Product Introduction

The GE IC695ETM001-GT is a high-performance Gigabit Ethernet communication module tailored for GE’s PACSystems RX3i platform, serving as a critical connectivity hub between RX3i controllers (such as the high-reliability IC695CPU330) and industrial Ethernet networks. Unlike entry-level Ethernet modules, it delivers Gigabit-speed data transfer and multi-protocol support, enabling seamless integration with a wide range of industrial devices—from modern Ethernet/IP-enabled drives to legacy Modbus TCP/IP sensors and SCADA systems.

As a key component of the PACSystems RX3i ecosystem, the GE IC695ETM001-GT integrates directly with RX3i racks (e.g., IC698CRE020CA) via the backplane, eliminating the need for external wiring for CPU communication. Its built-in MRP redundancy ensures uninterrupted operation in mission-critical applications, while the dual Gigabit ports support flexible network topologies (ring, star, daisy-chain). Whether used in large-scale manufacturing plants, power distribution facilities, or water treatment systems, the GE IC695ETM001-GT provides the speed, reliability, and compatibility needed to unify industrial communication under the PACSystems RX3i umbrella.

Core Advantages and Technical Highlights

Gigabit Ethernet speed for high-throughput data exchange: The GE IC695ETM001-GT’s dual 10/100/1000 Base-TX ports enable data transfer rates up to 1 Gbps—10x faster than 100 Mbps RX3i Ethernet modules (e.g., IC695ETM001). This speed is transformative for applications requiring large-volume data transmission, such as real-time video monitoring of production lines, high-frequency data logging from hundreds of sensors, or synchronization of multiple RX3i controllers in a distributed control system. For example, in a semiconductor manufacturing facility, the GE IC695ETM001-GT can transmit high-resolution wafer inspection data to the IC695CPU330 in milliseconds, enabling immediate quality control adjustments.

Multi-protocol support for heterogeneous system integration: The GE IC695ETM001-GT natively supports Ethernet/IP (as both adapter and scanner), Modbus TCP/IP (client/server), TCP/IP, UDP, and DNP3.0 over TCP/IP—eliminating the need for separate protocol converters. This versatility allows it to connect RX3i controllers to diverse industrial equipment: for instance, it can communicate with Allen-Bradley Ethernet/IP VFDs, Modbus TCP/IP pressure sensors, and DNP3.0-enabled power meters simultaneously. In a smart grid application, this means the GE IC695ETM001-GT can aggregate data from multiple meter types and send it to a central SCADA system via a single module—reducing system complexity and cost by up to 35%.

MRP redundancy for zero-downtime operation: The GE IC695ETM001-GT supports Media Redundancy Protocol (MRP), a ring-based redundancy standard that ensures automatic failover in less than 50 ms if a network link or port fails. Unlike non-redundant modules, this feature is critical for applications where downtime is costly or dangerous—such as nuclear power plant control, chemical batch processing, or water treatment pump stations. For example, in a wastewater treatment plant, if a primary Ethernet cable connecting the GE IC695ETM001-GT to a pump controller is damaged, the module immediately switches to the backup link, preventing pump shutdowns and avoiding untreated water overflow.

Compact design and broad environmental tolerance: Measuring just 44.5 mm wide, the GE IC695ETM001-GT saves valuable rack space in RX3i systems, allowing more I/O or communication modules to be installed in the same rack. It also operates in a wider temperature range (-20°C to 60°C) than many competing modules, making it suitable for harsh environments like outdoor power substations or cold-storage manufacturing facilities. Its IP20 rating and resistance to vibration (10 g peak) and shock (30 g peak) further ensure reliable performance in industrial settings where dust, temperature fluctuations, and mechanical stress are common.

Typical Application Scenarios

Smart manufacturing production lines: In automotive assembly plants, the GE IC695ETM001-GT acts as the communication backbone for PACSystems RX3i controllers (e.g., IC695CPU310) managing robotic arms, conveyor belts, and quality inspection systems. Its Gigabit speed enables real-time synchronization of 20+ robots via Ethernet/IP, ensuring precise coordination of welding, painting, and assembly tasks. The module’s Modbus TCP/IP support also allows it to collect data from legacy conveyor speed sensors, while MRP redundancy prevents production line stoppages if a network cable is accidentally disconnected. Engineers can access real-time production metrics (e.g., cycle time, defect rate) via a central HMI connected to the GE IC695ETM001-GT, enabling data-driven efficiency improvements.

Power distribution and smart grid management: In electrical substations, the GE IC695ETM001-GT connects PACSystems RX3i controllers to DNP3.0-enabled power meters, Ethernet/IP circuit breakers, and SCADA systems. Its Gigabit speed handles the high-volume data logging required for load balancing and energy management, while MRP redundancy ensures continuous communication with the grid operator—even if a substation experiences severe weather (e.g., thunderstorms that damage network cables). The GE IC695ETM001-GT also supports secure TCP/IP communication, encrypting data between the substation and control center to prevent cyber threats—critical for compliance with utility industry security standards (e.g., NERC CIP).

Food and beverage processing: In a beverage bottling plant, the GE IC695ETM001-GT integrates PACSystems RX3i controllers with Ethernet/IP-enabled filling machines and Modbus TCP/IP temperature sensors. Its wide operating temperature range (-20°C to 60°C) allows it to function reliably in cold-storage areas where bottles are chilled before filling, while its compact design fits in the small RX3i racks used on the production floor. The module’s UDP support enables fast transmission of machine status alerts—if a filling machine detects a jam, the GE IC695ETM001-GT sends an immediate alert to the controller, which triggers a shutdown to prevent product waste. MRP redundancy ensures that even if a network link to a sensor fails, the plant can continue operating with backup data sources.

GE IC695ETM001-GT

Related Model Recommendations

GE IC695CPU330: Mid-range PACSystems RX3i CPU module, optimized for use with the GE IC695ETM001-GT. The CPU leverages the module’s Gigabit speed and multi-protocol support to manage complex control logic and large-scale data collection.

GE IC695ETM001: 100 Mbps Ethernet module for PACSystems RX3i, a cost-effective alternative to the GE IC695ETM001-GT for applications where Gigabit speed is not required. It shares similar protocol support but with lower throughput.

GE IC698CRE020CA: 20-slot PACSystems RX3i rack, compatible with the GE IC695ETM001-GT. Provides physical space for the module alongside the CPU and I/O modules, ideal for large-scale systems.

GE IC695PWR320: High-output power supply module for RX3i racks, recommended for systems with the GE IC695ETM001-GT and other high-consumption modules. Delivers stable 5 V DC to support the module’s 1.2 A power needs.

GE IC695MDL754: 16-channel digital input/output module for RX3i, paired with the GE IC695ETM001-GT. Sends sensor data to the CPU, which then transmits aggregated data to SCADA systems via the Ethernet module.

GE IC695CMM320: Profinet communication module for RX3i, complementary to the GE IC695ETM001-GT. For systems with Profinet-enabled devices (e.g., Siemens drives), it works with the Ethernet module to unify communication protocols.

GE IC695HSC304: 4-channel high-speed counter module, generates pulse data (e.g., bottling line speed) that is stored in the CPU and transmitted to HMIs via the GE IC695ETM001-GT.

GE IC698BEM001: Backplane expansion module for RX3i, compatible with the GE IC695ETM001-GT. Extends the RX3i backplane to remote racks, allowing the Ethernet module to be installed in distant locations (e.g., outdoor substations) while maintaining communication with the CPU.

GE IC695DNP001: DNP3.0 communication module for RX3i, a supplement to the GE IC695ETM001-GT for large-scale power applications. Adds advanced DNP3.0 features (e.g., event logging) that complement the module’s existing DNP3.0 support.

GE IC695SEC001: Security module for RX3i, paired with the GE IC695ETM001-GT to enhance data security. Provides firewall protection and secure VPN connectivity for Ethernet communication, critical for cyber-sensitive applications like smart grids.

Installation, Commissioning and Maintenance Instructions

Installation preparation: Before installing the GE IC695ETM001-GT, power off the PACSystems RX3i rack (e.g., IC698CRE020CA) and wear an anti-static wristband to prevent damage to internal components. Ensure the rack has an available slot (slots 2-20, as slot 1 is typically reserved for the CPU) and is powered by a compatible supply (e.g., GE IC695PWR320) to support the module’s 1.2 A power consumption. Gather tools: a screwdriver (to secure the module to the rack), a torque wrench (to tighten rack screws to 3.5 N·m), Cat6a Ethernet cables (required for Gigabit speed), and a PC with GE Proficy Machine Edition software (v9.5+ recommended for full feature support). Verify the environment meets the module’s specs: -20°C to 60°C, 5%-95% humidity (non-condensing), and no direct exposure to liquids or excessive dust.

Commissioning steps:

Align the GE IC695ETM001-GT with the rack slot, ensuring the backplane connector is properly positioned, and slide the module into place. Secure it with screws using the torque wrench (3.5 N·m) to prevent loose connections.

Power on the rack and confirm the module’s LEDs: green (power), blue (backplane communication with the CPU, e.g., IC695CPU330), solid green (Ethernet port link), and blinking amber (port activity). A red LED indicates a fault (e.g., MRP configuration error).

Connect the PC to one of the module’s Ethernet ports via a Cat6a cable, launch Proficy Machine Edition, and detect the GE IC695ETM001-GT using the software’s “Module Discovery” tool.

Configure settings: Assign a static IP address compatible with the plant’s network, enable MRP (if using a ring topology) and select protocols (e.g., Ethernet/IP Scanner, Modbus TCP/IP Server). Map device data to the CPU’s memory (e.g., link a pressure sensor’s Modbus register to the CPU’s Input Register 40001).

Test communication: Connect Ethernet devices (e.g., VFDs, sensors) to the module’s ports, send a test command from the CPU to a device (e.g., “set VFD speed to 50 Hz”), and verify the GE IC695ETM001-GT forwards the command and returns a confirmation within 1 ms. Test MRP by disconnecting a primary link and confirming failover to the backup within 50 ms.

Maintenance suggestions:

Daily: Inspect LEDs—green power, blue backplane, solid green port links, and blinking amber activity indicate normal operation. A red fault LED signals issues (e.g., port failure, MRP ring break) that require immediate attention.

Weekly: Clean the module’s Ethernet ports and backplane connector with a dry, lint-free cloth to remove dust (prevents Gigabit speed degradation). Check Cat6a cables for damage (e.g., bent pins) and replace if necessary.

Monthly: Use Proficy Machine Edition to run a diagnostic scan on the GE IC695ETM001-GT—check for protocol errors, packet loss, and redundancy status. Back up the module’s configuration to a secure PC to ensure quick recovery if the module fails.

Quarterly: Test MRP redundancy by intentionally breaking the network ring and verifying failover time with a network analyzer (should be < 50 ms). Update the module’s firmware via GE’s support portal—ensure compatibility with the CPU’s firmware and connected devices.

Annually: Inspect the module for physical damage (e.g., corrosion on connectors) and verify environmental compliance (e.g., temperature, humidity) with a data logger. For outdoor or harsh environments, check the module’s IP20 protection by removing dust from vents and ensuring no moisture has entered the housing.

Service and Guarantee Commitment

The GE IC695ETM001-GT is backed by a 3-year standard manufacturer’s warranty from GE Industrial Solutions, covering defects in materials, workmanship, and performance (including MRP redundancy and Gigabit speed functionality) under normal industrial use. During the warranty period, if the module fails to meet published technical specifications (e.g., data transfer rate below 1 Gbps, MRP failover exceeding 50 ms, port malfunctions), GE will repair or replace it free of charge, including expedited shipping for critical applications (e.g., power plants, manufacturing lines with zero downtime tolerance).

Beyond warranty, GE offers specialized support for the GE IC695ETM001-GT:

24/7 technical assistance: Certified engineers with expertise in PACSystems RX3i Ethernet communication are available via phone and email to help with MRP configuration, protocol troubleshooting, and network optimization. For urgent issues (e.g., unexpected module failure in a live production line), engineers provide remote diagnostic support within 1 hour.
