Product Overview
The GE IC800SSI228RD2 – EE is a high – performance servo motor controller from General Electric, a renowned name in the industrial automation domain. As part of the S2K series, it is specifically engineered to drive MTR series motors operating at 230V AC. This controller is a cornerstone in industrial automation setups, offering precise control over servo motors, which is crucial for achieving high – quality and efficient production processes.
It plays a pivotal role in accurately regulating the speed and position of the connected motors. By leveraging advanced control algorithms, the GE IC800SSI228RD2 – EE can translate input commands into smooth and accurate motor movements. In industrial applications, it interfaces with various sensors and actuators, receiving real – time feedback to adjust the motor’s operation accordingly. This ensures that production lines run with minimal errors, enhancing overall productivity and product quality. Whether in a high – speed manufacturing environment or a precision – oriented production process, this controller is designed to meet the stringent demands of modern industrial automation.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC800SSI228RD2 – EE |
| Manufacturer | GE |
| Product Type | Servo Motor Controller |
| Input Voltage | 230V AC |
| Output Current | 28 Amp |
| Control Type | Servo Control for MTR Series Motors |
| Communication Protocol | DeviceNet |
| Position Control Accuracy | High – precision, with minimal error |
| Speed Control Range | Wide range for flexible operation |
| Operating Temperature | – 10°C to 50°C |
| Mounting Method | Suitable for standard industrial mounting, e.g., DIN – rail mount |
| Input/Output Interfaces | Discrete and analog I/O for versatile connections |
Main Features and Advantages
High – Precision Control
The GE IC800SSI228RD2 – EE excels in delivering high – precision position and speed control. Its advanced control algorithms enable it to precisely regulate the movement of MTR series motors, minimizing errors and ensuring consistent performance. In applications such as precision machining, the controller can accurately position the cutting tools, resulting in high – quality finished products. This level of precision is also beneficial in assembly lines, where parts need to be placed with utmost accuracy.
Versatile Input/Output Functionality
Equipped with a variety of input/output interfaces, this controller can easily integrate with different types of sensors and actuators. The discrete input/output ports are useful for handling digital signals from switches and relays, while the analog input/output ports can interface with sensors that provide continuous data, such as temperature and pressure sensors. Additionally, its clock function allows for time – based control operations, adding to its versatility in different industrial scenarios.
Robust Communication Capabilities
With support for the DeviceNet communication protocol, the GE IC800SSI228RD2 – EE can communicate effectively with other devices in an industrial network. This enables seamless data exchange and coordination between the controller, motors, and other components in the automation system. It allows for remote monitoring and control, enhancing the overall flexibility and manageability of the production process. For example, operators can monitor the motor’s performance and adjust its settings from a central control station, improving operational efficiency.
Application Field
Manufacturing Industry
In manufacturing, the GE IC800SSI228RD2 – EE is widely used in automated production lines. In automotive manufacturing, it controls the servo motors that operate robotic arms for tasks like welding, painting, and assembling parts. The controller’s high – precision control ensures that each operation is carried out accurately, contributing to the production of high – quality vehicles. In electronics manufacturing, it is used to control the movement of pick – and – place machines, which place tiny electronic components on circuit boards with extreme precision.
Packaging Industry
In the packaging industry, this controller is employed to control the motors that drive packaging machinery. It ensures that the packaging materials are precisely fed, cut, and sealed. For instance, in a food packaging plant, the GE IC800SSI228RD2 – EE controls the motors that move food products along the conveyor belts, adjust the speed of filling machines, and seal the packages. Its ability to provide consistent speed and position control helps maintain the quality and integrity of the packaged products.
Material Handling
In material handling applications, such as in warehouses and distribution centers, the GE IC800SSI228RD2 – EE is used to control the motors of automated guided vehicles (AGVs) and conveyor systems. It enables the AGVs to move precisely along their designated paths, picking up and delivering goods accurately. In conveyor systems, the controller adjusts the speed of the belts to ensure smooth and efficient movement of materials, improving overall logistics operations.
Related Products
- IC800SSI104D2: This is another servo controller in the S2K series. It has a different current rating compared to the IC800SSI228RD2 – EE, making it suitable for applications with lower power requirements. It can be used in less demanding industrial setups where cost – effectiveness and basic servo control capabilities are sufficient.
- IC800SSI407RD2 – EE: Also a servo motor controller, it might offer different features like additional communication options or enhanced feedback mechanisms. It could be an upgrade option for users who require more advanced functionality than what the IC800SSI228RD2 – EE provides, such as more complex motion control profiles.
- MTR – 3S and MTR – 3N series motors: These are motors that can be paired with the IC800SSI228RD2 – EE controller. They have different torque and speed characteristics, allowing users to select the appropriate motor – controller combination based on the specific requirements of their industrial application, whether it’s for high – torque or high – speed operations.
- Motion Developer software: This software is used to configure and program the S2K series controllers, including the IC800SSI228RD2 – EE. It provides users with an intuitive interface to set up motor parameters, define motion profiles, and monitor the performance of the controller – motor system.
- GE 90 – 30 series PLC: Can be integrated with the IC800SSI228RD2 – EE in more complex industrial automation systems. The PLC can act as a central control unit, coordinating the operations of the servo controller and other devices in the system, enabling more comprehensive control and automation of industrial processes.
Installation and Maintenance
Pre – installation preparation: Before installing the GE IC800SSI228RD2 – EE, carefully check the installation environment. Ensure that the ambient temperature is within the specified – 10°C to 50°C range and that there is no excessive humidity or dust. Verify that the 230V AC power supply is stable and properly grounded. Mount the controller securely, following the recommended DIN – rail mounting method. Connect the communication cables for DeviceNet according to the wiring diagram, ensuring proper shielding to prevent interference.
Maintenance recommendations: Regularly inspect the GE IC800SSI228RD2 – EE for any signs of physical damage, such as cracks in the casing or loose connections. Clean the controller periodically to remove dust that could affect its performance. Monitor the motor’s performance data, such as speed and position accuracy, through the controller’s interface. If any anomalies are detected, check the motor – controller connections, and if necessary, recalibrate the controller using the Motion Developer software. Replace any worn – out components promptly to ensure continuous and reliable operation.
Product Guarantee
GE stands firmly behind the quality of the GE IC800SSI228RD2 – EE servo motor controller. The product undergoes rigorous testing during the manufacturing process to meet high – quality standards. GE offers a standard warranty period, during which any defects in materials or workmanship will be rectified free of charge. Their experienced technical support team is available to assist customers with installation, configuration, and any technical issues that may arise during the product’s lifespan. Whether it’s a problem with the controller’s communication, control accuracy, or compatibility with other devices, GE is committed to providing timely and effective solutions. This gives customers confidence in their investment and ensures the long – term, reliable operation of the IC800SSI228RD2 – EE in various industrial applications.
