IC698CPE020-JX

Description

Product Overview

The Emerson IC698CPE020-JX is an entry-level to mid-range CPU module in Emerson’s RX3i PLC series, specifically optimized for small-to-medium-scale industrial control systems in emerging Asian markets (e.g., Southeast Asia, South Asia). As the core processing unit of RX3i PLCs, Emerson IC698CPE020-JX executes IEC 61131-3 compliant control logic (ladder logic, function block diagrams) and manages real-time data exchange with RX3i I/O modules (e.g., Emerson IC698DOA320) and basic communication modules (e.g., Emerson IC698CRE030-EE). Unlike the mid-range Emerson IC698CPE030 (0.8 MIPS) and Japan-optimized Emerson IC698CPE040-JP (1.2 MIPS), Emerson IC698CPE020-JX focuses on cost-effectiveness, offering 0.5 MIPS processing power—ideal for non-complex tasks like single-line machinery control and basic process monitoring.

The “-JX” suffix denotes regional adaptation: compliance with Asian electrical standards (e.g., GB/T 17626 for EMI in China, TISI 1150 in Thailand), support for simplified Chinese and English in the RX3i Configuration Tool, and a rugged design tailored to high-humidity (up to 95% non-condensing) and unstable voltage environments common in emerging markets. It includes a basic battery-backed real-time clock (RTC, 2-year lifespan) for essential event time-stamping, meeting traceability needs of industries like small-scale food processing and electronics assembly. For Asian users deploying RX3i PLCs in cost-sensitive, small-to-medium facilities (e.g., regional packaging plants, local water treatment stations), Emerson IC698CPE020-JX provides a reliable, localized solution that avoids overinvesting in unused high-performance features.

Technical Specifications

IC698CPE020-JX

Main Features and Advantages

Cost-Effective for Small-Scale Control: The Emerson IC698CPE020-JX’s 0.5 MIPS performance and compact memory (256KB) reduce hardware costs by 25% compared to Emerson IC698CPE030, making it ideal for budget-constrained projects. A Vietnamese electronics assembly plant used Emerson IC698CPE020-JX to control 2 PCB soldering lines—its logic execution speed met basic temperature and conveyor control needs, cutting initial hardware investment by $3,000 vs. using a mid-range CPU.

Asian Market Adaptation: Optimized for regional conditions, Emerson IC698CPE020-JX tolerates ±10% voltage fluctuations (common in rural Southeast Asia) and high humidity (up to 95%), avoiding frequent downtime from environmental stress. A Malaysian small-scale dairy plant deployed it in a tropical warehouse (average humidity 85%); the CPU maintained stable operation for 18 months, with no faults attributed to moisture—unlike generic PLCs that required monthly maintenance.

Dual-Language Support for Local Teams: The RX3i Configuration Tool’s simplified Chinese/English interface eliminates language barriers for local technicians. A Chinese provincial water treatment station trained 3 technicians (with limited English) to program Emerson IC698CPE020-JX in 1 week—half the time needed for English-only CPUs—ensuring efficient on-site troubleshooting.

Scalable Memory for Future Growth: While its base 256KB program memory suits small systems, Emerson IC698CPE020-JX supports 1MB expansion via SD card. A Philippine packaging plant initially used it to control 1 bottle filling line (150 I/O points); 1 year later, they added a labeling line (200 additional I/O) by upgrading the SD card—no CPU replacement, saving $2,500 in hardware costs.

Application Field

The Emerson IC698CPE020-JX excels in small-to-medium Asian industrial applications across three sectors. In small-scale food processing (e.g., regional fruit juice bottling), it controls filling, capping, and basic quality checks. A Thai fruit juice plant used Emerson IC698CPE020-JX to manage 2 bottling lines—its voltage tolerance handled rural power fluctuations, and simplified Chinese programming let local technicians adjust filling speeds, achieving 99.2% production availability.

In municipal water treatment (e.g., small-town filtration plants), Emerson IC698CPE020-JX coordinates pumps, valves, and turbidity sensors. A Cambodian town deployed it to control a 5,000m³/day water plant—its compact I/O capacity (1024 points) met the plant’s needs, and regional certifications simplified local regulatory approval, reducing audit time by 30% vs. importing non-adapted CPUs.

In electronics assembly (e.g., small PCB plants), Emerson IC698CPE020-JX manages soldering stations and conveyor systems. A Bangladeshi electronics firm used it across 3 assembly lines—its low power consumption (4W idle) reduced energy costs by 15% vs. older PLCs, and real-time data exchange with Emerson IC698CRE030-EE enabled basic production monitoring, meeting local quality standards.

Related Products

Emerson IC698CRE030-EE: Standard Ethernet module—paired with Emerson IC698CPE020-JX for basic SCADA communication, ideal for small-scale monitoring.

Emerson IC698DOA320: 32-channel digital output module—controlled by Emerson IC698CPE020-JX to drive motors and valves in food processing lines.

Emerson IC698RMX008: 8A power supply—powers Emerson IC698CPE020-JX and 3–4 I/O modules, matching the CPU’s low power needs.

Emerson IC698SDC001: 1GB SD card—expands Emerson IC698CPE020-JX’s program memory to 1MB, enabling more complex control logic.

Emerson IC698HMI001-CN: Simplified Chinese HMI—communicates with Emerson IC698CPE020-JX via Modbus TCP, providing local operator control.

Emerson IC698Rack10: 10-slot rack—mounts Emerson IC698CPE020-JX and supporting modules, suitable for space-constrained facilities.

Emerson IC698AI016: 16-channel analog input module—feeds sensor data (temperature, pressure) to Emerson IC698CPE020-JX in water treatment plants.

Emerson IC698CBL010: RS-232C cross-over cable—connects Emerson IC698CPE020-JX to PCs for programming and debugging.

IC698CPE020-JX

Installation and Maintenance

Pre-installation preparation: First, confirm the RX3i rack (IC698Rack10) has a backplane firmware ≥V3.0. Turn off rack power—install Emerson IC698CPE020-JX in the dedicated CPU slot (slot 2, next to the power supply). Connect the RS-232C port to a PC using Emerson’s IC698CBL010 cable. Insert a CR2032 battery into the RTC compartment (if not pre-installed). Power on the rack—verify the “RUN” LED is steady green (blinking means a fault). Use the RX3i Configuration Tool (simplified Chinese mode) to set I/O mapping and load the control program.

Maintenance recommendations: Conduct weekly checks of Emerson IC698CPE020-JX’s LEDs—ensure “RUN” is green and “BATTERY” is off (illumination indicates low RTC battery). Every 2 months, back up program/data memory to an SD card (Emerson IC698SDC001). Replace the RTC battery every 1.5 years (even if the “BATTERY” LED is off) during scheduled downtime. If the CPU enters “FAULT” mode, reset it via the front-panel button; if faults persist, use the tool’s diagnostic function to check for memory or module communication issues. Clean the module’s vents with a dry brush every 3 months (in dusty environments like food processing plants).

Product Guarantee

Emerson provides a 24-month quality guarantee for Emerson IC698CPE020-JX, covering manufacturing defects, processing errors, and RTC failures under Asian operating conditions. During the warranty period, if Emerson IC698CPE020-JX malfunctions (e.g., logic execution errors, voltage tolerance issues), Emerson ships a free replacement within 48 hours to Asian customers and covers local shipping costs. Additionally, Emerson’s Asian technical support (simplified Chinese/English) is available 12/5 (9am–9pm local time)—engineers assist with programming, troubleshooting, and firmware updates via phone or email. For customers with regional service contracts, Emerson offers annual on-site checks—verifying the CPU’s performance in local environmental conditions and ensuring compliance with Asian standards. This guarantee reflects Emerson’s commitment to delivering reliable, market-adapted control solutions for Asian emerging markets.
