Product Overview
The GE IC693PWR330G is a high – capacity power supply module, part of the renowned GE Fanuc Series 90 – 30 platform. This module is designed to meet the demanding power requirements of industrial control systems, offering reliable and stable power distribution.
With a nominal input voltage range of 85 to 264 VAC or 100 to 300 VDC, the IC693PWR330G can adapt to various power sources commonly found in industrial settings. It has a total load capacity of 30 watts, with the ability to allocate a significant 30 watts to the +5 VDC output, making it ideal for applications where higher current capacity at this voltage level is essential, such as in larger 90 – 30 PLC racks. The module provides three distinct outputs: a +5 VDC output for powering sensitive electronic components, a +24 VDC relay power output to energize the circuitry on Series 90 – 30 output relay modules, and an isolated +24 VDC output, which can be used internally by some modules or to supply external power for 24 VDC input cards. This versatility in output options allows for seamless integration within complex industrial automation setups, ensuring that different components receive the appropriate power supply they need to function optimally.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC693PWR330G |
| Manufacturer | GE |
| Product Type | High – Capacity Power Supply Module |
| Series | 90 – 30 |
| Nominal Rated Voltage | 120/240 VAC or 125 VDC |
| Input Voltage Range (AC) | 85 to 264 VAC |
| Input Voltage Range (DC) | 100 to 300 VDC |
| Input Power | 90 VA with VAC; 50 W with VDC |
| Output Voltage (+5 VDC) | 5.0 – 5.2 VDC (nominal 5.1 VDC) |
| Output Voltage (+24 VDC Relay) | 24 – 28 VDC |
| Output Voltage (Isolated +24 VDC) | 21.5 – 28 VDC |
| Output Power (+5 VDC) | 30 watts maximum |
| Output Power (+24 VDC Relay) | 15 watts maximum |
| Output Power (Isolated +24 VDC) | 20 watts maximum |
| Holdup Time | 20 milliseconds minimum |
| Communication | RS485 |
| Protective Limit (+5 VDC Overvoltage) | 6.4 – 7 volts |
| Protective Limit (+5 VDC Overcurrent) | 7 amps |
| Standards | CE, UL |
| Number of Connection Terminals | 6 |
| Location on Baseplates | Leftmost slot |
IC693PWR330G
Main Features and Advantages
High – capacity power output: The GE IC693PWR330G stands out with its ability to deliver 30 watts of power to the +5 VDC output. This high – capacity feature makes it suitable for applications that require substantial power at this voltage, such as power – hungry industrial control components. In large – scale industrial automation systems, where multiple devices need to be powered simultaneously, the IC693PWR330G can ensure stable operation without overloading the power supply.
Multiple output options: Its three – output configuration provides great flexibility. The +24 VDC relay power output is specifically designed to power Series 90 – 30 output relay modules, while the isolated +24 VDC output can be used for both internal module power needs and external 24 VDC input card power supply. This allows for a more customized and efficient power distribution within the industrial control system, catering to the diverse power requirements of different components.
Reliable protection features: The module is equipped with overvoltage and overcurrent protective limits for the 5 volts DC output. In case of voltage spikes or excessive current draw, these protective features kick in to safeguard the connected components and prevent damage to the power supply itself. The built – in fuse in the input also acts as a backup protection mechanism, further enhancing the reliability and safety of the power supply in case of unexpected electrical faults.
RS485 communication port: The embedded RS485 communication port enables seamless connection to a desktop or laptop workstation, a GE Fanuc hand – held programmer, or other compatible serial devices. This communication capability allows for remote monitoring and configuration of the power supply, making it easier for technicians to manage and troubleshoot the power supply system in an industrial setting.
IC693PWR330G
Application Field
Industrial automation: In manufacturing plants, the GE IC693PWR330G powers a wide range of industrial control components. It can supply power to programmable logic controllers (PLCs), which are crucial for controlling the operation of production lines, such as robotic arms, conveyor belts, and assembly machines. By providing a stable power source, it ensures the smooth and accurate operation of these devices, enhancing production efficiency and product quality.
Process control: In industries like chemical and oil & gas, where precise control of processes is essential, the IC693PWR330G plays a vital role. It powers sensors and actuators that monitor and control parameters such as temperature, pressure, and flow rate. The stable power supply provided by this module is critical for the accurate functioning of these devices, ensuring that the process control system can make real – time adjustments to maintain optimal process conditions.
Building automation: In smart buildings, the power supply module is used to power various control systems. It can provide power to lighting control systems, HVAC (heating, ventilation, and air – conditioning) controllers, and access control systems. By supplying reliable power, it enables these systems to function efficiently, contributing to energy savings and improved building management.
Process control: In industries like chemical and oil & gas, where precise control of processes is essential, the IC693PWR330G plays a vital role. It powers sensors and actuators that monitor and control parameters such as temperature, pressure, and flow rate. The stable power supply provided by this module is critical for the accurate functioning of these devices, ensuring that the process control system can make real – time adjustments to maintain optimal process conditions.
Building automation: In smart buildings, the power supply module is used to power various control systems. It can provide power to lighting control systems, HVAC (heating, ventilation, and air – conditioning) controllers, and access control systems. By supplying reliable power, it enables these systems to function efficiently, contributing to energy savings and improved building management.
Related Products
- GE IC693PWR321: A standard power supply in the same series. While it also has a 30 – watt load capacity, it does not have the ability to allocate all 30 watts to the +5 VDC output like the IC693PWR330G. It is more suitable for applications with less demanding +5 VDC power requirements.
- GE IC697PWR711: This power supply module is part of the GE 90 – 70 series. It may have different voltage outputs, power capacities, and compatibility compared to the IC693PWR330G. It is designed for use in larger and more complex industrial control systems within the 90 – 70 platform.
- GE IC200PWR001: Belonging to the GE Fanuc Series 200, it is a power supply with its own set of specifications. It likely has different input and output voltage ranges and power capabilities, and is used in systems that are based on the Series 200 platform, which may have different application requirements compared to the Series 90 – 30 where the IC693PWR330G is used.
- GE IC695PWR320: Another power supply module within the GE product range. It may offer different features in terms of output power distribution, communication capabilities, or physical dimensions. It could be an alternative for applications where the specific features of the IC693PWR330G are not fully required or where a different form factor is more suitable.
- GE IC698PWR320: Designed for use in the GE PACSystems RX3i series, it has its own unique power – related characteristics. It is meant to power components within this particular series of industrial control systems, which may have different power needs and system architectures compared to the Series 90 – 30 systems that the IC693PWR330G is tailored for.
Installation and Maintenance
Pre – installation preparation: Before installing the GE IC693PWR330G, carefully check the input voltage of the power source to ensure it falls within the specified range of 85 to 264 VAC or 100 to 300 VDC. Verify that the installation location is clean, dry, and free from excessive heat or humidity. Inspect the power supply module for any visible signs of damage during transit. Also, make sure to have the necessary tools for installation, such as screwdrivers if the module requires physical mounting.
Maintenance recommendations: Regularly monitor the status LEDs on the IC693PWR330G. The PWR LED should indicate that the module is receiving sufficient external power, the OK LED shows the overall operational status, the run LED gives information about the module’s running state, and the batt LED indicates the battery charge (if applicable). Check the connection terminals for any signs of looseness or corrosion, as these can affect the power supply’s performance. Periodically clean the module to remove dust and debris, which can accumulate and potentially cause overheating. In case of any power – related issues, refer to the product manual’s troubleshooting section or contact GE’s technical support for assistance.
Maintenance recommendations: Regularly monitor the status LEDs on the IC693PWR330G. The PWR LED should indicate that the module is receiving sufficient external power, the OK LED shows the overall operational status, the run LED gives information about the module’s running state, and the batt LED indicates the battery charge (if applicable). Check the connection terminals for any signs of looseness or corrosion, as these can affect the power supply’s performance. Periodically clean the module to remove dust and debris, which can accumulate and potentially cause overheating. In case of any power – related issues, refer to the product manual’s troubleshooting section or contact GE’s technical support for assistance.
Product Guarantee
GE offers a comprehensive product guarantee for the GE IC693PWR330G. The module is designed and manufactured to meet high – quality standards, undergoing rigorous testing procedures. In case of any manufacturing defects, GE provides a specified warranty period during which they will repair or replace the module free of charge. Their global network of technical support teams is readily available to offer assistance. Whether it’s helping with installation queries, providing guidance on maintenance, or troubleshooting any power – supply – related problems, GE is committed to ensuring that customers can rely on the IC693PWR330G for long – term, stable operation in their industrial control systems. This reflects GE’s confidence in the quality and reliability of the product, giving customers peace of mind when using this power supply module in their critical industrial applications.
