GE IC697PWR710F

Description

Detailed Parameter Table

GE IC697PWR710F

Product Introduction

The GE IC697PWR710F is an entry-level standard-capacity power supply module in GE’s Series 90-70 PLC family, designed to serve as the “cost-effective energy foundation” for small-to-medium industrial automation systems. Unlike mid-high capacity models (e.g., IC697PWR720 with 15 A output) or high-end IC697PWR748 (20 A), the GE IC697PWR710F delivers 10 A continuous current—ideal for powering 6-slot to 8-slot Series 90-70 chassis (e.g., IC697CHS730) with basic-to-mid modules: 1 × IC697CPU770 CPU, 2–3 × IC697ALG320 analog I/O modules, 1 × IC697BEM731U Ethernet module, and 1 × IC697DIA310 digital input module.

Technical positioning for industries like small chemical workshops, local water treatment stations, and low-volume electronic component assembly lines, the GE IC697PWR710F features a universal input (85–264 V AC/120–370 V DC) to adapt to global power grids and minor voltage fluctuations (e.g., brownouts in rural areas). It converts unstable line power into regulated 5 V DC, ensuring basic modules avoid crashes caused by underpower or voltage spikes. In automation architectures, the GE IC697PWR710F acts as a “budget-friendly power hub”—meeting the core needs of small systems without paying for unused high capacity (15 A/20 A)—making it the first choice for Series 90-70 deployments with limited budgets and moderate power demands.

Core Advantages and Technical Highlights

10 A Standard Capacity for Small-Mid Systems: The GE IC697PWR710F’s 10 A continuous output is perfectly matched to small chassis like the 6-slot IC697CHS730. For a local water treatment station using 1 × IC697CPU770 CPU, 2 × IC697ALG320 flow/turbidity modules, and 1 × IC697BEM731U communication module, this capacity eliminates the need for two low-power supplies (saving 1 chassis slot) while avoiding the premium cost of IC697PWR720—reducing total hardware costs by 30%.

Universal Input for Global Adaptability: With 85–264 V AC/120–370 V DC input, the GE IC697PWR710F works seamlessly in diverse regions—from 110 V AC (North American small factories) to 230 V AC (European workshops) or DC grids (remote solar-powered pump stations). A multinational electronic component manufacturer, for example, can standardize on GE IC697PWR710F across global low-volume lines, simplifying inventory management and reducing technician training costs.

Basic but Reliable Protection: The GE IC697PWR710F includes essential protection features: overload protection trips at 120% load (12 A) to prevent overheating, short-circuit crowbar protection instantly shuts down output if a wire is grounded, and 70°C over-temperature shutdown safeguards components. For a small plastic injection workshop using IC697ALG320 temperature modules, this protection prevents expensive I/O modules from being damaged by power anomalies—cutting replacement costs by 40% compared to unprotected generic supplies.

Easy Integration with Series 90-70 Ecosystem: The GE IC697PWR710F shares the same mounting interface and wiring standard as other Series 90-70 power supplies (e.g., IC697PWR720). Technicians familiar with Series 90-70 can install it in 5 minutes—no need to modify chassis or learn new wiring methods. It also supports N+1 redundancy with the IC697PWRRED adapter, allowing critical small systems (e.g., pharmaceutical small-batch lines) to upgrade to fault tolerance without replacing the power supply model.

Typical Application Scenarios

In small plastic injection workshops, the GE IC697PWR710F powers a 6-slot IC697CHS730 chassis housing 1 × IC697CPU770 CPU, 2 × IC697ALG320 barrel temperature modules, 1 × IC697DO310 digital output module (controlling injection valves), and 1 × IC697BEM731U Ethernet module (linking to a local HMI). Its 10 A capacity ensures stable power for all modules, while overload protection prevents shutdowns during valve startup—avoiding defective plastic parts and $5,000+ in daily production losses.

For local water treatment stations (serving 3,000–8,000 residents), the GE IC697PWR710F supplies power to an 8-slot IC697CHS750 chassis with 1 × IC697CPU770 CPU, 3 × IC697ALG320 (monitoring flow, turbidity, chlorine levels), 1 × IC697DIA310 (pump status), and 1 × IC697BEM731U (transmitting data to regional SCADA). Its universal input adapts to the station’s 230 V AC grid, while 4 kV surge protection shields against thunderstorm-induced grid spikes—ensuring uninterrupted water treatment and compliance with local environmental standards.

In low-volume electronic component assembly lines (e.g., PCB soldering), the GE IC697PWR710F powers a 6-slot IC697CHS730 chassis with 1 × IC697CPU770 CPU, 3 × IC697DIA310 (part presence, soldering machine status), 1 × IC697ALG320 (soldering temperature), and 1 × IC697BEM731U (quality log upload). Its 12 A peak current handles startup surges from soldering irons, while regulated 5 V DC ensures temperature modules maintain ±0.5°C accuracy—reducing PCB defect rates by 25%.

Related Model Recommendations

IC697PWR720: Mid-capacity 15 A power supply—upgrade option for GE IC697PWR710F when scaling to 12-slot chassis (e.g., IC697CHS770) with 8+ high-power modules.

IC697CHS730: 6-slot Series 90-70 chassis—primary compatible chassis for GE IC697PWR710F in small systems (e.g., local pump stations).

IC697CPU770: Mid-entry Series 90-70 CPU—optimized pairing with GE IC697PWR710F for small-scale control (e.g., plastic injection, water treatment).

IC697PWRRED: Redundancy adapter—enables N+1 redundancy for two GE IC697PWR710F units in critical small systems (e.g., pharmaceutical small-batch lines).

IC697BEM731U: Entry-level Ethernet module—low-power communication module ideally powered by GE IC697PWR710F in small chassis.

IC697ALG320: 4-channel analog input module—basic I/O module paired with GE IC697PWR710F for process monitoring (temperature, pressure).

IC697CHS750: 8-slot Series 90-70 chassis—compatible with GE IC697PWR710F for medium-small systems (e.g., electronic component assembly).

IC697DO310: 16-channel digital output module—low-power output module for GE IC697PWR710F-powered systems (valve control, conveyor drives).

GE IC697PWR710F

Installation, Commissioning and Maintenance Instructions

Installation preparation: Before installing GE IC697PWR710F, power off the Series 90-70 chassis (e.g., IC697CHS730) and verify input power matches the facility’s grid (85–264 V AC/120–370 V DC). Required tools include a torque screwdriver (0.8–1.2 N·m for chassis screws), wire strippers (18–14 AWG for input wires), a multimeter (to test input voltage), and an anti-static wristband (prevent ESD damage to modules). Ensure the chassis’s “PWR” slot is free of dust and debris.

Installation and maintenance: Align GE IC697PWR710F with the chassis’s power slot, push firmly until it latches, and secure with front-panel screws (torque to 1.0 N·m). Connect input wires: for AC, attach L (line), N (neutral), and GND (ground); for DC, attach + (positive) and – (negative). Tighten terminal screws to 0.5 N·m to avoid arcing. Daily maintenance involves checking the “PWR OK” LED (steady green = normal, red = fault). Every 6 months, use compressed air (≤50 psi) to clean dust from vents—accumulated dust reduces efficiency by 5–10%. If the red fault LED activates, first test input voltage with a multimeter; if voltage is normal, replace the module (ensure firmware matches the chassis).

Service and Guarantee Commitment

The GE IC697PWR710F comes with a 1-year manufacturer’s warranty—standard for entry-level Series 90-70 power supplies—covering defects in materials (e.g., transformers, surge protection components) and workmanship under industrial use. GE provides 24/7 technical support via phone, email, and online portals, with certified engineers specializing in Series 90-70 power systems available to assist with GE IC697PWR710F installation, redundancy setup, and fault diagnosis.

Beyond warranty, GE offers on-site service for GE IC697PWR710F, including power load testing, redundancy validation, and compatibility checks with Series 90-70 chassis/modules. Global service centers stock genuine spare parts, ensuring expedited replacement (typically 2–3 business days for urgent orders) to minimize downtime in small-scale systems. GE’s quality commitment includes 100% factory testing of each GE IC697PWR710F—validating output regulation, protection functions, and efficiency—to meet the reliability standards of small manufacturing, water treatment, and electronic assembly industries.
