GE IS220UCSAH1A | Mark VIe Series Embedded Controller for Gas/Steam Turbine Control

  • Brand: GE (General Electric)
  • Model: IS220UCSAH1A (Variant of Mark VIe Series)
  • Product Type: Embedded Controller Module (UCSA Acoustic Monitor Processor)
  • Series: Mark VIe (Gas/Steam Turbine Control Systems)
  • Core Function: Serves as the central processing unit​ for GE Mark VIe turbine control systems, executing real-time control algorithms, managing communication with I/O modules and external devices, and ensuring reliable operation in industrial environments. Designed for high performance and scalability in mission-critical applications (e.g., power generation, oil & gas).
  • Key Specs:
    • Processor: Freescale PowerPC 8349 (667 MHz, robust performance for complex control logic)
    • Operating System: QNX Neutrino RTOS (preemptive multitasking, real-time response)
    • Memory: 256 MB DDR SDRAM (runtime data storage) + 512 MB NAND Flash (firmware/application storage)
    • Communication: 6× Ethernet (RJ45, IONet protocol) + 1× USB (configuration/maintenance)
    • Power Supply: 18–36 V DC (12 W typical, redundant power support)
    • Operating Temperature: 0°C to +65°C (industrial-grade, fanless design)
Get a Quote
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.

Description

IS220UCSAH1A: Product Overview​
The GE IS220UCSAH1A​ is an embedded controller module​ from GE’s Mark VIe series, a legacy platform renowned for its reliability in industrial automation. As the “brain” of Mark VIe systems, it executes user-defined control logic (e.g., turbine speed control, valve positioning), manages communication with I/O modules (e.g., digital inputs/outputs, analog modules) and external devices (e.g., HMIs, SCADA systems), and ensures system uptime through robust design—critical for applications where process stability is paramount (e.g., power plants, refineries).
Role in Automation Systems:
Positioned as the core control module​ in Mark VIe architectures, the IS220UCSAH1A performs three primary functions:
  1. Logic Execution: Runs control logic to manage industrial processes (e.g., turbine speed control, fuel flow adjustment), ensuring precise and timely adjustments.
  2. I/O Management: Communicates with I/O modules via the Mark VIe backplane to acquire field device signals (e.g., sensor data from turbine blades) and send control commands (e.g., actuator adjustments to valves).
  3. System Reliability: Features hot-swappable design and triple-redundant configuration support (up to three modules in parallel), ensuring uninterrupted operation in case of hardware failure.
Core Functionality:
  • High-Speed Processing: The 667 MHz Freescale PowerPC 8349 processor and QNX Neutrino RTOS enable fast logic execution (e.g., <1 ms response time for turbine tripping), critical for time-sensitive processes.
  • Flexible Communication: 6× Ethernet ports support GE’s proprietary IONet protocol for high-speed communication with I/O modules and external systems (e.g., HMIs, SCADA). The USB port allows for easy configuration and maintenance.
  • Rugged Design: Fanless, passive cooling design ensures reliable operation in high-temperature environments (up to +65°C), while conformal coating protects against dust and moisture (NFPA Class 1, Div. 2 compliant).
  • Diagnostic Features: Front-panel LEDs (Power, Boot, Online, Flash, DC, Diag) provide real-time status feedback, simplifying troubleshooting and reducing downtime.
Platform Benefits (Mark VIe Series):
The IS220UCSAH1A inherits the Mark VIe platform’s strengths, including:
  • Reliability: Proven 24/7 operation in power plants, refineries, and manufacturing facilities worldwide.
  • Legacy Compatibility: Works with existing Mark VIe components (e.g., I/O racks, communication modules), reducing upgrade costs.
  • Scalability: Supports expansion with additional I/O modules or memory boards to accommodate growing system demands.

    GE IS220UCSAH1A

    GE IS220UCSAH1A

Technical Specifications​
  • Model Number: IS220UCSAH1A (Variant of Mark VIe Series)
  • Manufacturer: GE (General Electric)
  • Product Type: Embedded Controller Module
  • Series: Mark VIe (Industrial Automation)
  • Processor: Freescale PowerPC 8349 (667 MHz)
  • Operating System: QNX Neutrino RTOS (preemptive multitasking)
  • Memory: 256 MB DDR SDRAM + 512 MB NAND Flash
  • Communication Ports: 6× Ethernet (RJ45, IONet) + 1× USB (configuration)
  • Power Supply: 18–36 V DC (12 W typical)
  • Operating Temperature: 0°C to +65°C (industrial-grade)
  • Storage Temperature: -40°C to +85°C
  • Humidity: 5–95% non-condensing
  • Weight: ~0.91 kg (2 lbs)
  • Certifications: CE, UL, NFPA Class 1 Div 2 (inferred from GE industrial product standards)
Core Features & Customer Value​
1. High-Speed Logic Execution:
The 667 MHz processor and QNX RTOS ensure fast processing of control logic, critical for time-sensitive processes like turbine speed control or chemical dosing. This minimizes process deviations and optimizes efficiency.
2. Reliable Operation:
Triple-redundant configuration support and hot-swappable design ensure uninterrupted operation, even in case of hardware failure. This is critical for applications like power generation, where downtime can result in significant losses.
3. Flexible Communication:
6× Ethernet ports and 1× USB port allow for easy integration with existing systems, reducing installation costs and complexity. The IONet protocol ensures high-speed communication with I/O modules and external devices.
4. Rugged Design:
Fanless, passive cooling design and conformal coating ensure reliable operation in harsh industrial environments (e.g., power plant turbine halls). This reduces maintenance costs and extends the module’s lifespan.
5. Easy Troubleshooting:
Front-panel LEDs provide real-time status feedback, simplifying troubleshooting and reducing downtime. For example, if the “Diag” LED turns on, technicians can quickly identify a fault and take corrective action.

GE IS220UCSAH1A

GE IS220UCSAH1A

Typical Applications​
The GE IS220UCSAH1A​ is widely used in industrial automation systems for:
  1. Power Generation:
    • Controls turbine speed, fuel flow, and generator output in gas/steam turbine power plants—ensuring stable power output and preventing turbine damage.
  2. Oil & Gas:
    • Manages valve positioning, flow rates, and temperature loops in refineries—ensuring safe and efficient operation of catalytic cracking units and distillation columns.
  3. Manufacturing:
    • Controls assembly line equipment (e.g., robotic arms, conveyor belts) in automotive and electronics manufacturing—ensuring precise and efficient production.
  4. Water Treatment:
    • Manages pump and valve control in water treatment plants—ensuring proper flow and quality of treated water.
