GE IC697BEM731U

Product Introduction

The GE IC697BEM731U is a cost-optimized Ethernet communication module in GE’s Series 90-70 PLC family, designed to serve as a reliable “network bridge” for mid-sized industrial automation systems. Unlike high-end modules like the GE IC697BEM733D, the GE IC697BEM731U focuses on essential communication functions, making it ideal for applications that don’t require gigabit speed or PROFINET support—without compromising on GE’s industrial-grade reliability.

Technical positioning for cost-sensitive, low-to-moderate complexity projects (e.g., small manufacturing lines, regional water treatment plants), the GE IC697BEM731U enables seamless data exchange between Series 90-70 controllers and key devices: EtherNet/IP-enabled HMIs, Modbus TCP/IP-based sensors, and SRTP-connected remote I/O racks. In automation architectures, the GE IC697BEM731U acts as a “simplified data hub,” ensuring critical control data flows reliably while keeping hardware costs in check—perfect for businesses scaling their automation without overinvesting in unneeded features.

Core Advantages and Technical Highlights

Essential protocol coverage: The GE IC697BEM731U natively supports three high-demand industrial protocols (EtherNet/IP, Modbus TCP/IP, GE SRTP), eliminating the need for external converters in most mid-sized systems. For example, in a packaging plant, it can connect a IC697CPU770 PLC to EtherNet/IP HMIs (for operator control) and Modbus TCP/IP weigh scales (for product dosing)—all via a single GE IC697BEM731U. This balances functionality with cost, avoiding the premium for unused protocols like PROFINET.

Cost-optimized design: Built for budget-conscious projects, the GE IC697BEM731U reduces upfront costs by focusing on core features (10/100 Mbps ports, 128-node capacity) while retaining GE’s rugged industrial build. It consumes 33% less power than the GE IC697BEM733D (200mA vs. 300mA), lowering long-term energy costs—especially in systems with multiple modules. For small-scale manufacturers, this means accessing Series 90-70’s reliability without stretching capital budgets.

Seamless Series 90-70 integration: Like all Series 90-70 modules, the GE IC697BEM731U leverages the platform’s high-speed backplane (up to 160 Mbps) for low-latency data exchange with the PLC CPU. It draws power directly from the chassis, eliminating external power supplies and reducing cable clutter. Configuration is simplified via GE’s Proficy Machine Edition software, with pre-built templates for EtherNet/IP and Modbus TCP/IP—cutting setup time by 25% compared to generic third-party modules.

Reliable industrial durability: The GE IC697BEM731U retains the Series 90-70’s rugged credentials, with a wide operating temperature range (0°C-60°C) and resistance to vibration (5 g peak) and shock (30 g peak). It meets EMC compliance (EN 61000-6-2) to shield against electrical noise from nearby motors or VFDs—ensuring stable communication in noisy environments like plastic injection molding facilities.

Typical Application Scenarios

In small-to-mid-sized manufacturing (e.g., plastic bottle production lines), the GE IC697BEM731U connects a IC697CPU760 PLC to critical devices: EtherNet/IP-based conveyor controllers (for line speed adjustment) and Modbus TCP/IP pressure sensors (for monitoring injection molding machines). Its 10/100 Mbps ports provide ample bandwidth for real-time data transfer, while its cost-effectiveness allows the plant to deploy multiple modules across three production lines without exceeding budget.

For regional water treatment plants, the GE IC697BEM731U enables distributed monitoring of pump stations. It links Series 90-70 PLCs at remote sites to a central SCADA system via Modbus TCP/IP, transmitting flow rate and pressure data. The module’s rugged design withstands the humid, dusty conditions of pump houses, while basic STP redundancy prevents communication drops during network maintenance—ensuring compliance with local water quality regulations.

In food processing (e.g., bakery production), the GE IC697BEM731U integrates with SRTP-connected temperature controllers (monitoring oven temperatures) and EtherNet/IP HMIs (for operator recipe adjustments). Its 128-node capacity supports up to 10 ovens and 5 HMIs per module, while its low power consumption aligns with the plant’s energy efficiency goals. Unlike more complex modules, the GE IC697BEM731U’s simplified feature set reduces training needs for on-site technicians.
