Product Overview
The GE IC693DNM200 – BD is a high – performance DeviceNet master module, an integral part of the GE Fanuc 90 – 30 series programmable logic controller (PLC) platform, now under Emerson Automation. This single – slot communication module is engineered to facilitate seamless and efficient communication within industrial automation systems.
Functionally, it serves as the central hub for DeviceNet networks. By supporting all standard DeviceNet data rates, specifically 125K, 250K, and 500K baud, it enables rapid data transfer between the PLC system and a plethora of connected devices. It can manage up to 63 DeviceNet slave devices, with each slave capable of handling up to 255 bytes of input data and 255 bytes of output data. In total, the module can receive up to 3972 bytes of input information and send out 3972 bytes of output information, ensuring comprehensive data handling for complex industrial setups. The IC693DNM200 – BD also allows for the establishment of 126 I/O connections, as each of the 63 slaves can be assigned up to two I/O stations. With features like configurable data connections (polling, strobe, cyclic, or change – of – state) and support for explicit messaging, it offers great flexibility in network communication. Its RS232 service port enables easy firmware upgrades, keeping the module up – to – date with the latest functionality and bug fixes.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC693DNM200 – BD |
| Manufacturer | General Electric (GE Fanuc, now Emerson Automation) |
| Product Type | DeviceNet Master Module |
| Communication Protocol | DeviceNet |
| Supported Data Rates | 125K, 250K, 500K baud |
| Max Input Data per Slave | 255 bytes |
| Max Output Data per Slave | 255 bytes |
| Total Input Data Capacity | 3972 bytes |
| Total Output Data Capacity | 3972 bytes |
| Number of Slave Devices Supported | 63 |
| Number of I/O Connections | 126 |
| Rated Voltage | 12 – 24 V DC (Positive Logic) |
| Backplane Current Consumption at 5V DC | 450 mA |
| Output Current per Point | 0.5 A |
| Surge Current | 5.4 A for 10 ms |
| Operating Temperature Range | 0 – 60 °C (32 – 140 °F) |
| Storage Temperature Range | – 40 – 85 °C (- 40 – 185 °F) |
| Module Location | Any slot in 90 – 30 series except slots 0 and 1 |
| Port Configuration | One DeviceNet terminal, one RS232 9 – pin D – type female (service port) |
IC693DNM200-BD
Main Features and Advantages
High – speed and Versatile Communication: With support for multiple high – speed DeviceNet data rates, the GE IC693DNM200 – BD ensures rapid data transfer. This is crucial for real – time control applications where quick response times are essential. Its ability to handle different data transfer modes (polling, strobe, cyclic, or change – of – state) makes it adaptable to various industrial processes, whether it’s a fast – paced manufacturing line or a complex process control system.
Extensive I/O and Slave Management: The module’s capacity to manage up to 63 slave devices and handle large amounts of input and output data (255 bytes per slave for both input and output) makes it suitable for large – scale industrial automation projects. It can efficiently coordinate the communication between the PLC and a wide range of connected devices such as sensors, actuators, and drives, enabling comprehensive control over industrial operations.
Reliable and Upgradable: Equipped with a RS232 service port for firmware upgrades, the IC693DNM200 – BD can stay relevant in evolving industrial environments. It is designed to operate reliably within a wide temperature range, from 0 to 60 °C during operation and – 40 to 85 °C during storage. This robustness ensures continuous operation even in harsh industrial settings, reducing the risk of system failures due to environmental factors.
Flexible Configuration: It offers flexible configuration options for data connections and supports explicit messaging, non – connected message manager (UCMM), and proxy connections. This flexibility allows engineers to tailor the network communication to the specific requirements of their industrial applications, whether it’s for simple point – to – point communication or complex multi – device network setups.
Extensive I/O and Slave Management: The module’s capacity to manage up to 63 slave devices and handle large amounts of input and output data (255 bytes per slave for both input and output) makes it suitable for large – scale industrial automation projects. It can efficiently coordinate the communication between the PLC and a wide range of connected devices such as sensors, actuators, and drives, enabling comprehensive control over industrial operations.
Reliable and Upgradable: Equipped with a RS232 service port for firmware upgrades, the IC693DNM200 – BD can stay relevant in evolving industrial environments. It is designed to operate reliably within a wide temperature range, from 0 to 60 °C during operation and – 40 to 85 °C during storage. This robustness ensures continuous operation even in harsh industrial settings, reducing the risk of system failures due to environmental factors.
Flexible Configuration: It offers flexible configuration options for data connections and supports explicit messaging, non – connected message manager (UCMM), and proxy connections. This flexibility allows engineers to tailor the network communication to the specific requirements of their industrial applications, whether it’s for simple point – to – point communication or complex multi – device network setups.
Application Field
In manufacturing industries, the GE IC693DNM200 – BD plays a pivotal role. In an automotive assembly plant, it can connect and control numerous sensors and actuators on the production line. For example, it can communicate with sensors that detect the position of car parts on conveyor belts and send control signals to actuators that operate robotic arms for precise part assembly. This ensures smooth and efficient production processes, minimizing errors and maximizing productivity.
In the food and beverage industry, it is used to manage the operation of various machinery. It can control the filling and capping machines, ensuring accurate filling levels and proper capping. By connecting to sensors that monitor liquid levels and cap tightness, and sending commands to the corresponding actuators, it helps maintain high – quality product standards.
Power generation facilities also benefit from the IC693DNM200 – BD. In a power plant, it can be used to connect and control variable – frequency drives (VFDs) that regulate the speed of pumps and fans. By communicating with these VFDs over the DeviceNet network, it can optimize the power consumption and performance of the equipment, contributing to more efficient power generation.
IC693DNM200-BD
Related Products
- GE IC693MDL940: An I/O module in the 90 – 30 series. While the IC693DNM200 – BD focuses on network communication as a DeviceNet master, the IC693MDL940 is designed for handling digital input and output signals. It can be connected to sensors and actuators, and the IC693DNM200 – BD can then communicate with it over the network to control and monitor the connected devices.
- GE IC693CPU374: A CPU module in the 90 – 30 series. The IC693CPU374 is responsible for overall system control and running the PLC programs. The IC693DNM200 – BD works in tandem with it, providing the communication interface for the CPU to interact with external DeviceNet devices. The CPU can send commands through the IC693DNM200 – BD to control the connected slaves and receive data from them for further processing.
- GE IC693ACC300: A power supply module for the 90 – 30 series. It provides the necessary electrical power for the operation of modules like the IC693DNM200 – BD. A stable power supply from the IC693ACC300 is essential for the reliable operation of the IC693DNM200 – BD, ensuring continuous and accurate communication within the DeviceNet network.
- GE IC693PBM200: A Profibus – DP master module. Similar to the IC693DNM200 – BD, it is a communication module but for Profibus – DP networks. While the IC693DNM200 – BD is focused on DeviceNet, the IC693PBM200 can be used in industrial setups where Profibus – DP is the preferred network protocol, and in some cases, both modules might be used in a larger industrial network to support different types of devices.
- GE IC693MDL930: Another I/O module with different I/O capabilities compared to the IC693MDL940. The IC693MDL930 can be integrated into the system along with the IC693DNM200 – BD to expand the range of input and output signals that can be handled in an industrial automation system. The IC693DNM200 – BD can manage the communication for these additional I/O modules, enabling a more comprehensive control solution.
Installation and Maintenance
Pre – installation preparation: Before installing the GE IC693DNM200 – BD, ensure that the power to the 90 – 30 series PLC system is turned off to avoid electrical hazards. Check the module for any visible signs of damage, such as bent pins or cracks in the casing. Verify that the installation slot in the 90 – 30 series rack is clean and free of debris, and is not slot 0 or 1 as the module is not compatible with these slots. Also, ensure that the power supply within the system can provide the required 12 – 24 V DC with sufficient current to power the module.
Maintenance recommendations: Regularly monitor the status of the IC693DNM200 – BD through the PLC system’s diagnostic tools. Check for any abnormal communication patterns, such as dropped connections or slow data transfer rates. Clean the module periodically to remove dust, especially in dusty industrial environments, as dust accumulation can affect its performance. Update the firmware regularly through the RS232 service port to benefit from the latest features and bug fixes. If any issues are detected, refer to the detailed GE – provided manuals for troubleshooting steps. In case of complex problems, contact GE’s technical support for expert assistance to keep the module operating at its best.
Maintenance recommendations: Regularly monitor the status of the IC693DNM200 – BD through the PLC system’s diagnostic tools. Check for any abnormal communication patterns, such as dropped connections or slow data transfer rates. Clean the module periodically to remove dust, especially in dusty industrial environments, as dust accumulation can affect its performance. Update the firmware regularly through the RS232 service port to benefit from the latest features and bug fixes. If any issues are detected, refer to the detailed GE – provided manuals for troubleshooting steps. In case of complex problems, contact GE’s technical support for expert assistance to keep the module operating at its best.
Product Guarantee
GE, now Emerson Automation, stands firmly behind the quality of the GE IC693DNM200 – BD DeviceNet master module. It typically comes with a standard one – year warranty, covering any defects in materials and workmanship under normal usage conditions. In the unlikely event that the module malfunctions within this period, Emerson Automation’s dedicated technical support team is readily available. They can offer comprehensive assistance, from providing installation guidance and helping with configuration issues to troubleshooting operational problems. This commitment reflects their confidence in the product’s reliability and performance, giving customers peace of mind when integrating the IC693DNM200 – BD into their critical industrial automation systems.
