GE IS230TCISH6C

Description

Detailed Parameter Table

GE IS230TCISH6C

Product Introduction

The **GE IS230TCISH6C** is a high – performance industrial Ethernet communication interface module under GE’s Mark VIe control system series, specifically designed to enable seamless data exchange between Mark VIe I/O modules/controllers and upper – level industrial networks. As a core connectivity component in automation systems, it serves as the bridge between distributed control units and supervisory systems (such as SCADA, MES), supporting multiple mainstream industrial Ethernet protocols to ensure compatible and efficient data transmission in complex industrial environments.

In modern industrial digitization scenarios, the **GE IS230TCISH6C** plays a vital role in breaking down “information silos” between different system layers. Its dual – gigabit Ethernet ports support network redundancy, ensuring uninterrupted communication even in case of a single network failure. By providing real – time data transmission with low latency, the **GE IS230TCISH6C** enables remote monitoring, centralized control, and data analytics of automation systems, laying a solid foundation for industrial internet of things (IIoT) applications.

Core advantages and technical highlights

Multi – Protocol Compatibility: The **GE IS230TCISH6C** supports three mainstream industrial Ethernet protocols—Ethernet/IP, Modbus TCP, and PROFINET. This multi – protocol capability allows it to seamlessly integrate with different brand devices and systems, such as Allen – Bradley PLCs, Siemens SCADA, and third – party MES platforms. Users can switch between protocols via software configuration without changing hardware, greatly enhancing the flexibility and scalability of the automation system.

High – Speed and Redundant Communication: Equipped with 2 x 10/100/1000 Mbps Ethernet ports, the **GE IS230TCISH6C** achieves data transfer rates up to 1 Gbps, ensuring real – time transmission of large – volume process data. The ports support network redundancy modes such as ring topology and dual – path backup, which can automatically switch to the standby network within milliseconds when the primary network fails, minimizing communication interruptions and improving the reliability of the entire control system.

Robust Isolation and Anti – Interference: With a 2kVrms isolation rating between Ethernet ports and the backplane, the **GE IS230TCISH6C** effectively suppresses electrical noise, ground loops, and voltage transients common in industrial sites. Its built – in surge protection (IEC 61000 – 4 – 5) and electromagnetic compatibility (EMC) design enable stable operation in harsh environments with strong electromagnetic interference, such as power plant switchyards and steel mills.

Easy Integration and Configuration: The **GE IS230TCISH6C** is fully compatible with the Mark VIe chassis, supporting hot – swapping for quick module replacement without shutting down the system. It can be configured via GE’s Proficy Machine Edition software, which provides an intuitive graphical interface for protocol setting, IP address assignment, and data mapping. The module also supports auto – discovery by upper – level systems, simplifying the commissioning process and reducing setup time.

Typical application scenarios

In coal – fired power plants, the **GE IS230TCISH6C** is deployed in the Mark VIe turbine control system to connect the local I/O modules with the central SCADA system. It transmits real – time turbine parameters (such as speed, pressure, and temperature) via Ethernet/IP to the SCADA platform, enabling operators to monitor turbine operation remotely. The dual – port redundancy ensures that communication is not interrupted even if one Ethernet cable is damaged, preventing production losses caused by communication failures.

In automotive manufacturing plants, the **GE IS230TCISH6C** is used to connect Mark VIe I/O modules on the production line with the MES system via PROFINET. It sends production data (such as equipment status, production count, and defect rate) to the MES platform for data analytics and production scheduling. Meanwhile, it receives control commands from the MES system to adjust the production line speed or switch production models, realizing the integration of production execution and process control. Its anti – interference capability ensures stable communication in the factory environment with a large number of frequency converters and motors.

Related model recommendations

**GE IS230TCICH1A**: A Mark VIe communication module supporting only Ethernet/IP, which is a cost – effective alternative to the **GE IS230TCISH6C** for single – protocol applications.

**GE IS230TNTRHIC**: A Mark VIe isolated digital input module that works with the **GE IS230TCISH6C** to collect field sensor data and transmit it to upper – level systems.

**GE IS230TCISH8C**: An upgraded version of the **GE IS230TCISH6C** with 4 Ethernet ports, suitable for large – scale network topologies requiring more connection points.

**GE IS230TSPRH1CDIN**: A Mark VIe signal processing module that, when paired with the **GE IS230TCISH6C**, transmits processed analog signals to the SCADA system for monitoring.

**GE IS230TDBTH6A**: A Mark VIe discrete I/O terminal board that provides wiring interfaces for field devices connected to the I/O modules, working in tandem with the **GE IS230TCISH6C** in the entire control system.

**GE IS230TCISH4C**: A compact version of the **GE IS230TCISH6C** with 1 Ethernet port, designed for small – scale automation systems with simple network requirements.

**GE IS230TRLYH1B**: A Mark VIe digital relay output module that executes control commands received by the **GE IS230TCISH6C** from upper – level systems.

GE IS230TCISH6C

Installation, commissioning and maintenance instructions

Installation preparation: Before installing the **GE IS230TCISH6C**, ensure the Mark VIe chassis is powered off. Check that the chassis slot is compatible with the module (Mark VIe standard slot). Required tools include a Phillips screwdriver and ESD wristband. Clean the module and chassis slot to remove dust. Align the module with the chassis guide rails and insert it firmly until it clicks into place, then fasten the front panel screws. Use CAT5e or higher – grade shielded Ethernet cables to connect the module’s ports to the network switch; ensure the cable length does not exceed 100 meters. Configure the module’s IP address via Proficy Machine Edition software before powering on the system.

Maintenance suggestions: Perform monthly visual inspections of the **GE IS230TCISH6C** to check the status of the Ethernet port LEDs (link/activity indicators) and ensure no loose connections. Use a network tester quarterly to verify Ethernet port communication performance. Clean the module’s ventilation holes and chassis slot with compressed air (max pressure 0.5MPa) every six months to prevent dust accumulation. If communication failures occur, first check the Ethernet cable and switch, then use the module’s built – in diagnostic function via Proficy Machine Edition to locate faults. Replace the module with a genuine GE spare part if it is damaged, and ensure the new module’s firmware version is consistent with the system.

Service and guarantee commitment

The **GE IS230TCISH6C** comes with a 12 – month manufacturer’s warranty covering defects in materials and workmanship. GE’s global technical support team provides 24/7 assistance via email, online portals, and phone, offering firmware updates, configuration guides, and network troubleshooting solutions. We also provide on – site technical support for complex network integration projects. Extended warranty plans up to 3 years are available to ensure long – term operational stability. GE is committed to delivering high – quality communication modules and professional services to help customers build reliable and efficient industrial automation networks.
