IC698CMX016 VMIVME-5567-000 350-005567-000

The GE IC698CMX016 VMIVME – 5567 – 000 350 – 005567 – 000 is a high – performance communication module, an integral part of the GE Fanuc RX7i series, designed for the PACSystems RX7i programmable controllers. It plays a crucial role in industrial automation by enabling seamless transfer of information between devices and PLCs. Using reflective memory technology, it operates on a high – speed fiber optic network with a data rate of 2.12 giga baud, allowing for real – time data sharing. This module supports up to 256 nodes that are compatible with 5565 devices, forming a daisy – chained loop. Any change in status at one node is instantaneously relayed to all others, ensuring efficient and coordinated operation within complex industrial control systems. It serves as a key component for applications that demand rapid and reliable data exchange across multiple devices, such as in large – scale manufacturing plants or industrial process control facilities.

The GE IC698CMX016 VMIVME – 5567 – 000 350 – 005567 – 000 offers an impressive 2.12 giga baud data rate. This high – speed transfer capability is essential for applications where real – time data sharing is critical. For example, in fast – paced manufacturing lines where multiple PLCs and devices need to communicate instantaneously to coordinate production processes, this module ensures that data is transmitted without significant delay.

With its use of reflective memory, any change in data at one node is automatically updated across all nodes in the network. This feature simplifies data management and synchronization, reducing the complexity of programming and system integration. In industrial settings where multiple components need to work in harmony, such as in a large – scale chemical plant with numerous sensors and actuators, this technology ensures that all devices have the most up – to – date information.

It can support up to 256 nodes, providing extensive connectivity options. The daisy – chained loop configuration using fiber optic cables not only offers reliable connec

tions but also allows for easy expansion of the network. This makes it suitable for both small – scale industrial setups that may grow in the future and large – scale, complex industrial plants that require a high number of connected devices.

In manufacturing plants, the GE IC698CMX016 VMIVME – 5567 – 000 350 – 005567 – 000 is used to control and coordinate various production processes. For instance, in an automotive assembly line, it can facilitate communication between different PLCs that control the movement of robotic arms, conveyor belts, and other equipment. This ensures that each component of the assembly process is synchronized, leading to increased production efficiency and reduced errors.

In industries such as oil and gas, chemical, and power generation, process control is crucial. The module can be used to connect sensors and actuators in a distributed control system. For example, in a power plant, it can enable seamless communication between temperature sensors, pressure sensors, and control valves. This allows for real – time monitoring and adjustment of the power generation process, ensuring stable and efficient operation.

For large – scale industrial automation systems, this module serves as a key communication hub. It can integrate different subsystems, such as material handling systems, quality control systems, and production scheduling systems. In a food and beverage factory, it can connect the PLCs controlling the filling machines, labeling machines, and packaging equipment, enabling smooth operation of the entire production line.

This is a variant of the GE IC698CMX016 VMIVME – 5567 – 000 350 – 005567 – 000 module. It may have some differences in features or performance, perhaps an enhanced version in terms of additional diagnostic capabilities or slightly different memory management functions.

These are the programmable logic controllers with which the GE IC698CMX016 VMIVME – 5567 – 000 350 – 005567 – 000 is designed to work. The PLCs provide the overall control logic, and the communication module enhances their ability to exchange data with other devices in the network.

These devices are compatible with the GE IC698CMX016 VMIVME – 5567 – 000 350 – 005567 – 000 module. They can be part of the same reflective memory network, sharing data and working together to achieve coordinated operation in industrial applications.

Specific fiber optic cables, such as those with 62.5 – micron core LC type connectors, are used to connect the GE IC698CMX016 VMIVME – 5567 – 000 350 – 005567 – 000 module to other nodes in the network. They are essential for ensuring high – speed and reliable data transmission.

Since the GE IC698CMX016 VMIVME – 5567 – 000 350 – 005567 – 000 operates on 5 – volt buses with a minimum current requirement of 1.2 amperes, compatible power supplies are needed to ensure proper functioning of the module.

Pre – installation preparation: Before installing the GE IC698CMX016 VMIVME – 5567 – 000 350 – 005567 – 000 module, carefully read the installation manual provided by GE. Ensure that the PACSystems RX7i programmable controller where it will be installed is powered off. Check the compatibility of all the devices that will be part of the reflective memory network. The module should be installed in a clean environment, free from excessive dust and humidity, within the specified temperature range. Use the appropriate 62.5 – micron core LC type connectors to make secure fiber optic cable connections.
Maintenance recommendations: Regularly inspect the module for any signs of physical damage, such as cracks in the casing or loose fiber optic connections. Monitor the data transfer rate and network performance. If there are any significant drops in data transfer speed or communication errors, it could indicate a problem with the module. Clean the module periodically to remove any dust that may have accumulated, as this can affect its performance. If any issues are detected, refer to the troubleshooting guide in the manual or contact GE’s technical support for assistance.

GE offers a comprehensive product guarantee for the GE IC698CMX016 VMIVME – 5567 – 000 350 – 005567 – 000 module. Usually, it comes with a standard warranty period during which any defects in materials or workmanship will be rectified by GE at no cost to the customer. Their global technical support team is available to provide assistance with installation, operation, and troubleshooting. Whether it’s helping with initial setup in a complex industrial network, answering questions about data transfer rates, or resolving issues related to network connectivity, GE’s experts are committed to ensuring the optimal performance of the module. This product guarantee reflects GE’s confidence in the reliability and durability of the GE IC698CMX016 VMIVME – 5567 – 000 350 – 005567 – 000 module, giving customers peace of mind when integrating it into their industrial automation systems.
