GE IS215VPROH2B

Description

Detailed Parameter Table

GE IS215VPROH2B

Product Introduction

The **GE IS215VPROH2B** is a high-performance industrial communication processing module under GE’s classic Mark VI control system series, specifically engineered to realize protocol conversion, data processing, and seamless communication between Mark VI controllers, distributed I/O modules, and upper-level industrial networks. As a core communication hub in complex automation systems, it serves as the bridge connecting the field control layer and the supervisory layer, enabling efficient data interaction and centralized management for multi-protocol industrial environments.

In industrial scenarios requiring multi-system integration, the **GE IS215VPROH2B** excels in processing large-volume real-time data while supporting multiple mainstream industrial Ethernet protocols. Its high data processing capacity ensures smooth transmission of control commands and field data, even in environments with dense I/O points and complex network topologies. By providing flexible protocol conversion and reliable communication, the **GE IS215VPROH2B** lays a solid foundation for system integration, remote monitoring, and intelligent management in power generation, petrochemicals, and heavy manufacturing industries.

Core advantages and technical highlights

Multi-Protocol Conversion & Compatibility: The **GE IS215VPROH2B** natively supports Modbus TCP, Ethernet/IP, and PROFINET—three of the most widely used industrial Ethernet protocols. It can realize bidirectional protocol conversion between different networks, for example, converting Mark VI controller data from Ethernet/IP to Modbus TCP for transmission to third-party SCADA systems, or receiving PROFINET commands from Siemens PLCs and converting them to Ethernet/IP for Mark VI I/O modules. This multi-protocol capability eliminates the need for additional protocol converters, simplifying system architecture.

High-Speed Data Processing & Expansion: With a data processing capacity of up to 10,000 data points per second, the **GE IS215VPROH2B** can efficiently handle large-volume real-time data from distributed I/O modules. Equipped with 4 x 10/100/1000 Mbps Ethernet ports, it supports network expansion and redundancy configuration—two ports can be used for connecting to different networks (e.g., control network and monitoring network), and the other two for device cascading, enhancing network flexibility and reliability.

Robust Communication & Anti-Interference: Featuring a 2kVrms isolation rating between Ethernet ports and the backplane, the **GE IS215VPROH2B** effectively suppresses electrical noise, ground loops, and voltage transients common in industrial sites. It complies with IEC 61000-4 EMC standards, ensuring stable communication near high-power equipment such as motors and inverters. The built-in network fault detection function can quickly identify port disconnection and data packet loss, triggering alarms to facilitate timely troubleshooting.

Seamless Mark VI Integration & Easy Configuration: The **GE IS215VPROH2B** is fully compatible with the Mark VI control system chassis, supporting hot-swapping for quick module replacement without system shutdown. It can be configured via GE’s Proficy Machine Edition software, which provides an intuitive graphical interface for protocol setting, data mapping, and network parameter configuration. The module supports auto-discovery by Mark VI controllers and upper-level systems, significantly reducing commissioning time.

Typical application scenarios

In large-scale coal-fired power plants, the **GE IS215VPROH2B** is deployed as the communication core of the Mark VI distributed control system. It connects Mark VI controllers (controlling boilers, turbines, and generators) via the backplane, and communicates with third-party equipment such as SIS (Safety Instrumented System) and MES (Manufacturing Execution System) through different protocols. For example, it transmits real-time turbine parameter data from Ethernet/IP to the SIS via Modbus TCP, and receives production scheduling commands from the MES via PROFINET, realizing integrated management of the entire power plant production process.

In petrochemical refineries, the **GE IS215VPROH2B** is used to integrate multiple distributed I/O systems. It connects **GE IS220UCSAH1A** analog input modules (monitoring pipeline pressure/temperature) and **GE IS220YDIAS1A** digital input modules (monitoring valve status) via the Mark VI backplane, and converts the collected field data into Ethernet/IP signals for transmission to the central SCADA system. At the same time, it receives control commands from the SCADA system and converts them to Modbus TCP for下发 to third-party intelligent valves, ensuring coordinated operation of the entire refining process. Its multi-port design enables simultaneous connection to the control network and the safety network, enhancing system security.

Related model recommendations

**GE IS220UCSAH1A**: A Mark VI analog input module that collects field analog data and transmits it to the **GE IS215VPROH2B** for protocol conversion and network transmission.

**GE IS220YDIAS1A**: A Mark VI digital input module that provides discrete status signals for the **GE IS215VPROH2B** to process and upload.

**GE IS215VPROH3B**: An upgraded version of the **GE IS215VPROH2B** with 6 Ethernet ports and higher data processing capacity (20,000 data points/sec), designed for large-scale network integration.

**GE IS220PBIH1A**: A Mark VI terminal board that provides wiring interfaces for I/O modules connected to the **GE IS215VPROH2B**-based system.

**GE IS220PCAAH1A**: A Mark VI power supply module that provides stable 24V DC power to the **GE IS215VPROH2B** and associated I/O modules.

**GE IS220TCICH1A**: A Mark VI single-protocol communication module that complements the **GE IS215VPROH2B** in single-protocol sub-network scenarios.

**GE IS220TRLYH1B**: A Mark VI digital output module that executes control commands下发 by the **GE IS215VPROH2B** after protocol conversion.

GE IS215VPROH2B

Installation, commissioning and maintenance instructions

Installation preparation: Before installing the **GE IS215VPROH2B**, power off the Mark VI chassis and verify slot compatibility. Required tools include a Phillips screwdriver, ESD wristband, and network tester. Clean the module and chassis slot to remove dust or debris. Align the module with the chassis guide rails, insert firmly until it clicks into place, and fasten the front-panel screws. Use CAT5e or higher-grade shielded Ethernet cables to connect the module’s ports to networks or devices, ensuring cable length does not exceed 100 meters. Configure network parameters (IP address, subnet mask) and protocol conversion rules via Proficy Machine Edition software before powering on the system.

Maintenance suggestions: Conduct monthly visual inspections of the **GE IS215VPROH2B** to check Ethernet port LED status (link/activity) and secure cable connections. Use a network tester quarterly to verify communication speed, packet loss rate, and protocol conversion functionality. Clean the module surface and chassis slot every six months using compressed air (max pressure 0.5MPa) to remove dust buildup. In case of communication failures, first check network cables and switches, then use Proficy Machine Edition to view module diagnostic logs. Replace damaged modules with genuine GE spares to ensure compatibility and network stability.

Service and guarantee commitment

The **GE IS215VPROH2B** comes with a 12-month manufacturer’s warranty covering material and workmanship defects. GE’s global technical support team provides 24/7 assistance via email, online portals, and phone, offering network configuration guides, protocol conversion solutions, and troubleshooting advice. For on-site service needs, certified GE engineers specializing in industrial communication can be dispatched to customer locations within 48 hours in major industrial regions. Extended warranty plans up to 3 years and customized network integration design services are available to maximize the module’s operational lifespan. GE is committed to delivering high-reliability, flexible communication processing modules to support customers’ complex industrial system integration requirements.
