GE IS210BPPBH2C Mark VIe Power Supply Module

Detailed Parameter Table

Parameter Name | Parameter Value ———|——– Product Model | **IS210BPPBH2C** Manufacturer | GE General Electric Product Category | Industrial Power Supply Module Series | Mark VIe (Turbine Control System) Input Voltage | 110/220V AC (Auto-Ranging), 125/250V DC Output Voltage | 24V DC (Regulated) Output Current | 15A (Continuous), 25A (Peak) Efficiency | ≥90% @ Full Load Protection Features | Over-Voltage, Over-Current, Short-Circuit, Over-Temperature Operating Temperature | 0°C to 60°C Storage Temperature | -40°C to 85°C Protection Rating | IP20 (Module), NEMA 12 (Chassis Mount) Physical Dimensions | 150mm × 110mm × 35mm Certifications | UL 508, CE, CSA

Product Introduction

The **GE IS210BPPBH2C** is a high-reliability power supply module designed exclusively for GE’s Mark VIe turbine control system, serving as the energy backbone for critical control components. As a core power management solution in GE’s industrial portfolio, the **GE IS210BPPBH2C** delivers stable, regulated 24V DC power to Mark VIe control modules (such as the **IS210MACCH1A**), I/O modules, and safety systems—ensuring uninterrupted operation of turbine control functions. Its auto-ranging input design and robust protection features make it adaptable to diverse power grid conditions, a key requirement for power generation facilities worldwide.

What sets the **GE IS210BPPBH2C** apart is its seamless integration with the Mark VIe ecosystem and focus on cost-effective turbine control solutions. Leveraging GE’s expertise in power electronics and industrial system design, the **GE IS210BPPBH2C** maintains precise voltage regulation even during load fluctuations, a common scenario during turbine start-up and load changes. By providing consistent power, it directly enhances the reliability of the entire control system, reducing the risk of unplanned turbine downtime and associated revenue losses—ideal for mid-sized generation facilities.

Core Advantages and Technical Highlights

Dual-Input Versatility: The **IS210BPPBH2C** supports both AC (110/220V) and DC (125/250V) input with auto-ranging capability, eliminating the need for manual configuration. This flexibility allows deployment in power plants with varying primary power sources, from standard AC grids to backup DC systems—ensuring continuous power supply during grid transitions or outages.

Stable Regulated Output: Delivering 24V DC with ±0.5V precision, the **IS210BPPBH2C** maintains consistent power to Mark VIe components even under 15A continuous load. Its advanced switching topology ensures minimal voltage ripple (<50mV), protecting sensitive electronics in control modules like the **IS210MACCH1A** from signal interference and performance degradation.

Comprehensive Protection Mechanisms: The **IS210BPPBH2C** integrates multi-layer protection, including over-voltage (28V DC cutoff), over-current (25A peak limit), short-circuit, and over-temperature safeguards. In fault conditions, it triggers rapid shutdown or current limiting, preventing damage to both the power supply and connected control components—critical for avoiding cascading system failures.

High Efficiency and Thermal Performance: With ≥90% efficiency at full load, the **IS210BPPBH2C** minimizes energy waste and heat generation. Its passive heat dissipation design, combined with high-conductivity housing, ensures stable operation at ambient temperatures up to 60°C—eliminating fan-related maintenance and failure risks in turbine enclosures.

IS210BPPBH2C

Typical Application Scenarios

In gas and steam turbine control systems, the **IS210BPPBH2C** acts as the primary power source for the Mark VIe control cabinet. It supplies regulated 24V DC to the **IS210MACCH1A** control module, I/O modules, and HMI interfaces, ensuring consistent performance during turbine start-up, load changes, and normal operation. Its auto-ranging input is particularly valuable in regions with unstable AC grids, where it adapts to voltage fluctuations without disrupting control functions—ideal for mid-sized turbines (50-150 MW).

For small to mid-sized hydroelectric power plants, the **IS210BPPBH2C** integrates with both main AC power and backup DC systems (from batteries), providing redundant power to turbine governor controls. During grid outages, it seamlessly switches to DC input, maintaining power to safety systems and control modules—ensuring the turbine can be safely shut down or transitioned to island mode, protecting equipment and avoiding water management issues at dams.

In industrial cogeneration facilities, the **IS210BPPBH2C** supports the Mark VIe system controlling on-site turbines, powering control components that balance electrical output and thermal energy supply. Its 15A continuous output easily handles the power demands of compact control systems, while over-current and short-circuit protection safeguards against electrical faults from industrial machinery—preventing disruptions to both the turbine system and the facility’s internal power grid.

Related Model Recommendations

**IS210BPPBH1C**: 10A variant of **IS210BPPBH2C**, ideal for small-scale Mark VIe systems with lower power demands, paired with compact control modules.

**IS210MACCH1A**: Mark VIe control module directly powered by **IS210BPPBH2C**, forming the core control-power combination for mid-sized turbines.

**IS210BPPBH2C-R**: Redundant power supply kit including two **IS210BPPBH2C** modules and a redundancy controller, ensuring 100% power availability for critical systems.

**IS210MCPMG1A**: Power monitoring module that works with **IS210BPPBH2C** to track voltage, current, and efficiency, enabling predictive maintenance.

**IS210IAIH1A**: Mark VIe analog input module, receiving stable power from **IS210BPPBH2C** to collect turbine sensor data.

**IS210BPPBH3C**: 20A high-capacity variant of **IS210BPPBH2C**, designed for large Mark VIe systems with multiple control and I/O modules.

**IC754VSF12CTD-JH**: GE VersaMax HMI, powered by **IS210BPPBH2C** to display real-time turbine data and enable operator control.

IS210BPPBH2C

Installation, Commissioning and Maintenance Instructions

Installation preparation: Before installing **IS210BPPBH2C**, disconnect all primary power sources and verify the input voltage matches the plant’s supply (AC or DC). Ensure the Mark VIe chassis has a dedicated power slot and that wiring is sized for 15A continuous current (16 AWG minimum for DC outputs). Use insulated tools to connect input/output terminals, and secure the module with mounting screws to prevent vibration-induced loose connections. Label all wires clearly to avoid polarity errors, which could damage connected modules.

Maintenance suggestions: Conduct monthly visual inspections of **IS210BPPBH2C**, checking for loose terminals, discolored components, and dust accumulation—clean ventilation slots with compressed air (max 0.3 MPa). Measure output voltage quarterly using a calibrated multimeter to ensure it remains within 23.5-24.5V DC. Replace the module if efficiency drops below 85% or if protection alarms trigger frequently. Avoid exposing **IS210BPPBH2C** to direct steam or oil, and ensure the control cabinet has adequate ventilation to stay within the operating temperature range.

Service and Guarantee Commitment

GE General Electric provides a 30-month quality guarantee for the **IS210BPPBH2C**, covering manufacturing defects, output regulation failures, and protection system malfunctions under normal operation. Our global technical support team offers 24/7 assistance, including remote troubleshooting, installation guidance, and firmware updates. Customers receive access to GE’s Power Supply Configuration Tool and technical documentation for the **IS210BPPBH2C** throughout the guarantee period. For priority service clients, we ensure 48-hour replacement of defective modules to minimize turbine control system downtime—reflecting our commitment to reliable power generation infrastructure.
