GE IC693CBK001 | Series 90-30 High-Density I/O Cable Kit – 24-Pin Connectors

  • Model:​ IC693CBK001
  • Brand:​ GE Fanuc (Emerson Automation)
  • Series:​ Series 90-30
  • Core Function:​ High-density I/O cable kit for connecting 32-point I/O modules to GE Series 90-30 PLCs via pre-terminated 24-pin connectors.
  • Product Type:​ I/O Cable Kit
  • Key Specs:​ 2x 10-foot cables | 1.2A per conductor | 24-pin connectors | Slot 1/2/3 compatibility
  • Condition:​ New Original (Discontinued by OEM; third-party stock available)
Get a Quote
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.

Description

3. Key Technical Specifications

Parameter​
Specification​
Included Cables​
IC693CBL327 (left), IC693CBL328 (right)
Connector Type​
Fujitsu FCN-365S024-AU 24-pin connectors with stripped wire ends
Cable Length​
3 meters (10 feet) per cable
Current Rating​
1.2 amps per conductor (max 32 points per module)
Compatibility​
Series 90-30 32-point I/O modules (e.g., IC693MDL654, 752, 753)
Reduced Clearance​
Optimized right-angle design minimizes PLC front-panel space
Wiring Configuration
Direct replacement for older straight connectors; supports field termination
Certifications​
UL, CE
Warranty​
12 months (defects only; third-party suppliers may offer extended terms)

4. Product Introduction

The GE IC693CBK001​ is a factory-assembled high-density I/O cable kit designed for GE Series 90-30 PLC systems. It replaces manual connector assembly with pre-terminated 24-pin connectors, ensuring consistent signal integrity and reducing installation time.
Core Advantages:​
  • Space Efficiency:​ Right-angle connectors reduce front-panel clearance requirements by up to 40% .
  • Durability:​ Stripped wire ends and shielded cables resist EMI in industrial environments.
  • Scalability:​ Supports distributed I/O architectures with up to 32 points per module.

    IC693CBK001

    IC693CBK001

5. Firmware/Software Versions & Upgrade Notes

  • Configuration Tools:​
    • LogicMaster 90-30:​ Legacy tool for basic I/O mapping.
    • VersaPro:​ Modern IEC 61131-3-compliant software for advanced diagnostics.
  • Compatibility Notes:​
    • Works with all Series 90-30 CPUs (firmware ≥5.0).
    • No firmware updates required—plug-and-play installation.

6. Frequently Asked Questions (FAQ)

1. Can I use this kit with 16-point I/O modules?​
Yes, but the 1.2A per conductor rating must be derated. For 16-point modules, limit current to 0.6A per conductor to avoid overheating .
2. Is hot-swapping supported?​
No. Always power down the PLC rack before connecting/disconnecting cables to prevent short circuits .
3. How does this compare to OEM discontinued units?​
We source new-old-stock (NOS) units with full factory testing, including:
  • 24-hour load testing for signal stability.
  • Megger insulation tests (>10MΩ).
  • Connector torque verification.
4. Warranty & Support​
  • 12-month warranty​ covering manufacturing defects (e.g., broken connectors, shorted wires).
  • Extended options:​ 24-month warranty available for +15% cost.
5. Why choose this over field-assembled cables?​
  • Precision:​ Factory-terminated connectors ensure <0.1mm wire stripping accuracy.
  • Time Savings:​ Eliminates 2+ hours of manual wiring per module.
  • Compliance:​ Meets UL AWM 20963 standards for industrial durability.
6. What’s the max I/O capacity per PLC?​
With 8 modules (max per PLC), the system supports 256 I/O points​ (32 points/module × 8 modules).
7. Can I use this for analog I/O?​
Yes, but ensure the module’s voltage matches the cable’s insulation rating (up to 600V AC/DC).
