IC697CHS790

Description

Description

The IC697CHS790 is a high-performance 10-slot backplane module developed by GE Fanuc (now part of Emerson’s industrial automation portfolio) for the RX3i Programmable Logic Controller (PLC) system. As the central “nerve center” of the RX3i rack, it provides the physical and electrical connection between the CPU, I/O modules, and communication modules, enabling high-speed data transfer and reliable operation in demanding industrial environments. Its rugged design, high-density slot configuration, and advanced backplane technology make it an essential component for building scalable, high-performance automation systems.

Application Scenarios

A large automotive parts manufacturer in Ohio faced a significant challenge when expanding its production line: the existing control system was spread across multiple small cabinets with limited I/O capacity, resulting in complex wiring, increased maintenance costs, and slower system response times. By implementing the IC697CHS790 as the central backplane in a new RX3i system, the manufacturer was able to consolidate its control architecture into a single, high-density rack. This reduced wiring complexity by 60%, improved system response time by 40%, and simplified maintenance procedures. The IC697CHS790’s robust design also proved reliable in the plant’s harsh environment, operating continuously without failure for over two years.

Parameter

IC697CHS790

Technical Principles and Innovative Values

High-Speed Backplane Architecture: The IC697CHS790 features a high-speed data bus that enables rapid communication between the CPU and I/O modules. This architecture reduces system latency and improves overall performance, making it ideal for time-critical applications.

Enhanced Signal Integrity: The backplane design incorporates advanced noise filtering and signal conditioning techniques, ensuring reliable data transmission even in electrically noisy industrial environments.

High-Density Design: With 10 slots in a compact form factor, the IC697CHS790 maximizes I/O capacity while minimizing the space required in control cabinets.

Robust Construction: Built to withstand harsh industrial conditions, the backplane features rugged components and a durable design that ensures long-term reliability.

Easy System Expansion: The modular design allows for straightforward system expansion by simply adding more modules to the backplane, making it easy to adapt to changing production needs.

Application Cases and Industry Value

Automotive Manufacturing Plant: An automotive assembly plant implemented the IC697CHS790 as part of a complete RX3i control system upgrade. The backplane’s high-speed data transfer capabilities enabled precise synchronization of robotic welding equipment, reducing production defects by 35%. The plant also benefited from simplified maintenance procedures, with technicians reporting a 50% reduction in troubleshooting time.

Water Treatment Facility: A municipal water treatment plant replaced its outdated control system with an RX3i solution centered around the IC697CHS790. The backplane’s robust design and reliable performance ensured continuous operation of critical pumping and chemical dosing systems. Plant operators noted improved system stability and reduced downtime, leading to significant cost savings.

Related Product Combination Solutions

IC697CPU350: High-performance RX3i CPU module that serves as the system’s processing center.

IC697PWR720: Power supply module that provides reliable power to the entire RX3i system.

IC697MDL240: 32-channel digital input module for monitoring various sensors and devices.

IC697MDL250: 32-channel digital output module for controlling actuators and other devices.

IC697ALG440: 4-channel analog output module for precise control of variable-speed equipment.

IC697CMM742: Ethernet communication module for connecting the RX3i system to plant networks.

IC697MEM320: Memory module for expanding the system’s data storage capabilities.

IC697CHS790

Installation, Maintenance, and Full-Cycle Support

Installing the IC697CHS790 is straightforward, with a simple rack-mount design that allows for quick integration into control cabinets. The backplane accepts all RX3i modules, which simply slide into place and lock securely. Proper installation requires connecting the backplane to a compatible power supply and ensuring all modules are correctly seated.

Maintenance of the IC697CHS790 is minimal due to its rugged design and high-quality components. Regular visual inspections to ensure all modules are properly seated and connectors are clean is recommended. In the event of a module failure, individual components can be replaced without affecting the entire system.

Emerson provides comprehensive support for the IC697CHS790, including technical assistance, repair services, and replacement parts. The module is backed by a standard warranty, and Emerson’s global network of service centers ensures prompt support wherever your facility is located.
