Product Introduction

The GE IC695CRU320-EN is a high-scalability CPU module in GE’s RX3i PLC family, designed to serve as the “brain” of mid-to-large-scale industrial automation systems. Unlike entry-level RX3i CPUs, the GE IC695CRU320-EN integrates a 1.0 GHz RISC processor and expanded memory, enabling it to handle complex, multi-function control tasks—from discrete logic and PID process regulation to multi-axis motion synchronization—without performance bottlenecks.

Technical positioning for industries like renewable energy, water treatment, and automotive component manufacturing, the GE IC695CRU320-EN supports up to 131,072 discrete I/O points, making it ideal for systems requiring centralized control of distributed equipment (e.g., remote pump stations, solar inverter arrays). It runs on GE’s Proficy Machine Edition software, unifying diverse control functions into a single programming environment—eliminating the need for separate motion or process controllers. In automation architectures, the GE IC695CRU320-EN acts as the “decision hub,” processing real-time data from sensors/I/O modules, executing control logic, and communicating with upstream SCADA/MES systems—ensuring reliable, efficient operation of critical processes.

Core Advantages and Technical Highlights

High-speed control processing: The GE IC695CRU320-EN’s 1.0 GHz RISC processor delivers a control update rate as fast as 0.1 ms—2x faster than entry-level RX3i CPUs like the IC695CRU310-EN. This speed is critical for time-sensitive applications like automotive transmission assembly lines, where the GE IC695CRU320-EN synchronizes 12 robotic torque tools to within 0.05 ms, reducing fastening errors by 35% and improving production throughput.

Expansive I/O scalability: With support for up to 131,072 discrete and 16,384 analog I/O points, the GE IC695CRU320-EN scales to large, distributed systems without adding extra CPUs. For example, a solar farm with 500 inverters can use one GE IC695CRU320-EN to monitor and control all inverters (via RX3i remote I/O modules), eliminating the need for multiple regional controllers and simplifying system management.

Integrated high-speed communication: The GE IC695CRU320-EN includes two gigabit EtherNet/IP ports, enabling direct connection to high-speed devices like machine vision cameras, servo drives, and enterprise MES platforms. Unlike CPUs requiring external communication modules, the GE IC695CRU320-EN natively supports CIP Sync (for time synchronization) and CIP Motion (for multi-axis control), reducing chassis slot usage and lowering hardware costs.

Hot-standby redundancy for zero downtime: The GE IC695CRU320-EN supports hot-standby redundancy when paired with a second GE IC695CRU320-EN (and IC695RCM001 redundancy module). The redundant CPU mirrors all program data and I/O states in real time, switching over in ≤5 ms if the primary unit fails. This is critical for water treatment plants, where even a 1-second CPU outage could disrupt pump control and lead to non-compliant effluent discharge.

Typical Application Scenarios

In utility-scale solar farms, the GE IC695CRU320-EN controls and monitors hundreds of solar inverters. It receives analog data (e.g., DC voltage, AC power output) from IC695ALG808-AA analog input modules, executes PID logic to optimize inverter efficiency, and transmits performance metrics to a central SCADA system via its gigabit EtherNet/IP ports. Its high I/O capacity eliminates the need for multiple CPUs, while redundancy ensures continuous operation during maintenance—maximizing energy production and minimizing revenue loss.

For municipal water treatment plants, the GE IC695CRU320-EN manages distributed pump stations and filtration systems. It processes discrete inputs (e.g., pump run status, valve position) from IC695DIA320-AA digital input modules and sends control signals to IC695ALO404-AA analog output modules (to adjust pump speed). Its RS-232 serial port connects to legacy flow meters, while EtherNet/IP enables remote monitoring by plant operators. Redundancy ensures pump control is never interrupted, preventing overflow or underflow in treatment tanks.

In automotive component manufacturing (e.g., brake caliper production), the GE IC695CRU320-EN integrates motion control for 8 CNC machines. It synchronizes machine tool movements via CIP Motion, processes feedback from laser measurement sensors, and logs production data for quality audits. Its 1.0 GHz processor handles 50+ concurrent PID loops (for temperature and pressure control), ensuring consistent part tolerances. The GE IC695CRU320-EN’s rugged design withstands the vibration and temperature fluctuations of manufacturing floors, ensuring 99.9% uptime.

Related Model Recommendations

IC695CRU310-EN: Entry-level RX3i CPU, 800 MHz processor with 16 MB flash—cost-effective alternative to GE IC695CRU320-EN for small-to-medium systems (e.g., standalone HVAC units).

IC695CHS016: 16-slot RX3i chassis, required to mount GE IC695CRU320-EN and associated I/O/communication modules in large-scale systems.

IC695PWR120: 120V AC to 5V DC power supply module, provides chassis power for GE IC695CRU320-EN and connected modules.

IC695BEM010: RX3i gigabit Ethernet module, expands GE IC695CRU320-EN’s network ports for connecting additional devices (e.g., remote I/O racks).

IC695ALG808-AA: 8-channel analog input module, sends sensor data (e.g., temperature, voltage) to GE IC695CRU320-EN for control logic execution.

IC695ALO404-AA: 4-channel analog output module, receives control signals from GE IC695CRU320-EN to drive actuators (e.g., valves, variable-speed pumps).

IC695DIA320-AA: 32-channel digital input module, collects discrete data (e.g., limit switch status) and transmits it to GE IC695CRU320-EN.

IC695RCM001: Redundancy control module, simplifies hot-standby setup for two GE IC695CRU320-EN CPUs, reducing configuration time by 40%.

IC695DO320-AA: 32-channel digital output module, acts on control commands from GE IC695CRU320-EN to activate relays or contactors.

GE IC695CRU320-EN

Installation, Commissioning and Maintenance Instructions

Installation preparation: Before installing GE IC695CRU320-EN, power off the RX3i chassis and verify the control cabinet meets environmental specs (0°C-60°C, 5%-95% non-condensing humidity). Required tools include an anti-static wristband (to prevent ESD damage), torque screwdriver (0.5-0.8 N·m for chassis screws), and Proficy Machine Edition software (for configuration). Align the GE IC695CRU320-EN with the chassis’s CPU slot (labeled “CPU”), push until it latches, and secure with front-panel screws—never hot-swap the CPU, as this may corrupt program memory or damage the backplane.

Maintenance suggestions: Daily maintenance for GE IC695CRU320-EN involves checking the “RUN/STOP” LED (steady green = normal operation, flashing red = fault) and “REDUNDANT” LED (steady green = redundancy active). Every 6 months, use compressed air (≤40 psi) to clean dust from the CPU’s vents, preventing overheating. If a fault occurs, use Proficy Machine Edition to access error logs (e.g., memory errors, Ethernet communication failures); if the CPU is unresponsive, reset it via a chassis power cycle. When replacing GE IC695CRU320-EN, transfer program data via Ethernet or USB, and verify firmware compatibility with the chassis (GE’s technical support portal provides firmware update tools and release notes).

Service and Guarantee Commitment

The GE IC695CRU320-EN comes with a 1-year manufacturer’s warranty, covering defects in materials and workmanship under normal industrial use. GE provides 24/7 technical support via phone, email, and online portals, with certified engineers specializing in RX3i systems available to assist with GE IC695CRU320-EN configuration, redundancy setup, and troubleshooting.

Beyond warranty, GE offers on-site commissioning services for GE IC695CRU320-EN, including program validation, redundancy testing, and integration checks with existing RX3i I/O/communication modules. Global service centers stock genuine spare parts, ensuring expedited replacement (typically 1-3 business days for urgent orders) to minimize downtime. GE’s quality commitment includes 100% factory testing of each GE IC695CRU320-EN—validating processor performance, I/O scalability, and redundancy switchover—to ensure it meets the strict reliability standards of industrial automation applications.
