GE IS215VPROH1BD

Description

Detailed Parameter Table

GE IS215VPROH1BD

Product Introduction

The **GE IS215VPROH1BD** is a reliable industrial communication processing module under GE’s classic Mark VI control system series, specifically engineered to realize protocol conversion, data processing, and seamless communication between Mark VI controllers, distributed I/O modules, and upper-level industrial networks. As a key communication hub in medium-scale automation systems, it serves as the bridge connecting the field control layer and the supervisory layer, enabling efficient data interaction and centralized management for dual-protocol industrial environments.

In industrial scenarios requiring dual-system integration, the **GE IS215VPROH1BD** excels in processing moderate-volume real-time data while supporting two mainstream industrial Ethernet protocols. Its stable data processing capacity ensures smooth transmission of control commands and field data, even in environments with moderate I/O points and standard network topologies. By providing flexible dual-protocol conversion and reliable communication, the **GE IS215VPROH1BD** lays a solid foundation for system integration, remote monitoring, and intelligent management in medium-sized power generation, petrochemicals, and manufacturing industries.

Core advantages and technical highlights

Dual-Protocol Conversion & Compatibility: The **GE IS215VPROH1BD** natively supports Modbus TCP and Ethernet/IP—two of the most widely used industrial Ethernet protocols. It can realize bidirectional protocol conversion between different networks, for example, converting Mark VI controller data from Ethernet/IP to Modbus TCP for transmission to third-party SCADA systems, or receiving Modbus TCP commands from external devices and converting them to Ethernet/IP for Mark VI I/O modules. This dual-protocol capability eliminates the need for additional protocol converters, simplifying system architecture.

Stable Data Processing & Basic Expansion: With a data processing capacity of up to 5,000 data points per second, the **GE IS215VPROH1BD** can efficiently handle moderate-volume real-time data from distributed I/O modules. Equipped with 2 x 10/100/1000 Mbps Ethernet ports, it supports basic network redundancy configuration—one port for connecting to the control network and the other for the monitoring network, enhancing network reliability in medium-scale applications.

Robust Communication & Anti-Interference: Featuring a 2kVrms isolation rating between Ethernet ports and the backplane, the **GE IS215VPROH1BD** effectively suppresses electrical noise, ground loops, and voltage transients common in industrial sites. It complies with IEC 61000-4 EMC standards, ensuring stable communication near high-power equipment such as motors and inverters. The built-in network fault detection function can quickly identify port disconnection and data packet loss, triggering alarms to facilitate timely troubleshooting.

Seamless Mark VI Integration & Easy Configuration: The **GE IS215VPROH1BD** is fully compatible with the Mark VI control system chassis, supporting hot-swapping for quick module replacement without system shutdown. It can be configured via GE’s Proficy Machine Edition software, which provides an intuitive graphical interface for protocol setting, data mapping, and network parameter configuration. The module supports auto-discovery by Mark VI controllers and upper-level systems, significantly reducing commissioning time.

Typical application scenarios

In medium-scale biomass power plants, the **GE IS215VPROH1BD** is deployed as the communication core of the Mark VI distributed control system. It connects Mark VI controllers (controlling boilers and generators) via the backplane, and communicates with third-party SIS (Safety Instrumented System) through different protocols. For example, it transmits real-time boiler parameter data from Ethernet/IP to the SIS via Modbus TCP, and receives production scheduling commands from the upper-level system via Ethernet/IP, realizing integrated management of the power plant production process.

In medium-sized chemical plants, the **GE IS215VPROH1BD** is used to integrate distributed I/O systems. It connects **GE IS220UCSAH1A** analog input modules (monitoring reactor pressure/temperature) and **GE IS220YDIAS1A** digital input modules (monitoring valve status) via the Mark VI backplane, and converts the collected field data into Ethernet/IP signals for transmission to the central SCADA system. At the same time, it receives control commands from the SCADA system and converts them to Modbus TCP for下发 to third-party pumps, ensuring coordinated operation of the entire chemical production process. Its dual-port design enables simultaneous connection to the control network and the monitoring network, enhancing system stability.

Related model recommendations

**GE IS220UCSAH1A**: A Mark VI analog input module that collects field analog data and transmits it to the **GE IS215VPROH1BD** for protocol conversion and network transmission.

**GE IS220YDIAS1A**: A Mark VI digital input module that provides discrete status signals for the **GE IS215VPROH1BD** to process and upload.

**GE IS215VPROH2B**: An upgraded version of the **GE IS215VPROH1BD** with 4 Ethernet ports and higher data processing capacity (10,000 data points/sec), designed for large-scale network integration.

**GE IS220PBIH1A**: A Mark VI terminal board that provides wiring interfaces for I/O modules connected to the **GE IS215VPROH1BD**-based system.

**GE IS220PCAAH1A**: A Mark VI power supply module that provides stable 24V DC power to the **GE IS215VPROH1BD** and associated I/O modules.

**GE IS220TCICH1A**: A Mark VI single-protocol communication module that complements the **GE IS215VPROH1BD** in single-protocol sub-network scenarios.

**GE IS220TRLYH1B**: A Mark VI digital output module that executes control commands下发 by the **GE IS215VPROH1BD** after protocol conversion.

GE IS215VPROH1BD

Installation, commissioning and maintenance instructions

Installation preparation: Before installing the **GE IS215VPROH1BD**, power off the Mark VI chassis and verify slot compatibility. Required tools include a Phillips screwdriver, ESD wristband, and network tester. Clean the module and chassis slot to remove dust or debris. Align the module with the chassis guide rails, insert firmly until it clicks into place, and fasten the front-panel screws. Use CAT5e or higher-grade shielded Ethernet cables to connect the module’s ports to networks or devices, ensuring cable length does not exceed 100 meters. Configure network parameters (IP address, subnet mask) and protocol conversion rules via Proficy Machine Edition software before powering on the system.

Maintenance suggestions: Conduct monthly visual inspections of the **GE IS215VPROH1BD** to check Ethernet port LED status (link/activity) and secure cable connections. Use a network tester quarterly to verify communication speed, packet loss rate, and protocol conversion functionality. Clean the module surface and chassis slot every six months using compressed air (max pressure 0.5MPa) to remove dust buildup. In case of communication failures, first check network cables and switches, then use Proficy Machine Edition to view module diagnostic logs. Replace damaged modules with genuine GE spares to ensure compatibility and network stability.

Service and guarantee commitment

The **GE IS215VPROH1BD** comes with a 12-month manufacturer’s warranty covering material and workmanship defects. GE’s global technical support team provides 24/7 assistance via email, online portals, and phone, offering network configuration guides, protocol conversion solutions, and troubleshooting advice. For on-site service needs, certified GE engineers specializing in industrial communication can be dispatched to customer locations within 48 hours in major industrial regions. Extended warranty plans up to 3 years and customized network integration design services are available to maximize the module’s operational lifespan. GE is committed to delivering high-reliability, flexible communication processing modules to support customers’ medium-scale industrial system integration requirements.
