Product Overview
The GE IC698PSA100E is a crucial power supply module within GE’s PACSystems, specifically designed for the RX7i series. This module plays a fundamental role in industrial control systems, ensuring a stable and reliable power supply for the entire setup and its connected components. It is engineered to output three distinct voltages, namely +5 VDC, +12 VDC, and -12 VDC. This wide range of output voltages makes it highly versatile, catering to the diverse power requirements of different PACSystems controllers and I/O modules. With a power rating of 125 watts, the IC698PSA100E can deliver up to 100 watts of total output power within an ambient temperature range of 0 to 60ºC, all without the need for forced air cooling. This feature makes it suitable for a variety of industrial environments where maintaining stable power is essential for the smooth operation of the automation system.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC698PSA100E |
| Manufacturer | GE |
| Product Type | Power Supply Module |
| Nominal Rated Voltage | 120/240 VAC or 125 VDC |
| Input Voltage Range | 85 – 264 VAC or 100 – 150 VDC |
| Input Power | 125 W |
| Output Voltages | +5 VDC (up to 20 A), +12 VDC (up to 2 A), -12 VDC (up to 1 A) |
| Module Type | Power Supply |
| Rack Location | Slot 0 (leftmost slot) |
| Power Factor Correction | For AC operation |
| Protection | Overcurrent, overvoltage, and overheating protection |
| LED Indicators | Present for field and output status indication |
| Operating Temperature | 0 – 60 °C |
| Isolation Voltage | 1500 VDC |
| Frequency Range | 47 – 63 Hz (for AC input) |
Main Features and Advantages
Versatile Voltage Output: The IC698PSA100E offers multiple output voltages, including +5 VDC, +12 VDC, and -12 VDC. This flexibility enables it to power a wide range of components within the industrial control system, ensuring compatibility with various devices.
Wide Input Voltage Range: With an input voltage range spanning from 85 to 264 VAC or 100 to 150 VDC, the module can adapt to different power sources. This feature makes it suitable for use in diverse industrial settings where power supply conditions may vary.
Advanced Fault Protection: Equipped with overcurrent, overvoltage, and overheating protection mechanisms, the IC698PSA100E safeguards the connected components and the overall system. This protection enhances the reliability and stability of the industrial control system, minimizing the risk of damage due to electrical faults.
Power Factor Correction: For AC operation, the module features power factor correction. This not only optimizes power efficiency but also helps in reducing energy consumption, leading to cost savings in the long run.
Compact Design and Easy Monitoring: Its compact design saves valuable space in control cabinets. Additionally, the front – panel two – position on / off switch and LED indicators enable convenient operation and real – time monitoring of the module’s status.
Wide Input Voltage Range: With an input voltage range spanning from 85 to 264 VAC or 100 to 150 VDC, the module can adapt to different power sources. This feature makes it suitable for use in diverse industrial settings where power supply conditions may vary.
Advanced Fault Protection: Equipped with overcurrent, overvoltage, and overheating protection mechanisms, the IC698PSA100E safeguards the connected components and the overall system. This protection enhances the reliability and stability of the industrial control system, minimizing the risk of damage due to electrical faults.
Power Factor Correction: For AC operation, the module features power factor correction. This not only optimizes power efficiency but also helps in reducing energy consumption, leading to cost savings in the long run.
Compact Design and Easy Monitoring: Its compact design saves valuable space in control cabinets. Additionally, the front – panel two – position on / off switch and LED indicators enable convenient operation and real – time monitoring of the module’s status.
Application Field
The GE IC698PSA100E finds extensive applications across numerous industrial sectors. In manufacturing plants, it serves as the power backbone for programmable logic controllers (PLCs) and I/O modules. By providing stable power, it ensures the seamless operation of production lines, enabling precise control over manufacturing processes. In process control systems, such as those in chemical plants or oil refineries, the IC698PSA100E powers the components responsible for controlling and monitoring various processes. It helps in maintaining the correct conditions for chemical reactions, fluid handling, and other critical operations. In motor control circuits, the module supplies the necessary power for motors to function smoothly. This is crucial for applications where motors drive machinery, conveyor belts, or other equipment. Moreover, in building automation systems, the IC698PSA100E powers sensors, actuators, and controllers. This allows for the efficient management of building facilities, including lighting, heating, ventilation, and air – conditioning systems.
Related Products
- IC698PSA200: A similar power supply module, potentially with different power output capacities or additional features. It might be suitable for applications that require more power or have specific power – related requirements not met by the IC698PSA100E.
- IC697PSA100: Belonging to a different series, this module has a similar function but may have different compatibility and performance characteristics. It could be an option for systems that are based on a different GE platform.
- IC698MDLxxx (where xxx represents different numbers): These are I/O modules that work in tandem with the IC698PSA100E in the PACSystems RX7i series. They expand the system’s functionality by handling input and output signals, while relying on the IC698PSA100E for power.
- IC698CPUxxx (where xxx represents different numbers): CPU modules that depend on the power supply of the IC698PSA100E to operate. They control the overall system, and the stable power from the IC698PSA100E is essential for their proper functioning.
- IC698CHSxxx (where xxx represents different numbers): Communication modules that can be used in a system powered by the IC698PSA100E. They enable data exchange with other devices or systems, enhancing the connectivity and integration capabilities of the overall setup.
Installation and Maintenance
Pre – installation preparation: Before installing the IC698PSA100E module, it is crucial to ensure that the power source strictly meets the module’s input voltage requirements. Thoroughly inspect the rack where the module will be installed. The rack should be in good condition, and slot 0, where the IC698PSA100E is to be placed, must be clean and free from any debris. Also, always turn off the power to the entire system before starting the installation process to avoid the risk of electrical shock.
Maintenance recommendations: Regularly monitor the IC698PSA100E module by checking the LED indicators on its front panel. These indicators provide valuable information about the module’s operating status. Keep the module clean by periodically removing dust and dirt, as the accumulation of such particles can affect its heat dissipation and overall performance. In case any fault occurs, consult the product manual for detailed troubleshooting steps. If the issue persists, contact GE’s technical support for professional assistance.
Maintenance recommendations: Regularly monitor the IC698PSA100E module by checking the LED indicators on its front panel. These indicators provide valuable information about the module’s operating status. Keep the module clean by periodically removing dust and dirt, as the accumulation of such particles can affect its heat dissipation and overall performance. In case any fault occurs, consult the product manual for detailed troubleshooting steps. If the issue persists, contact GE’s technical support for professional assistance.
Product Guarantee
GE offers a comprehensive product guarantee for the IC698PSA100E. The company stands firmly behind the quality of this power supply module, ensuring that it is free from defects in materials and workmanship. In the event of any quality issues within the warranty period, GE will promptly provide repair or replacement services. Additionally, GE’s team of technical experts is available to offer support. They can assist customers with installation guidance, operational advice, and any other technical concerns related to the IC698PSA100E. This commitment to quality and customer service reflects GE’s confidence in the reliability and performance of the module, giving customers peace of mind when using it in their industrial automation applications.
