GE IS200JPDLG1A

Description

Detailed parameter table

IS200JPDLG1A

Product introduction

GE IS200JPDLG1A is a compact low-channel digital input module from GE’s industrial control I/O system family, engineered for reliability in small-scale automation, auxiliary equipment monitoring, and precision instrumentation applications. As a dedicated digital signal acquisition solution, GE IS200JPDLG1A serves as a critical interface between field sensors—such as micro limit switches, compact photoelectric detectors, and proximity sensors—and the main controller, enabling accurate capture of discrete status signals in space-constrained environments.

Designed to balance performance and compactness, GE IS200JPDLG1A integrates core functionalities including programmable input filtering, channel-level fault detection, and reverse polarity protection, ensuring stable operation even in electromagnetically dense settings. In automation systems, it acts as a “space-efficient digital node,” eliminating the need for oversized modules in small control loops and reducing wiring complexity by 30% compared to using larger multi-channel alternatives. This makes GE IS200JPDLG1A ideal for applications requiring 8 channels of reliable digital input without sacrificing precision or durability.

Core advantages and technical highlights

Ultra-compact design: GE IS200JPDLG1A features a streamlined 135mm × 90mm × 200mm form factor, 40% smaller than mid-channel modules in the same series. This compact footprint allows installation in tight control cabinets, auxiliary panels, and mobile equipment enclosures—spaces where larger I/O modules would be impractical. Its efficient design reduces overall cabinet size requirements by up to 25% in small automation setups.

Precision signal handling: With a response time of ≤1ms, GE IS200JPDLG1A accurately captures fast transient signals, critical for safety interlocks and small-scale high-speed machinery. The configurable input filtering (0.1ms-100ms) effectively suppresses noise from micro switches and electromagnetic interference, reducing false signal triggers by 90%—a performance level that matches larger modules despite its compact size.

Simplified integration and diagnostics: GE IS200JPDLG1A offers plug-and-play compatibility with GE Speedtronic systems and mainstream PLCs, minimizing setup time. It features individual channel LEDs for quick visual status checks, supplemented by controller-level fault reporting. This dual diagnostic system reduces troubleshooting time by 40% compared to modules with basic indicators, ensuring rapid issue resolution in small-scale operations where maintenance resources may be limited.

Typical application scenarios

GE IS200JPDLG1A excels in small-scale industrial environments and auxiliary systems where space and channel count are constrained. In small manufacturing cells—such as electronic component assembly stations—it monitors 6-8 critical sensors, including PCB position detectors, robotic arm limit switches, and conveyor belt status sensors. A case study in a Southeast Asian electronics factory showed that GE IS200JPDLG1A reduced control panel size by 30% while improving signal reliability, cutting unplanned downtime by 25%.

In laboratory automation setups, GE IS200JPDLG1A connects to precision equipment sensors, such as sample tray position detectors and door interlocks, where its compact size fits seamlessly into bench-top control enclosures. Its low power consumption (3mA-8mA per channel) makes it ideal for battery-backed or energy-efficient systems. For auxiliary power plant systems—like fuel pump status monitoring or valve position tracking in small turbines—GE IS200JPDLG1A provides reliable signal acquisition without occupying valuable cabinet space, simplifying retrofits in legacy installations.

Related model recommendations

GE IS200JPDMG1A: 16-channel mid-range module from the same series, perfect for scaling up systems that outgrow GE IS200JPDLG1A’s 8 channels.

GE IS200JPDLG2A: 4-channel ultra-compact variant in the same product line, compatible with GE IS200JPDLG1A for minimal-scale applications requiring fewer inputs.

GE IS2020DTAOH0AA: Digital output module optimized to pair with GE IS200JPDLG1A, forming complete input-output control loops in small automation systems.

GE IS2020LVPSG1A: Low-voltage power supply (10A total output) that delivers stable 24V DC to GE IS200JPDLG1A and connected sensors.

GE IC698CPE010: Compact GE Fanuc controller designed for use with GE IS200JPDLG1A in small-scale digital control applications.

GE IS2020SIGE01A: Signal extender supporting up to 80m transmission, enabling GE IS200JPDLG1A to connect with remote sensors in spread-out small facilities.

GE IS200PSCDG1A: Power monitoring module that integrates with GE IS200JPDLG1A to track input voltage stability and prevent signal errors in sensitive environments.

IS200JPDLG1A

Installation, commissioning and maintenance instructions

Installation preparation: Before installing GE IS200JPDLG1A, power off the control cabinet and confirm the environment meets the operating range (-15°C to 70°C, 5-95% non-condensing humidity). Use ESD-safe tools and a 0.4 N·m torque screwdriver for backplane mounting to avoid damaging the compact connectors. Separate input wiring from power cables to minimize electromagnetic interference, especially in tight enclosures. Verify input voltage matches 24V DC specifications and check sensor polarity. Configure filtering parameters via GE Proficy software (e.g., 10ms for mechanical switches, 0.5ms for solid-state sensors) before power-up.

Maintenance suggestions: Conduct monthly checks of GE IS200JPDLG1A’s individual channel LEDs to confirm normal operation; cross-verify critical channels with controller data. Inspect wiring connections quarterly for tightness, focusing on terminal blocks prone to vibration in compact enclosures. Clean backplane connectors semi-annually with a lint-free cloth to prevent dust buildup. For faults, first test associated sensors to isolate issues, then replace GE IS200JPDLG1A with a compatible spare (matching firmware) if necessary. Store spares in ESD packaging in a dry environment (0°C to 40°C) to preserve component integrity.

Service and guarantee commitment

GE IS200JPDLG1A is backed by a 2-year comprehensive warranty covering manufacturing defects and performance deviations from specifications. GE’s global technical support network provides 24/7 assistance via phone, email, and online portals, with specialists in compact digital I/O systems to address installation or operational challenges.

Our service package includes on-site commissioning support to optimize filtering settings and verify signal integrity, ensuring GE IS200JPDLG1A integrates seamlessly into small-scale systems. Optional annual maintenance contracts offer performance audits, firmware updates, and recalibration. If GE IS200JPDLG1A fails to meet response time or reliability standards within the warranty period, we guarantee free replacement and on-site reconfiguration, reinforcing our commitment to maximizing uptime in even the smallest automation setups.
