NATOG1ABB performs two primary functions:
  1. Voltage Signal Acquisition: Receives voltage signals from field devices (e.g., turbine voltage sensors) and converts them into a format suitable for the Mark V controller.
  2. Feedback Signal Transmission: Transmits processed voltage feedback signals to the Mark V controller via the 3PL data bus, enabling real-time adjustments to turbine operations (e.g., voltage regulation, power output control).
Core Functionality:
  • Real-Time Voltage Feedback: Captures and processes voltage signals with high accuracy, ensuring that the Mark V controller receives up-to-date information for precise control.
  • Signal Conditioning: Filters and amplifies raw voltage signals to remove noise and improve signal integrity, critical for maintaining turbine stability.
  • Diagnostic Indicators: Equipped with LEDs to indicate power status, signal presence, and fault conditions, simplifying troubleshooting and maintenance.
Platform Benefits (Mark V Series):
The DS200NATOG1ABB leverages GE’s Mark V platform, which is renowned for:
  • Reliability: Industrial-grade components and a rugged design ensure 24/7 operation in harsh turbine hall environments (e.g., high temperature, vibration).
  • Scalability: Supports expansion with additional feedback boards to accommodate growing system demands (e.g., adding more voltage sensors).

  • Integration: Seamlessly integrates with Mark V controllers and other I/O components (e.g., TCQA, TCQC), reducing setup time and effort.

    GE DS200NATOG1ABB

    GE DS200NATOG1ABB

Technical Specifications​
  • Model Number: DS200NATOG1ABB (variant of DS200NATOG1A)
  • Manufacturer: GE (General Electric)
  • Product Type: Voltage Feedback Board
  • Series: Mark V
  • Input Signals: Voltage signals from field devices (e.g., 0–10 V DC, 4–20 mA)
  • Output Signals: Processed voltage feedback signals (transmitted via 3PL data bus)
  • Connectors: 3PL (data bus to STCA/TCQA/TCQE boards), JE (generator/line signals to TCQC board)
  • Operating Temperature: 0°C to 50°C (32°F to 122°F)
  • Storage Temperature: -40°C to +85°C (-40°F to 185°F) (inferred from industrial-grade standards)
  • Humidity: 5–95% non-condensing (inferred from industrial-grade standards)
  • Dimensions: 173 mm × 112 mm × 13 mm (6.81 in × 4.41 in × 0.51 in) (inferred from similar Mark V series products)
  • Weight: 0.12 kg (0.26 lbs) (inferred from similar Mark V series products)
  • Certifications: CE, UL (inferred from GE industrial product standards)
Core Features & Customer Value​
1. Precise Voltage Feedback:
The DS200NATOG1ABB provides accurate voltage feedback, enabling the Mark V controller to make real-time adjustments to turbine operations. This precision is critical for maintaining grid stability and complying with utility regulations.
2. Rugged Industrial Design:
The board’s operating temperature range (0°C to 50°C) and compact form factor make it suitable for harsh turbine hall environments. Its DIN rail mounting option simplifies installation in crowded control cabinets, reducing setup time and effort.
3. Easy Troubleshooting:
Diagnostic LEDs indicate power status, signal presence, and fault conditions, allowing operators to quickly identify and resolve issues. This reduces downtime and improves system reliability.
4. Legacy System Compatibility:

As part of the Mark V series, the DS200NATOG1ABB integrates with existing turbine control systems, eliminating the need for costly upgrades. This compatibility is invaluable for facilities with legacy Mark V installations.

GE DS200NATOG1ABB

GE DS200NATOG1ABB

Typical Applications​
The GE DS200NATOG1ABB​ is widely used in turbine control systems for:
  1. Power Generation:
    • Provides voltage feedback for gas/steam turbines, enabling the Mark V controller to regulate power output and maintain grid stability.
  2. Industrial Automation:
    • Used in industrial automation systems to monitor voltage levels in manufacturing processes, ensuring consistent operation of equipment (e.g., motors, pumps).
  3. Legacy System Support:
    • Maintains compatibility with existing Mark V installations, allowing facilities to enhance system reliability without replacing entire architectures.
