GE DS3800NBIB1K1E | Mark IV Series Interface Module for Gas/Steam Turbine Control

  • Brand: GE (General Electric)
  • Model: DS3800NBIB1K1E (Variant of Mark IV Series)
  • Product Type: Interface Module (Critical Component for Turbine Control Systems)
  • Series: Mark IV (Legacy GE Turbine Control Systems)
  • Core Function: Serves as a critical interface​ in GE Mark IV turbine control systems, designed to facilitate signal transmission and communication between field devices (e.g., sensors, actuators) and the turbine control unit. It supports legacy VMEbus architectures, ensuring seamless integration with existing Mark IV components.
  • Key Specs:
    • Bus Compatibility: VMEbus Rev. C.1 (fits into Mark IV I/O racks)
    • Form Factor: 6U Eurocard (160 mm × 233 mm, standard for Mark IV devices)
    • Status: Discontinued by manufacturer (repair services available)
    • Weight: ~0.45 kg (1 lb)
Get a Quote
Manufacturer:
Part number: DS3800NBIB1K1E
Our extensive catalogue, including : DS3800NBIB1K1E , is available now for dispatch to the worldwide.

Description

DS3800NBIB1K1E: Product Overview​
The GE DS3800NBIB1K1E​ is an interface module​ belonging to the Mark IV series​ (a legacy platform for GE turbine control systems). It is engineered for signal interfacing​ in industrial automation systems, particularly in gas and steam turbine control applications. As part of the Mark IV ecosystem, it acts as a “bridge” between field devices (e.g., temperature sensors, pressure transducers, servo valves) and the turbine control unit, ensuring accurate and reliable data transmission for process control.
Role in Automation Systems:
Positioned as a “field signal interface” in Mark IV architectures, the DS3800NBIB1K1E performs two primary functions:
  1. Signal Acquisition: Receives digital/analog signals from field sensors (e.g., a thermocouple measuring turbine exhaust temperature) and conditions them for transmission to the turbine control unit.
  2. Signal Output: Sends control commands from the turbine control unit to field actuators (e.g., a solenoid valve opening to release a part) based on processed data.
Core Functionality:
  • VMEbus Compatibility: Conforms to VMEbus Rev. C.1 standards, ensuring seamless integration with existing Mark IV I/O racks and controllers. This eliminates the need for additional adapters or modifications, minimizing installation time and cost.
  • Legacy Support: Designed to work with existing Mark IV components (e.g., I/O modules, terminal boards), reducing the cost of system upgrades. This makes it an ideal choice for power plants with aging Mark IV systems, where replacing the entire control architecture is not feasible.
  • Rugged Design: Industrial-grade components and a compact form factor (6U Eurocard) enable 24/7 operation in high-temperature, high-vibration environments (e.g., turbine halls).
Platform Benefits (Mark IV Series):
The DS3800NBIB1K1E inherits the Mark IV platform’s strengths, including:
  • Reliability: The Mark IV system is a proven platform for turbine control, with a track record of 24/7 operation in power plants worldwide.
  • Scalability: Supports expansion with additional I/O modules to accommodate growing system demands (e.g., adding more sensors to a turbine control system).
  • Easy Integration: Compatible with GE Fanuc/Emerson PLC/PAC systems, ensuring seamless integration with existing automation architectures.
    GE DS3800NBIB1K1E

    GE DS3800NBIB1K1E

Technical Specifications​
Parameter
Specification
Model Number​
DS3800NBIB1K1E (Variant of Mark IV Series)
Manufacturer​
GE (General Electric)
Product Type​
Interface Module
Series​
Mark IV (Turbine Control Systems)
Bus Compatibility​
VMEbus Rev. C.1 (fits into Mark IV I/O racks)
Form Factor​
6U Eurocard (160 mm × 233 mm)
Status​
Discontinued by manufacturer
Weight​
~0.45 kg (1 lb)
Certifications​
CE, UL (inferred from GE industrial product standards)
Core Features & Customer Value​
1. Seamless Legacy Integration:
The DS3800NBIB1K1E’s VMEbus compatibility ensures seamless integration with existing Mark IV systems, minimizing downtime and effort during upgrades. This is invaluable for facilities with legacy Mark IV installations, allowing them to enhance system capabilities without replacing entire architectures.
2. Reliable Signal Transmission:
The module’s rugged design and legacy support ensure reliable signal transmission between field devices and the turbine control unit. This is critical for turbine control, where even minor signal inaccuracies can lead to process instability.
3. Cost-Effective Retrofit:
By enabling integration with existing Mark IV components, the DS3800NBIB1K1E eliminates the need for costly system upgrades. This makes it an ideal choice for power plants with aging Mark IV systems, where replacing the entire control architecture is not feasible.
4. Easy Maintenance:
The module’s modular design allows for quick replacement during maintenance, reducing downtime. Radwell provides repair services for the DS3800NBIB1K1E, ensuring that facilities can extend the lifespan of their existing systems.

GE DS3800NBIB1K1E

Typical Applications​
The GE DS3800NBIB1K1E​ is widely used in industrial automation systems for:
  1. Power Generation:
    • Controls gas/steam turbines in power plants, ensuring stable power output and efficient fuel use.
  2. Manufacturing:
    • Used in assembly lines to process digital/analog signals from sensors (e.g., pressure, flow) and control actuators (e.g., valves, motors).
  3. Petrochemical Industry:
    • Controls digital/analog signals from refinery equipment (e.g., distillation columns, pumps), ensuring safe and efficient operation in hazardous environments.
