Product Introduction

The GE VME7865RC is a high – performance VME single board computer designed by General Electric. It belongs to the VME product series, which is widely used in industrial control and automation systems. This single board computer serves as a crucial component in such systems, providing computing power and interface capabilities.

Powered by Intel Core/Core 2 Duo processors, the VME7865RC can reach speeds up to 2.16 GHz, offering excellent data processing capabilities. With up to 3GB of DDR2 SDRAM and 4GB of bootable Compact Flash, it can handle substantial amounts of data and programs. The VME7865RC is compliant with industry standards such as ANSI/VITA 1.5 – 2003 for its VMEbus interface, ensuring seamless integration with other VME – based systems. In an automation system, it acts as a central processing unit, coordinating data collection from various sensors, processing control algorithms, and sending control signals to actuators, thus enabling the smooth operation of the entire system.

Core Advantages and Technical Highlights

High – performance processing: The use of Intel Core/Core 2 Duo processors in the GE VME7865RC allows for rapid data processing. Whether it’s handling complex control algorithms in an industrial process or processing large amounts of sensor data in real – time, the up – to – 2.16 GHz speed ensures high – efficiency operation. This makes it suitable for applications where quick response times are critical, such as high – speed manufacturing lines.

Abundant memory and storage: With support for up to 3GB of DDR2 SDRAM and 4GB of bootable Compact Flash, the VME7865RC has ample resources to store programs and data. This large – capacity memory not only enables the smooth running of multiple tasks simultaneously but also provides sufficient space for data logging and buffering, which is essential for continuous operation in industrial environments.

Versatile I/O options: Equipped with two RS – 232/422 serial ports, four USB 2.0 ports, two gigabit ethernet RJ45 ports, and a PCI – X PMC site, the VME7865RC offers extensive connectivity options. It can easily interface with a wide range of devices, from traditional serial – connected sensors to modern high – speed network devices. This versatility allows for seamless integration into diverse automation systems, adapting to different application requirements.

Rugged design: Available in both commercial and rugged extended temperature versions, the GE VME7865RC can withstand harsh operating conditions. In industrial settings where temperature fluctuations, dust, and vibrations are common, the rugged version ensures reliable operation. This makes it a reliable choice for applications in factories, power plants, and other industrial facilities.

Typical Application Scenarios

Industrial automation: In manufacturing plants, the GE VME7865RC can be used to control complex production lines. For example, in an automotive assembly line, it can collect data from sensors on various robotic arms and conveyor belts. By processing this data, it can adjust the speed and movement of the equipment in real – time, ensuring smooth assembly operations and high – quality production. It can also communicate with other control systems in the plant, such as the overall production management system, to coordinate production schedules.

Power generation: In power plants, whether it’s a coal – fired, gas – fired, or hydroelectric power plant, the VME7865RC plays a vital role. It can be used to monitor and control the operation of turbines. By receiving data from sensors measuring temperature, pressure, and rotational speed of the turbines, it can adjust the fuel supply or water flow to optimize power generation efficiency. In addition, it can communicate with the power grid control system to ensure stable power output and grid connection.

Transportation infrastructure: In intelligent transportation systems, such as subway control centers, the GE VME7865RC can be used to manage train operations. It can process data from sensors on the tracks, platforms, and trains, including train location, speed, and door status. Based on this data, it can control the signaling system, adjust train schedules, and ensure the safe and efficient operation of the subway network.

GE VME7865RC V7865-23003 350-9300007865-230003 M

Related Model Recommendations

GE V7865 – 223003: It is in the same product series as the GE VME7865RC, with similar functionality. It is also designed for industrial control applications, offering real – time data processing and control capabilities. However, it may have some differences in specific configuration or performance parameters, which can be selected according to the actual needs of the project.

GE Wescom VME: This is another industrial control module from GE. It can be used in combination with the VME7865RC in some complex automation systems. For example, the Wescom VME module may focus on certain specific control functions, while the VME7865RC provides overall computing and general I/O capabilities, and they work together to enhance the performance of the entire system.

GE Fanuc VME single – board computers with different processor speeds: Such as models with lower – speed processors like 1.66 GHz. These models are suitable for applications where the processing power requirements are not extremely high, but cost – effectiveness is a key consideration. They can be used as an alternative to the VME7865RC in some less demanding industrial control scenarios.

GE VME modules with different memory configurations: Some modules may have different on – board memory sizes or memory expansion options. If the application has specific memory requirements, these modules can be selected. For example, if more on – board memory is needed for immediate data processing, a module with a larger on – board memory can be chosen instead of relying solely on external memory expansion as in the VME7865RC.

GE VME – based systems with additional specialized interfaces: These systems may have extra interfaces for specific applications, such as fiber – optic interfaces for high – speed data transfer in certain communication – intensive industrial scenarios. They can be integrated with the VME7865RC to meet the diverse needs of complex industrial automation projects.

Installation, Commissioning and Maintenance Instructions

Installation preparation: Before installing the GE VME7865RC, ensure that the power to the entire VME system is turned off to prevent electrical shock. The installation environment should be clean, dry, and free from excessive dust and electromagnetic interference. Check the physical dimensions of the installation location to ensure a proper fit, as the VME7865RC has a single – slot, eurocard form factor. Gather necessary installation tools, such as screwdrivers and anti – static wristbands to protect the board from electrostatic discharge.

Commissioning steps: Carefully insert the VME7865RC into the designated VME slot, making sure it is properly seated. Connect the power cables, ensuring correct polarity. Then, connect the various I/O cables, such as serial, USB, and ethernet cables, according to the system requirements. Power on the system and enter the BIOS setup (AMI BIOS for the VME7865RC) to configure basic settings, such as boot device selection (e.g., Compact Flash), system clock, and CPU settings. After that, test the board by running diagnostic software or by connecting it to a simple test system to verify its functionality.

Maintenance suggestions: Regularly check the GE VME7865RC for any signs of physical damage, such as cracks on the board or loose connectors. Clean the board periodically using a soft, dry brush to remove dust. Monitor the system performance, including CPU usage, memory utilization, and data transfer speeds. If any abnormal behavior is detected, such as system freezes or slow response times, check the system logs and run diagnostic tools. In case of component failures, such as a malfunctioning memory module, follow the manufacturer’s instructions to replace the faulty part. Keep the BIOS and any relevant software up – to – date to ensure optimal performance and compatibility.
