High Capacity and Flexibility: The IC200GBI001 supports up to 64 analog I/O points, 1024 discrete I/O points, and can manage up to 8 racks, each hosting 8 modules. This provides significant flexibility and scalability for complex industrial applications.
Advanced Communication Capabilities: The unit supports multiple transmission rates, including 153.6 Kbaud for extended configurations and 38.4 Kbaud for standard setups. It also features dual Genius bus terminals for redundancy, enhancing system reliability.
Enhanced Diagnostics: The IC200GBI001 includes an Enhanced Diagnostics Mode (EDM) that provides detailed diagnostic data, facilitating easier troubleshooting and maintenance.
Robust Design: The unit is designed to operate reliably in harsh industrial environments, with a wide operating temperature range and high humidity tolerance.
Get a Quote
Manufacturer:
Part number: GE IC200GBI001
Our extensive catalogue, including : GE IC200GBI001 , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

Detailed Parameter Table

Parameter Name Parameter Value
Product Model IC200GBI001
Manufacturer GE Fanuc
Product Category Network Interface Unit
Series VersaMax
Communication Ports Two Genius terminals
Redundancy Support Yes
Number of Modules per Rack 8 modules
Maximum Number of Racks 8 racks
Network Inputs per Scan 128 bytes
Discrete I/O Memory 1024 points
Analog I/O Memory 128 bytes
Supported Transmission Rates 153.6 Kbaud (extended), 153.6 Kbaud, 76.8 Kbaud, 38.4 Kbaud
Power Rating at 250 mA 5 V
Power Rating at 10 mA 3.3 V
Serial Bus Address Range 0 to 31
Compatible Controllers Series 90-70, PACSystem RX7i, PACSystem RX3i
LED Indicators PWR, OK, FAULTS, I/O ENBL, FORCE, SBA ERR, BUS B
Operating Temperature Range -20°C to +60°C
Humidity Range 5% to 95% non-condensing
Dimensions (L×W×H) 145 mm × 75 mm × 75 mm
Weight 0.25 kg
Certifications CE, UL
GE IC200GBI001

GE IC200GBI001

Product Introduction

The GE Fanuc IC200GBI001 is a high-performance Genius Network Interface Unit (NIU) designed for the VersaMax series of programmable logic controllers (PLCs). It provides robust control functions for various connected input and output modules, making it an essential component in industrial automation systems.

Core Advantages and Technical Highlights

High Capacity and Flexibility: The IC200GBI001 supports up to 64 analog I/O points, 1024 discrete I/O points, and can manage up to 8 racks, each hosting 8 modules. This provides significant flexibility and scalability for complex industrial applications.
Advanced Communication Capabilities: The unit supports multiple transmission rates, including 153.6 Kbaud for extended configurations and 38.4 Kbaud for standard setups. It also features dual Genius bus terminals for redundancy, enhancing system reliability.
Enhanced Diagnostics: The IC200GBI001 includes an Enhanced Diagnostics Mode (EDM) that provides detailed diagnostic data, facilitating easier troubleshooting and maintenance.
Robust Design: The unit is designed to operate reliably in harsh industrial environments, with a wide operating temperature range and high humidity tolerance.

GE IC200GBI001

GE IC200GBI001

Typical Application Scenarios

The GE Fanuc IC200GBI001 is widely used in:
  • Energy: Power generation and distribution systems.
  • Automotive: Robotic welding and assembly line control.
  • Food & Beverage: Packaging and processing systems.
  • Process Control: Chemical plants and water treatment facilities.

Related Model Recommendations

  • IC200GBI001-BF: A variant with similar functionality but different firmware.
  • IC200GBI001-FF: Another variant with enhanced features and improved performance.

Installation, Commissioning, and Maintenance Instructions

Installation Preparation: Ensure the environment meets the specified temperature and humidity requirements. Follow the installation manual carefully to ensure proper grounding and connection. Always disconnect the power source before starting the installation process to avoid electrical shock.
Maintenance Suggestions: Regularly inspect the module for signs of damage or wear. Clean the module periodically to remove dust and debris, which can affect performance and longevity. If any issues are detected, consult the troubleshooting guide or contact a professional for assistance.

Service and Guarantee Commitment

The GE Fanuc IC200GBI001 is backed by a comprehensive warranty, ensuring customer satisfaction and peace of mind. GE Fanuc offers technical support and service to assist with installation, troubleshooting, and maintenance.
