Powerful Processing Capability: The GE IC693CPU341 is equipped with an 80C188XL processor, which operates at a high speed of 20 MHz, enabling it to handle complex control tasks with ease and ensuring quick response times and efficient data processing.
Ample Memory: It has a relatively large user program memory of 80 K bytes, along with rich register memory, discrete global memory, etc. This allows for the storage of extensive program instructions and data, meeting the requirements of various industrial applications.
Versatile Communication: The module is equipped with a serial port that supports SNP/SNP – X slave protocols. It can also be expanded with optional network communication modules such as Ethernet, GBC, and FIP, facilitating seamless integration with other devices and systems in the industrial automation network.
Reliable Operation: With a rugged construction, the IC693CPU341 can operate stably within the temperature range of 0 – 60 °C, making it suitable for use in harsh industrial environments.
Manufacturer: GE Part number: IC693CPU341
Our extensive GE catalogue, including
: IC693CPU341
, is available now for dispatch to the worldwide.
The GE IC693CPU341 is a high – performance CPU module belonging to the GE Fanuc 90 – 30 series, designed for programmable logic controllers (PLCs) in industrial automation systems. It is a single – slot module with 5 baseplates, including CPU baseplate and 4 remote and/or expansion baseplates.
Equipped with an 80C188XL processor running at 20 MHz, the IC693CPU341 offers reliable and efficient operation. It has a maximum user program memory of 80 K bytes, along with various types of memory such as register memory, discrete global memory, internal coils, and output coils, which provide sufficient storage space for programs and data. This module is capable of handling complex control tasks, making it an important component in industrial automation, enhancing the overall control accuracy and efficiency.
Technical Specifications
Parameter Name
Parameter Value
Product Model
IC693CPU341
Manufacturer
General Electric
Product Type
CPU Module
Processor
80C188XL
Processor Speed
20 MHz
Power Supply
+5 VDC, 490 milliamps
Operating Temperature
0 – 60 °C (32 – 140 °F)
User Program Memory
80 K bytes
Register Memory
9999 words
Discrete Global Memory
1280 bits
Internal Coils
1024 bits
Output Coils
256 bits
Analog Inputs
1024 words
Analog Outputs
256 words
Discrete Inputs
512 words
Discrete Outputs
512 words
GE IC693APU301
Main Features and Advantages
Powerful Processing Capability: The GE IC693CPU341 is equipped with an 80C188XL processor, which operates at a high speed of 20 MHz, enabling it to handle complex control tasks with ease and ensuring quick response times and efficient data processing.
Ample Memory: It has a relatively large user program memory of 80 K bytes, along with rich register memory, discrete global memory, etc. This allows for the storage of extensive program instructions and data, meeting the requirements of various industrial applications.
Versatile Communication: The module is equipped with a serial port that supports SNP/SNP – X slave protocols. It can also be expanded with optional network communication modules such as Ethernet, GBC, and FIP, facilitating seamless integration with other devices and systems in the industrial automation network.
Reliable Operation: With a rugged construction, the IC693CPU341 can operate stably within the temperature range of 0 – 60 °C, making it suitable for use in harsh industrial environments.
Application Field
The GE IC693CPU341 is widely used in various industrial automation fields. In the manufacturing industry, it is used to control production lines, such as in automotive manufacturing for the control of robotic arms and conveyor belts. In the process control industry, it is applied to monitor and control chemical reaction processes, temperature, pressure, and other parameters. In building automation systems, it can be used to manage lighting, air – conditioning, and security systems. Moreover, in the power industry, it is utilized for the control and monitoring of power generation equipment and power distribution systems. No matter in which industrial field, the IC693CPU341 can provide reliable control and efficient operation, helping to improve production efficiency and product quality while reducing costs.
GE IC693APU301
Related Products
IC693CPU311: It is an embedded CPU module in the GE Fanuc 90 – 30 series, similar to the IC693CPU341 but with lower cost and relatively lower performance, suitable for applications with less complex control requirements.
IC693CPU323: Also an embedded CPU, it has different performance characteristics and memory configurations from the IC693CPU341, meeting the needs of some specific industrial control scenarios.
IC693CPU331: A modular CPU like the IC693CPU341, but with different features and performance in processing power and memory, suitable for applications that require different levels of control performance.
IC697HSC700: It is a high – speed counter module that can be used in conjunction with the IC693CPU341 to meet the needs of high – speed counting and position control in industrial automation.
IC693MDL940: An I/O module that can be connected to the IC693CPU341 to expand the input and output points, increasing the number of signals that the system can handle.
Installation and Maintenance
Pre – installation preparation: Before installing the GE IC693CPU341, make sure the power supply meets the requirements, and check that the baseplate and other related modules are in good condition. Clean the installation site to avoid dust and debris affecting the operation of the module. Also, ensure that the installation environment temperature is within the specified range of 0 – 60 °C.
Maintenance recommendations: Regularly check the operating status of the IC693CPU341, including its temperature, power supply, and communication status. Clean the module regularly to prevent dust from accumulating. When there is a problem, refer to the manual for troubleshooting or contact professional technical support. It is recommended to back up the program and data regularly to prevent data loss in case of module failure.
Product Guarantee
GE provides a quality – assured guarantee for the IC693CPU341. The product undergoes strict quality inspection before leaving the factory to ensure its performance and reliability. In terms of after – sales service, GE offers professional technical support to help customers solve problems encountered during use. If the product has quality problems within the warranty period, GE will provide repair or replacement services in a timely manner, demonstrating the company’s confidence in product quality and its commitment to customer satisfaction.
