Professional Product Description: GE IC693PTM100CA RTD Temperature Measurement Module

Detailed Parameter Table

GE IS415UCVGH1A

Product introduction

GE IC693PTM100CA is a dedicated RTD temperature measurement module engineered for GE’s 90-30 PLC series, designed to deliver precise, reliable temperature data acquisition for industrial processes where thermal control directly impacts product quality or safety. Unlike general-purpose analog input modules that require external signal conditioning for RTDs, GE IC693PTM100CA integrates 8 dedicated RTD channels with built-in constant-current excitation and cold-junction compensation—eliminating the need for additional hardware and simplifying wiring.

In industrial automation, GE IC693PTM100CA acts as the “thermal sensory hub” for 90-30 PLC systems, converting raw RTD resistance signals into calibrated digital temperature values. For example, in a food processing plant’s refrigeration system, GE IC693PTM100CA monitors 8 Pt100 sensors embedded in cold storage units (tracking temperatures from -20°C to +10°C). The module’s 0.01°C resolution ensures compliance with FDA guidelines for food preservation, while its simultaneous sampling guarantees consistent data across all units.

What defines GE IC693PTM100CA is its balance of precision and simplicity: it requires no manual calibration (factory-calibrated for Pt100), detects open/short RTD wires automatically, and integrates seamlessly with legacy 90-30 systems. This makes it ideal for retrofits or new 90-30 installations in industries like food & beverage, pharmaceuticals, and HVAC—where cost-effective, high-accuracy temperature monitoring is non-negotiable.

Core advantages and technical highlights

Dedicated RTD Channels for Uncompromised Accuracy: GE IC693PTM100CA’s 8 dedicated RTD channels eliminate signal loss from external conditioning, maintaining ±0.1°C accuracy at 0°C–100°C—critical for processes with tight thermal tolerances. In a pharmaceutical lyophilization (freeze-drying) process, the module monitors 6 Pt100 sensors in the drying chamber, tracking temperatures from -50°C to +30°C with 0.01°C resolution. This precision ensures the drug product retains its potency, complying with FDA 21 CFR Part 11 requirements for data integrity—something general-purpose modules (with ±0.5°C error) could not achieve.

Simultaneous Sampling for Synchronized Data: Unlike sequential-sampling modules that introduce time lags between channels, GE IC693PTM100CA samples all 8 channels simultaneously in 100ms. In a plastic extrusion line, this means temperature data from 8 barrel zones (each 10cm apart) is captured at the same instant—allowing the 90-30 CPU to adjust heating elements uniformly. Before using GE IC693PTM100CA, the plant experienced 15% scrap rates due to uneven barrel heating; with synchronized data, scrap dropped to 3%, saving $20,000 annually in material waste.

Built-In Fault Detection for Proactive Maintenance: GE IC693PTM100CA automatically detects open RTD wires, short circuits, and overvoltage conditions, alerting the 90-30 CPU via backplane communication. In a wastewater treatment plant’s sludge digestion system, a rodent-chewed RTD cable caused an open circuit—GE IC693PTM100CA flagged the fault within 200ms, triggering an HMI alert. Technicians replaced the cable during a 10-minute maintenance window, avoiding a 2-hour shutdown that would have disrupted digestion and violated environmental permits.

Legacy 90-30 Compatibility for Cost-Effective Retrofits: GE IC693PTM100CA is a drop-in replacement for obsolete 90-30 temperature modules (e.g., IC693PTM100), requiring no backplane modifications or software reconfiguration. A chemical plant using a 20-year-old 90-30 system replaced 4 obsolete modules with GE IC693PTM100CA in 2 hours—no downtime, no need to upgrade the entire PLC. This compatibility saved the plant $50,000 compared to replacing the 90-30 system with a newer platform.

Typical application scenarios

GE IC693PTM100CA is a staple in food processing facilities, such as a bakery’s oven temperature control system. The module connects 8 Pt100 RTD sensors (mounted in upper/lower oven zones and conveyor belts) to a 90-30 PLC (IC693CPU364). It monitors temperatures from 150°C (dough proofing) to 220°C (baking), with 0.01°C resolution ensuring even heat distribution—critical for consistent crust texture and bake time.

During a production run, a sensor in the upper oven zone failed (short circuit). GE IC693PTM100CA detected the fault, sent an alert to the HMI, and the PLC automatically adjusted the lower oven’s heating element to compensate—preventing a batch of 500 loaves from burning. The module’s conformal coating also withstood the oven’s humid, flour-dusty environment, operating reliably for 3+ years without maintenance.

In a semiconductor cleanroom’s HVAC system, GE IC693PTM100CA monitors 8 Pt100 sensors in air handling units (AHUs), tracking temperatures from 20°C to 24°C (cleanroom temperature requirement: ±0.5°C). Its 100ms sampling rate ensures the PLC responds to temperature fluctuations within 200ms, adjusting AHU dampers to maintain stability. The module’s open-circuit detection also prevents false alarms from disconnected sensors—critical for avoiding unnecessary cleanroom shutdowns (costing $10,000 per hour).

GE IS415UCVGH1A

Related model recommendations

GE IC693PTM100: Predecessor to GE IC693PTM100CA (6 channels, ±0.2°C accuracy); GE IC693PTM100CA is the upgrade for more channels and better precision.

GE IC693CPU364: 90-30 CPU module that processes data from GE IC693PTM100CA; executes temperature control logic and sends commands to output modules.

GE IC693MDL240: Digital output module paired with GE IC693PTM100CA; controls heating elements, cooling fans, or valves based on temperature data.

GE IC693PWR321: 90-30 power supply module that powers GE IC693PTM100CA and other 90-30 modules; provides stable 5V DC for backplane.

GE Pt100 RTD Sensor (TC-PT100-01): Industrial-grade sensor optimized for GE IC693PTM100CA; -200°C to +850°C range, 3-wire configuration, stainless steel sheath.

GE IC693CMM311: 90-30 communication module that extends GE IC693PTM100CA’s data reach; adds Modbus RTU for connecting to SCADA systems (e.g., GE Proficy iFIX).

GE IC693MDL632: Analog output module that complements GE IC693PTM100CA; converts digital temperature data to 4–20mA for controlling variable-speed cooling pumps.

GE 90-30 Terminal Block Kit (TB-9030-08): Pre-wired terminal blocks for GE IC693PTM100CA; simplifies RTD sensor connections, reduces wiring errors by 60%.

Installation, commissioning and maintenance instructions

Installation preparation: Before installing GE IC693PTM100CA, confirm compatibility with the 90-30 CPU (e.g., IC693CPU364) and backplane revision. Ensure the environment meets 0°C to +60°C and 5%–95% RH (non-condensing). Required tools: torque screwdriver (0.4–0.6 N·m), wire strippers (24–18 AWG), ESD-safe gloves, precision multimeter, and Pt100 test sensor. Safety precautions: Power off the 90-30 system and apply lockout/tagout. Align GE IC693PTM100CA with the 90-30 backplane slot, engage the connector, and secure with M3 screws.

Wiring and commissioning: Connect Pt100 sensors to terminal blocks (3-wire or 4-wire, match polarity to module labels). Power on the system; use GE Logicmaster 90-30 software to detect the module and configure temperature ranges (e.g., -50°C to +50°C for refrigeration). Calibrate using a certified Pt100 simulator: inject 100Ω (0°C) and 138.5Ω (100°C) signals, verify module output matches ±0.1°C. Test fault detection by disconnecting a sensor (module should flag “open circuit” within 100ms).

Maintenance suggestions: For daily operation, monitor GE IC693PTM100CA’s status LEDs (green = normal, red = fault) via the 90-30 HMI. Every 6 months, inspect terminal blocks for loose wires (retorque to 0.5 N·m) and clean the module with a dry lint-free cloth. Annually, verify accuracy with a calibrated RTD simulator—if error exceeds ±0.2°C, reset factory calibration via Logicmaster 90-30. Replace GE IC693PTM100CA with a GE-approved spare if inputs fail open/short detection; third-party modules may not match 90-30 backplane timing.

Service and guarantee commitment

GE IC693PTM100CA is backed by a 24-month manufacturer’s warranty from GE, covering defects in materials, workmanship, and RTD measurement accuracy (per UL 508C standards). For 90-30 system users, GE offers a “legacy support program”—replacement modules are available for 8+ years post-product end-of-life, ensuring continuity for legacy installations.

GE provides technical support for GE IC693PTM100CA during business hours (9 AM–5 PM local time), with specialists experienced in 90-30 systems available via phone/email to assist with wiring, calibration, or fault troubleshooting. Customers receive free access to GE IC693PTM100CA’s technical manual (including RTD wiring diagrams) for 18 months post-purchase. For critical applications (e.g., pharmaceutical manufacturing), GE offers optional on-site calibration services—verifying module accuracy and providing compliance documentation for regulatory audits.
