Product Overview
The GE IC693PCM311 is a high – performance programmable coprocessor module, an integral part of the esteemed Series 90 – 30 lineup. In industrial automation systems, it serves as a crucial component, enhancing the processing capabilities and communication efficiency. This module is designed to handle complex tasks, making it suitable for a wide range of industrial applications.
The IC693PCM311 comes equipped with 640 k of battery – backed RAM, ensuring data integrity even during power disruptions. It has 190 k of dedicated Mega Basic memory, which is beneficial for running specific programs. It supports communication protocols like Modbus RTU and GE Fanuc CCM, allowing seamless interaction with other devices in the industrial network. With two ports on its front panel, it can be easily connected to programming terminals, CRTs, bar code readers, and other ASCII devices. This makes it an ideal choice for applications that require extensive data exchange and real – time control, such as in manufacturing plants, power generation facilities, and process control systems.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC693PCM311 |
| Manufacturer | GE |
| Product Type | Programmable Coprocessor Module |
| Series | Series 90 – 30 |
| Communication Protocols | Modbus RTU, GE Fanuc CCM |
| Memory Backup | Lithium battery |
| Replacement Battery | IC693ACC301 (pkg of 2) |
| Battery – backed RAM | 640 k |
| Dedicated Mega Basic Memory | 190 k |
| Status LEDs | 3 |
| Number of Ports | 2 |
| Internal Power | 400 mA @ 5 VDC |
| Operating Temperature | 0 – 60 °C |
| Storage Temperature | – 40 – 100 °C |
| Relative Humidity | 5% – 95%, non – condensing |
| Weight | 450 g |
IC693PCM311
Main Features and Advantages
Robust Memory Management: The IC693PCM311‘s 640 k of battery – backed RAM ensures that important data is retained during power outages, preventing any loss of critical information. This is crucial for industrial applications where continuous operation and data integrity are essential. The 190 k of dedicated Mega Basic memory provides a sufficient space for running specific programs, optimizing the module’s performance for particular tasks.
Versatile Communication Capabilities: With support for Modbus RTU and GE Fanuc CCM protocols, the module can communicate with a wide array of devices. This compatibility enables seamless integration into existing industrial networks, whether they are based on Modbus – enabled sensors or other GE – specific equipment. The two – port design on the front panel further enhances its connectivity, allowing for easy connection to various input and output devices.
Reliable Operation: The use of a lithium battery for memory backup not only protects data but also contributes to the module’s reliable operation. The three status LEDs provide clear visual indications of the module’s working status, making it easy for operators to monitor and troubleshoot. Its ability to operate within a temperature range of 0 – 60 °C and relative humidity of 5% – 95% (non – condensing) ensures it can function well in diverse industrial environments.
Versatile Communication Capabilities: With support for Modbus RTU and GE Fanuc CCM protocols, the module can communicate with a wide array of devices. This compatibility enables seamless integration into existing industrial networks, whether they are based on Modbus – enabled sensors or other GE – specific equipment. The two – port design on the front panel further enhances its connectivity, allowing for easy connection to various input and output devices.
Reliable Operation: The use of a lithium battery for memory backup not only protects data but also contributes to the module’s reliable operation. The three status LEDs provide clear visual indications of the module’s working status, making it easy for operators to monitor and troubleshoot. Its ability to operate within a temperature range of 0 – 60 °C and relative humidity of 5% – 95% (non – condensing) ensures it can function well in diverse industrial environments.
Application Field
Manufacturing Plants: In manufacturing, the GE IC693PCM311 can be used to control and monitor production lines. It can communicate with sensors that detect the position of products on conveyor belts and actuators that perform tasks like picking, placing, and assembling. For example, it can receive data from proximity sensors to ensure accurate positioning of parts and then send control signals to robotic arms for precise assembly operations.
Power Generation Facilities: In power plants, this module plays a vital role. It can interface with sensors that measure parameters such as temperature, pressure, and flow rate in boilers and turbines. By using Modbus RTU or GE Fanuc CCM protocols, it can communicate with other control systems to optimize the power generation process. It can also be used to monitor and control the operation of auxiliary equipment like pumps and fans, ensuring efficient and reliable power production.
Process Control Systems: In industries such as chemical and petrochemical, the IC693PCM311 is used to manage complex chemical reactions. It can connect to sensors that monitor the concentration of chemicals, pH levels, and reaction temperatures. Based on the data received, it can send control signals to adjust the flow of reactants, control heating or cooling systems, and ensure the quality and consistency of the final products.
IC693PCM311
Related Products
IC693PCM313: Another programmable coprocessor module in the Series 90 – 30. It may have enhanced processing capabilities or different memory configurations compared to the IC693PCM311, suitable for more complex applications with higher computational demands.
IC693ALG392: An analog output module in the same series. While the IC693PCM311 focuses on processing and communication, the IC693ALG392 is used for outputting analog signals, which can be useful in applications where the control system needs to provide analog control signals, such as for modulating valves or controlling variable – speed drives.
IC693MDL940: A digital input/output module. It can be used in conjunction with the IC693PCM311 to expand the digital I/O capabilities of the system. The IC693PCM311 can process the signals received from the IC693MDL940 and make decisions based on them.
IC697CPU782RR: A CPU module with higher processing power. In more complex industrial setups, the IC693PCM311 can be paired with the IC697CPU782RR to create a more powerful control system, where the CPU module handles the main processing tasks and the IC693PCM311 focuses on specific coprocessing and communication functions.
GE PLC Communication Modules: These modules can be used to further expand the communication capabilities of the IC693PCM311. They can enable the module to communicate over additional protocols or connect to a wider range of devices, enhancing the overall connectivity of the industrial control system.
IC693ALG392: An analog output module in the same series. While the IC693PCM311 focuses on processing and communication, the IC693ALG392 is used for outputting analog signals, which can be useful in applications where the control system needs to provide analog control signals, such as for modulating valves or controlling variable – speed drives.
IC693MDL940: A digital input/output module. It can be used in conjunction with the IC693PCM311 to expand the digital I/O capabilities of the system. The IC693PCM311 can process the signals received from the IC693MDL940 and make decisions based on them.
IC697CPU782RR: A CPU module with higher processing power. In more complex industrial setups, the IC693PCM311 can be paired with the IC697CPU782RR to create a more powerful control system, where the CPU module handles the main processing tasks and the IC693PCM311 focuses on specific coprocessing and communication functions.
GE PLC Communication Modules: These modules can be used to further expand the communication capabilities of the IC693PCM311. They can enable the module to communicate over additional protocols or connect to a wider range of devices, enhancing the overall connectivity of the industrial control system.
Installation and Maintenance
Pre – installation preparation: Before installing the IC693PCM311, make sure the power supply is stable and within the appropriate voltage range. Check the installation area for any sources of electromagnetic interference that could disrupt the module’s operation. Familiarize yourself with the wiring diagram and ensure that all necessary cables, such as the IC 693 CBL 305 cables for connecting to the ports on the module’s front, are available. Do not install the module in slot 1 (the main CPU slot), and note that remote and expansion baseplates without extra CPU slots cannot support this module.
Maintenance recommendations: Regularly check the IC693PCM311 for any signs of physical damage, such as cracks in the casing or loose connections. Monitor the status LEDs to quickly identify any operational issues. If the module is not in use for an extended period, unplug the lithium battery (IC693ACC301) to preserve its lifespan. Periodically clean the module to remove dust, as dust accumulation can lead to overheating. If there are communication problems, verify the integrity of the communication cables and check the configured communication protocols.
Maintenance recommendations: Regularly check the IC693PCM311 for any signs of physical damage, such as cracks in the casing or loose connections. Monitor the status LEDs to quickly identify any operational issues. If the module is not in use for an extended period, unplug the lithium battery (IC693ACC301) to preserve its lifespan. Periodically clean the module to remove dust, as dust accumulation can lead to overheating. If there are communication problems, verify the integrity of the communication cables and check the configured communication protocols.
Product Guarantee
GE offers a comprehensive product guarantee for the IC693PCM311. The module comes with a standard warranty period, during which GE ensures that the product is free from defects in materials and workmanship. In case of any quality – related issues, GE’s dedicated technical support team is readily available. They can provide detailed guidance on installation, troubleshooting, and if necessary, arrange for product repair or replacement. This commitment reflects GE’s confidence in the reliability and performance of the IC693PCM311, giving customers peace of mind when integrating it into their critical industrial systems.
