Product Overview
The GE IC670CHS002 is a high – performance I/O terminal block meticulously crafted by General Electric, a globally recognized leader in industrial automation solutions. As an integral part of the Field Control series, it serves as a fundamental building block in industrial control systems, providing a reliable platform for connecting and managing various I/O modules.
This terminal block is designed to be a central hub for I/O connectivity. It enables seamless communication between different components within an industrial setup, ensuring that control signals are accurately transmitted and received. With its robust construction, the GE IC670CHS002 can withstand the rigors of harsh industrial environments, making it suitable for applications where reliability and durability are of utmost importance. It plays a crucial role in enhancing the overall efficiency and stability of industrial automation processes, whether in a large – scale manufacturing plant or a complex power generation facility.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC670CHS002 |
| Manufacturer | General Electric |
| Product Type | I/O Terminal Block |
| Number of Terminals | 37 |
| Terminal Connection | Wiring one AWG #14 (2.1 mm²) or two AWG #18 (0.86 mm²) through AWG #22 (0.35 mm²) wires |
| Terminal Torque | 4.5 pounds – inch |
| Maximum Current per Terminal | 10 Amperes |
| Hot – Swap Compatibility | Yes |
| Module Compatibility | Modules whose catalog number suffix is ‘j’ or above |
| Number of Modules per Block | 2 |
| Mounting Type | DIN rail / Panel mount |
| Certification | Compliant with industry standards |
IC670CHS002
Main Features and Advantages
High – Density Connectivity: The GE IC670CHS002 comes equipped with 37 terminals, offering a high – density solution for wiring and connections. This allows for the integration of multiple I/O modules, reducing the need for additional terminal blocks and simplifying the overall system architecture. In large – scale industrial projects, this high – density connectivity can significantly save space and cost.
Hot – Swap Capability: One of the standout features of the GE IC670CHS002 is its hot – swap compatibility. This means that users can insert or remove modules even when the power is on. In industrial operations where downtime can be costly, this feature enables maintenance and upgrades to be carried out without disrupting the ongoing process, ensuring continuous operation and minimizing production losses.
Robust Construction: Built to endure harsh industrial environments, the terminal block has a rugged design. It can resist vibrations, shocks, and temperature variations commonly found in industrial settings. This robustness ensures the integrity of electrical connections over time, reducing the risk of intermittent failures due to environmental factors.
Easy Installation and Configuration: The GE IC670CHS002 is designed for easy installation. It can be mounted on a DIN rail or a panel, providing flexibility in system layout. Additionally, the use of a lettered key system simplifies the process of determining which type of module should be installed in each connection slot, making it user – friendly for technicians.
Application Field
Manufacturing Industry: In manufacturing plants, the GE IC670CHS002 is used to connect sensors, actuators, and other I/O devices in automated production lines. For example, it can link proximity sensors that detect the position of products on a conveyor belt to the control system, and also connect to actuators that control the movement of robotic arms. This seamless connection ensures smooth and efficient production processes.
Power Generation and Distribution: In power plants and substations, this terminal block is employed to manage the I/O connections of various monitoring and control devices. It can connect sensors that monitor the temperature, pressure, and voltage of electrical equipment, and also connect to relays and circuit breakers for control purposes. The reliable performance of the GE IC670CHS002 is crucial for maintaining the stable operation of the power grid.
Water and Wastewater Treatment: In water treatment facilities, the terminal block is used to interface with pumps, valves, and sensors. It can connect flow sensors that measure the rate of water flow, and also connect to control valves that regulate the treatment process. In wastewater treatment, it helps in the proper operation of aeration systems and sludge handling equipment, ensuring compliance with environmental regulations.
Power Generation and Distribution: In power plants and substations, this terminal block is employed to manage the I/O connections of various monitoring and control devices. It can connect sensors that monitor the temperature, pressure, and voltage of electrical equipment, and also connect to relays and circuit breakers for control purposes. The reliable performance of the GE IC670CHS002 is crucial for maintaining the stable operation of the power grid.
Water and Wastewater Treatment: In water treatment facilities, the terminal block is used to interface with pumps, valves, and sensors. It can connect flow sensors that measure the rate of water flow, and also connect to control valves that regulate the treatment process. In wastewater treatment, it helps in the proper operation of aeration systems and sludge handling equipment, ensuring compliance with environmental regulations.
IC670CHS002
Related Products
GE IC670CHS002D: A revision of the GE IC670CHS002, denoted as Series D, Rev D. It likely has some specific improvements or differences in functionality compared to the base model, which may be suitable for certain applications with more specific requirements.
GE IC670CHS002E: Another revision, Series E, Rev E. It may offer enhanced features, such as improved compatibility with newer I/O modules or better performance in specific environmental conditions.
GE IC670CHS002F: Series F, Rev F. This version might have further refinements, perhaps in terms of electrical characteristics or mechanical design, to meet evolving industrial needs.
GE I/O Modules (suffix ‘j’ or above): These are the modules that are compatible with the GE IC670CHS002. They can be easily integrated with the terminal block to expand the I/O capabilities of the system. Different types of these modules, such as digital input/output or analog input/output modules, can be used depending on the specific requirements of the industrial application.
DIN Rail Mounting Accessories: These accessories are used in conjunction with the GE IC670CHS002 when it is mounted on a DIN rail. They ensure a secure and stable installation, helping to maintain the integrity of the connection between the terminal block and other components in the system.
GE IC670CHS002E: Another revision, Series E, Rev E. It may offer enhanced features, such as improved compatibility with newer I/O modules or better performance in specific environmental conditions.
GE IC670CHS002F: Series F, Rev F. This version might have further refinements, perhaps in terms of electrical characteristics or mechanical design, to meet evolving industrial needs.
GE I/O Modules (suffix ‘j’ or above): These are the modules that are compatible with the GE IC670CHS002. They can be easily integrated with the terminal block to expand the I/O capabilities of the system. Different types of these modules, such as digital input/output or analog input/output modules, can be used depending on the specific requirements of the industrial application.
DIN Rail Mounting Accessories: These accessories are used in conjunction with the GE IC670CHS002 when it is mounted on a DIN rail. They ensure a secure and stable installation, helping to maintain the integrity of the connection between the terminal block and other components in the system.
Installation and Maintenance
Pre – installation preparation: Before installing the GE IC670CHS002, ensure that the power to the relevant system is switched off to prevent electrical accidents. Check the DIN rail or panel where it will be mounted for any signs of damage or instability. Inspect the terminal block for any visible defects during transportation. When preparing to connect wires, make sure to strip the wires to the appropriate length and use the correct wire gauges as specified in the technical specifications. Also, be aware of the alignment slot on the terminal block when installing compatible I/O modules to ensure proper fitting.
Maintenance recommendations: Regularly inspect the GE IC670CHS002 for any loose connections. Check the terminal torque periodically to ensure that it remains at the specified 4.5 pounds – inch. Clean the terminal block to remove dust and debris, especially in dusty industrial environments, as these can affect the electrical conductivity. If any modules need to be replaced, ensure that they are of the correct type and compatible with the GE IC670CHS002. In case of any abnormal behavior, refer to the product manual for troubleshooting steps.
