Professional Product Description: GE IS200TBCIH2B

Detailed Parameter Table

IS200DSPXH1D

Product Introduction

The IS200TBCIH2B is an advanced turbine bypass control interface module developed by GE for its Mark VIe Speedtronic control system. This module serves as the critical interface between the turbine control system and bypass valves, handling both analog and digital signals with exceptional precision.

Designed specifically for steam turbine applications, the IS200TBCIH2B provides comprehensive I/O capabilities including 12 analog inputs, 16 digital inputs, 8 analog outputs, and 12 digital outputs. This extensive configuration allows the module to monitor numerous turbine parameters while controlling various actuators and valves throughout the steam path.

The IS200TBCIH2B plays a vital role in modern turbine control architectures by providing reliable signal processing, precise control outputs, and seamless communication with other system components. Its rugged design ensures reliable operation in the harsh environments typical of power generation facilities, making it an essential component for ensuring efficient and safe turbine operation.

Core Advantages and Technical Highlights

Enhanced I/O Capacity: The IS200TBCIH2B offers expanded I/O capabilities compared to previous generations, with 12 analog inputs and 16 digital inputs providing greater flexibility for complex bypass control applications.

High-Speed Signal Processing: With response times of less than 1ms for analog signals and 0.5ms for digital signals, the IS200TBCIH2B ensures rapid processing of critical turbine data. This speed is essential for maintaining stable turbine operation during transient conditions.

Flexible Output Configuration: The module’s digital outputs can be configured as either relays or solid-state devices, providing flexibility to match various field device requirements. This versatility makes the IS200TBCIH2B suitable for a wide range of control applications.

Advanced Diagnostics: The IS200TBCIH2B incorporates comprehensive diagnostic features that continuously monitor module health and signal integrity. This allows for proactive maintenance and reduces the risk of unexpected failures.

Robust Design: With high isolation ratings and a wide operating temperature range, the IS200TBCIH2B is built to withstand the harsh environmental conditions found in power generation facilities.

Typical Application Scenarios

In combined-cycle power plants, the IS200TBCIH2B manages the bypass systems that regulate steam flow between the gas turbine, heat recovery steam generator (HRSG), and steam turbine. It precisely controls valve positions to maintain optimal steam parameters during startup, shutdown, and load changes.

For example, during turbine startup, the IS200TBCIH2B processes signals from temperature and pressure sensors to ensure proper warm-up sequences are followed. It controls the opening of bypass valves based on these readings, preventing thermal shock to turbine components.

In coal-fired power plants, the IS200TBCIH2B plays a crucial role in load rejection scenarios. When the grid suddenly reduces its power demand, the module rapidly opens bypass valves to divert excess steam away from the turbine, preventing overspeed and potential damage.

The module also integrates with the plant’s safety systems, monitoring critical parameters and initiating protective actions when necessary. This includes emergency shutdowns in response to abnormal conditions such as excessive vibration or bearing temperature excursions.

Related Model Recommendations

IS200TBCIH1C – Previous generation bypass control interface module with slightly fewer I/O channels.

IS200TBAOH1B – Turbine bypass control analog output module that can expand the output capabilities of the IS200TBCIH2B.

IS200STCIH6A – Steam turbine control interface module that works with the IS200TBCIH2B in comprehensive control systems.

IS200STTCH2A – Steam turbine trip control module that pairs with the IS200TBCIH2B for protection functions.

IS200EACFG2A – Configuration module that stores the IS200TBCIH2B’s program and parameters.

IS200EHBQG2A – Backplane module that provides power and communication for the IS200TBCIH2B.

IS200JGNDG1A – Grounding module that enhances signal integrity for the IS200TBCIH2B.

IS200IVFBG1A – Voltage/frequency feedback module that supplies grid parameters to the IS200TBCIH2B.

IS200DSPXH1D

Installation, Commissioning and Maintenance Instructions

Installation preparation: Before installing the IS200TBCIH2B, ensure the Mark VIe backplane is powered down. Verify that the operating environment meets the module’s specifications (-40°C to +85°C). Use ESD-protective equipment during handling. Confirm that the backplane slot is compatible with interface modules and that the 24VDC power supply meets the required specifications (±10% tolerance). Use shielded twisted-pair cables for all signal connections and ensure proper grounding according to GE guidelines.

Commissioning: After physical installation, configure the IS200TBCIH2B using GE’s ToolboxST software. Set up the input channels for the specific sensors being used, configure output parameters, and verify communication with the main controller. Perform functional tests to ensure all I/O channels operate correctly and that the module properly processes and transmits turbine control signals.

Maintenance suggestions: Regularly monitor the IS200TBCIH2B status through the Mark VIe HMI. Review diagnostic information to identify any potential issues with the module or connected sensors. Perform periodic calibration of analog channels to maintain measurement accuracy. Keep firmware updated to the latest version recommended by GE. If a failure occurs, follow proper lockout/tagout procedures before replacement. Always use GE-approved replacement parts to ensure system compatibility and reliability.

Service and Guarantee Commitment

The IS200TBCIH2B comes with a 2-year standard warranty from GE, covering defects in materials and workmanship. GE’s global service network provides comprehensive support for the IS200TBCIH2B, including technical assistance, repair services, and spare parts availability.

GE offers 24/7 technical support for the IS200TBCIH2B, with specialists available to assist with installation, configuration, and troubleshooting. Customers have access to GE’s extensive library of technical documentation, including user manuals, application notes, and best practices guides for turbine control systems.

For mission-critical applications, GE provides extended warranty options and preventive maintenance services to ensure the IS200TBCIH2B operates at peak performance throughout its service life. GE’s commitment to quality ensures that the IS200TBCIH2B will provide reliable performance in even the most demanding power generation environments.
