Product Overview
The GE IC695CPU315 – BB is a high – performance central processing unit (CPU) module, an integral part of GE’s PACSystems RX3i series. Engineered to meet the demands of modern industrial automation, it plays a pivotal role in controlling and managing complex industrial processes.
Built around an Intel Celeron – M microprocessor running at 1.0 GHz, the IC695CPU315 – BB offers remarkable computational power. This allows it to execute a wide range of control algorithms and data processing tasks with high speed and precision. It comes equipped with 20 MB of user memory, which is ideal for storing extensive control programs, large volumes of data, and complex application logic. Additionally, it features 20 MB of flash storage memory, providing non – volatile storage for crucial system and user data, ensuring data integrity even during power outages. As a programmable controller, it can perform up to 32 k I/O operations per second, making it highly responsive to the real – time needs of industrial systems.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC695CPU315 – BB |
| Manufacturer | GE |
| Product Type | Central Processing Unit Module |
| Series | PACSystems RX3i |
| Processor | Intel Celeron – M, 1.0 GHz |
| User Memory | 20 MB |
| Flash Memory | 20 MB |
| I/O Operations per Second | Up to 32 k |
| Communication Ports | 2 integrated serial ports (1 RS – 232, 1 RS – 485) |
| Supported Serial Protocols | Serial I/O, Modbus RTU Slave, SNP |
| Bus Support | High – speed serial and RX3i PCU bus |
| Nominal Current Consumption | 1.2 A at 5V DC, 1 A at 3.3V DC |
| Operating Temperature Range | 32 – 140 degrees Fahrenheit (0 – 60 degrees Celsius) |
| Internal Clock Drift | 2 seconds per day (peak) |
| Internal Timing Precision | 0.01% |
| Program Blocks Supported | Up to 512, with 128 KB size per block |
| PCI Compliance | Version 2.2 |
| Weight | Approximately 1 lbs 0.0 oz (0.5 kg) |
| Dimensions | 2.8″ x 5.3″ x 5.3″ (7.0 cm x 13.3 cm x 13.3 cm) |
IC695CPU315-BB
Main Features and Advantages
High – Performance Processing
The 1.0 GHz Intel Celeron – M microprocessor in the GE IC695CPU315 – BB enables it to handle complex calculations and control tasks with ease. Whether it’s processing large amounts of sensor data in real – time or executing intricate control algorithms, the module’s high – speed processing ensures that industrial processes run smoothly and efficiently. This high – performance processing also reduces the overall cycle time of the control system, leading to increased productivity in industrial operations.
Ample Memory Capacity
With 20 MB of user memory and 20 MB of flash memory, the IC695CPU315 – BB provides plenty of space for users to develop and store comprehensive control programs. The large user memory allows for the implementation of complex logic, while the flash memory safeguards critical data and programs. This ample memory capacity means that the module can support large – scale industrial applications without the need for frequent memory upgrades, future – proofing the system.
Versatile Communication Capabilities
Featuring two integrated serial ports (one RS – 232 and one RS – 485) that support multiple serial protocols like Serial I/O, Modbus RTU Slave, and SNP, the GE IC695CPU315 – BB can communicate with a wide variety of industrial devices. This includes sensors, actuators, other PLCs, and human – machine interfaces (HMIs). The ability to interface with different devices using multiple protocols enhances the module’s compatibility within industrial networks, making it easier to integrate into existing or new industrial automation setups.
Compatibility and Expandability
The IC695CPU315 – BB supports most GE Series 90 – 30 modules and can be used with expansion racks. This compatibility allows for easy system expansion as industrial requirements grow. Users can add more input/output modules, communication modules, or other specialized modules to meet changing process needs. The module’s compliance with the PCI 2.2 standard also ensures its compatibility with a range of industry – standard hardware components.
IC695CPU315-BB
Application Field
The GE IC695CPU315 – BB finds extensive use across multiple industries. In manufacturing plants, it is used to control production lines. For example, it can manage the operation of robotic arms, conveyor belts, and assembly stations. By processing real – time data from sensors placed along the production line, it can adjust the speed of conveyor belts, control the movement of robotic arms for precise product handling, and ensure seamless coordination between different components of the production line, thereby improving production efficiency and product quality.
In the energy sector, power plants rely on the IC695CPU315 – BB for the control and monitoring of power – generation equipment. It can receive data from sensors that monitor parameters such as temperature, pressure, and voltage in generators and turbines. Based on this data, the module can make real – time adjustments to the operation of these components, ensuring optimal power generation and distribution. It can also be used to control the switching of power distribution systems, enhancing grid stability.
In the food and beverage industry, the GE IC695CPU315 – BB is employed to control the manufacturing process. It can regulate the filling of bottles, cans, or cartons, ensuring accurate volume control. It can also manage the capping, labeling, and packaging operations. By precisely controlling these processes, it helps maintain product consistency and quality, and reduces waste.
Related Products
- GE IC695ACC302: This is an intelligent auxiliary battery for the IC695CPU315 – BB. It provides backup power to ensure that the CPU module can retain its data and continue to function for a short period during power outages, protecting against data loss and system disruptions.
- GE IC693ACC302: A regular auxiliary battery for the IC695CPU315 – BB. While it may not have the advanced features of the IC695ACC302, it still serves as a reliable backup power source for the CPU module, ensuring data integrity during power – related issues.
- GE IC690RBT001: A rechargeable battery option for the IC695CPU315 – BB. It offers the convenience of rechargeability, reducing the need for frequent battery replacements and providing a cost – effective and environmentally friendly backup power solution.
- GE Series 90 – 30 Modules: Modules like the GE IC693MDL940 (digital input/output module). The IC695CPU315 – BB can communicate with these modules, receiving input data from sensors connected to the digital input channels and sending control signals to actuators through the digital output channels. Different Series 90 – 30 modules offer various I/O configurations and functions to expand the capabilities of the overall control system.
- GE RX3i Expansion Racks: These racks, such as specific models designed for the RX3i series, provide additional slots for installing more modules. The IC695CPU315 – BB can be used in conjunction with these expansion racks to increase the number of I/O points, communication interfaces, or other specialized modules in the industrial control system as the application requirements grow.
Installation and Maintenance
Pre – installation preparation: Before installing the GE IC695CPU315 – BB, ensure that the power to the industrial control system is turned off. Familiarize yourself with the module’s technical documentation, including the installation guide. Check the compatibility of the module with the existing system, such as the power supply requirements and the type of expansion racks or other modules it will be connected to. Clean the installation area to prevent dust and debris from affecting the module’s performance. Make sure that all the necessary cables and connectors are in good condition and are the correct type for the installation.
Maintenance recommendations: Regularly inspect the GE IC695CPU315 – BB for any signs of physical damage, such as cracks in the casing or loose connections. Monitor the temperature of the operating environment to ensure it stays within the specified range, as overheating can affect the module’s performance. Check the status of the communication ports and the data transfer rates to ensure that the module is communicating effectively with other devices in the system. Update the module’s firmware as new versions become available from GE, as these updates often include performance improvements, bug fixes, and enhanced features. Keep the module clean by periodically removing dust, as dust buildup can cause electrical problems.
Product Guarantee
GE stands firmly behind the quality of the GE IC695CPU315 – BB. The module comes with a standard one – year warranty from the date of purchase. During this period, if there are any defects in materials or workmanship, GE will provide repair or replacement services free of charge. GE also offers comprehensive technical support to assist customers with installation, configuration, and troubleshooting. Their team of experts is available to answer any questions and provide solutions to ensure the seamless operation of the IC695CPU315 – BB in industrial control systems. This commitment to quality and after – sales support gives customers the confidence to rely on the GE IC695CPU315 – BB for their critical industrial applications, knowing that they are backed by a trusted and experienced manufacturer.
