GE VMIVME2170A

Description

Detailed Parameter Table

GE VMIVME2170A

Product Introduction

GE’s VMIVME2170A is a high – performance 32 – bit optically isolated digital output board, an integral part of GE’s renowned VMIVME systems. It serves as a crucial interface between the VMIVME system and external devices, playing a pivotal role in industrial automation scenarios. This board is engineered to precisely control external equipment such as relays and solenoids based on digital signals received from the VMIVME system. With its advanced design, the VMIVME2170A ensures reliable and accurate operation, enabling seamless integration into complex industrial control setups. Whether in a large – scale manufacturing plant or a critical power generation facility, the VMIVME2170A contributes significantly to the smooth functioning of the overall automation system by efficiently translating digital commands into actionable outputs for external devices.

Core Advantages and Technical Highlights

High – current output capability: Each of the 32 channels on the VMIVME2170A can switch up to 2 amps of current. This high – current capacity allows it to drive a wide range of external devices directly, reducing the need for additional amplification or intermediate components in many applications. For example, it can power large – sized solenoids used in industrial valve control systems without any issues.

Optical isolation: The board features 2500 VDC optical isolation, which effectively protects the internal circuitry of the VMIVME system from electrical interference and transients from external devices. This isolation not only enhances the reliability of the system but also safeguards against potential damage caused by voltage spikes or short circuits in the external equipment, ensuring long – term stable operation.

Robust protection mechanisms: Equipped with built – in short – circuit and overload protection, the VMIVME2170A can withstand abnormal electrical conditions. In case of a short circuit in an external device connected to one of its output channels, the protection circuitry will quickly activate to prevent damage to the board and other components in the system, minimizing downtime and maintenance costs.

Wide temperature range operation: With an operating temperature range from – 40 °C to 85 °C, the VMIVME2170A is suitable for use in diverse and harsh industrial environments. Whether in cold storage facilities or hot and humid industrial processing plants, it can continue to function accurately, making it a versatile choice for various industrial applications.

Typical Application Scenarios

In manufacturing industries, the VMIVME2170A is extensively used in automated production lines. For instance, in an automotive assembly plant, it controls the relays that operate robotic arms, conveyor belts, and other mechanical components. By precisely timing the activation and deactivation of these devices, it ensures smooth and efficient production processes, minimizing errors and increasing productivity. In the power generation sector, it is employed to control the solenoid valves in cooling systems, fuel supply systems, and electrical switchgear. The high – current output and reliable performance of the VMIVME2170A are crucial for maintaining the stable operation of power plants. In chemical plants, it is used to control the opening and closing of valves in chemical reaction processes, where accurate control of external devices is essential for ensuring the safety and quality of chemical production.

GE VMIVME2170A

Related Model Recommendations

VMIVME2160: A related digital output board in the same series as VMIVME2170A. It has a lower number of output channels, typically 16, making it suitable for applications where a smaller number of external devices need to be controlled. It shares a similar form factor and basic functionality but is more cost – effective for less complex setups.

VMIVME2180: An upgraded version of the VMIVME2170A. It offers additional features such as higher isolation voltage (up to 3000 VDC) and enhanced diagnostic capabilities. This model is ideal for applications where a higher level of electrical safety and real – time monitoring of output status are required, like in high – voltage industrial environments.

VMIVME2171: A variant of the VMIVME2170A with a slightly different output voltage configuration. It is designed to work with specific external devices that require a different output voltage level, providing more flexibility in system integration.

VMIVME2155: A smaller – sized digital output board that can be used as a space – saving alternative to the VMIVME2170A in applications where physical space is limited. It still provides reliable digital output control but with a more compact footprint.

VMIVME2175: This model has a faster response time compared to the VMIVME2170A, making it suitable for applications that demand rapid switching of external devices, such as high – speed packaging machinery.

Installation, Commissioning and Maintenance Instructions

Installation preparation: Before installing the VMIVME2170A, ensure that the installation environment meets the specified temperature and humidity requirements. Use appropriate anti – static precautions to prevent damage to the board during handling. Prepare the necessary tools, such as screwdrivers for mounting the board in the VMIVME rack. Check the wiring connections carefully to ensure that the input and output voltages match the board’s specifications. Disconnect all power sources from the VMIVME system to ensure safety during installation.

Maintenance suggestions: Regularly inspect the VMIVME2170A for any signs of overheating, loose connections, or physical damage. Clean the board periodically to remove dust and debris, which can affect its performance. In case of a fault, use GE’s diagnostic tools to identify the problem. If a channel fails, check for short circuits in the connected external device first. When replacing spare parts, always use genuine GE components to ensure compatibility and performance. Keep a record of maintenance activities for future reference.

Service and Guarantee Commitment

GE offers a comprehensive service and guarantee for the VMIVME2170A. The product comes with a standard warranty period, during which GE will replace or repair any defective boards free of charge. GE’s global technical support team is available 24/7 to provide assistance. They can offer remote troubleshooting guidance or, if necessary, dispatch on – site technicians. GE also provides regular software updates and technical documentation to help users optimize the performance of the VMIVME2170A. This commitment reflects GE’s confidence in the quality of the product and its dedication to ensuring customer satisfaction in industrial automation applications.
