IC200ALG620
IC200ALG620
IC200ALG620

GE IC200ALG620

High Precision Measurement: The IC200ALG620 features 16-bit resolution, allowing for high-precision temperature readings. It supports various RTD types, including platinum, copper, nickel, and nickel/iron, providing flexibility in sensor selection.
Automatic Calibration: The module performs automatic A/D calibration at power-up and periodically during operation to compensate for ambient temperature changes, ensuring consistent accuracy without manual recalibration.
Robust Design: With an operating temperature range of 0°C to 60°C and high humidity tolerance, the IC200ALG620 is designed for reliable performance in harsh industrial environments.
LED Indicators: The module includes LED indicators for normal operation, updates, errors, and power status, facilitating easy monitoring and troubleshooting.
Get a Quote
Manufacturer:
Part number: IC200ALG620
Our extensive catalogue, including : IC200ALG620 , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

Detailed Parameter Table

Parameter Name Parameter Value
Product Model IC200ALG620
Manufacturer GE Fanuc (Emerson Automation)
Product Category Analog Input Module
Series VersaMax
Number of Channels 4 (3-wire and/or 4-wire RTDs)
Voltage Range 5 V nominal
RTD Types Platinum, Copper, Nickel, Nickel/Iron
Update Rate 210 ms (60 Hz), 230 ms (50 Hz)
LED Indicators OK (Green for normal operation, Amber for fault)
Power Consumption 125 mA from +5V bus
Resistance Input Range 0-500 Ohms, 0-3000 Ohms
Isolation (Input to Frame) 1500 V AC
Isolation (Input to Logic) 250 V AC
Accuracy (at 25°C) ±0.15% on resistance measurement, ±0.15% on RTD (temperature) measurement
Operating Temperature Range 0°C to 60°C
Humidity Range Up to 90% non-condensing
Certifications CE, UL
IC200ALG620

IC200ALG620

Product Introduction

The GE IC200ALG620 is a high-performance analog input module designed for the VersaMax series, specifically for industrial and process control applications. It provides precise temperature measurement using RTD sensors, ensuring accurate and reliable data for critical control loops.

Core Advantages and Technical Highlights

High Precision Measurement: The IC200ALG620 features 16-bit resolution, allowing for high-precision temperature readings. It supports various RTD types, including platinum, copper, nickel, and nickel/iron, providing flexibility in sensor selection.
Automatic Calibration: The module performs automatic A/D calibration at power-up and periodically during operation to compensate for ambient temperature changes, ensuring consistent accuracy without manual recalibration.
Robust Design: With an operating temperature range of 0°C to 60°C and high humidity tolerance, the IC200ALG620 is designed for reliable performance in harsh industrial environments.
LED Indicators: The module includes LED indicators for normal operation, updates, errors, and power status, facilitating easy monitoring and troubleshooting.

Typical Application Scenarios

The GE IC200ALG620 is widely used in:
  • Energy: Monitoring temperature in power generation and distribution systems.
  • Automotive: Controlling temperature in robotic welding and assembly lines.
  • Food & Beverage: Ensuring precise temperature control in packaging processes.
  • Process Control: Monitoring reactor temperature and flow rates in chemical plants.

    IC200ALG620

    IC200ALG620

Related Model Recommendations

  • IC200ALG620-JF: A variant with similar functionality but different labeling.
  • IC200ALG620-AA: An earlier revision with similar specifications.

Installation, Commissioning, and Maintenance Instructions

Installation Preparation: Ensure the environment meets the specified temperature and humidity requirements. Follow the installation manual carefully to ensure proper grounding and connection. Always disconnect the power source before starting the installation process to avoid electrical shock.
Maintenance Suggestions: Regularly inspect the module for signs of damage or wear. Clean the module periodically to remove dust and debris, which can affect performance and longevity. If any issues are detected, consult the troubleshooting guide or contact a professional for assistance.

Service and Guarantee Commitment

The GE IC200ALG620 is backed by a comprehensive warranty, ensuring customer satisfaction and peace of mind. Emerson Automation offers technical support and service to assist with installation, troubleshooting, and maintenance.
