IS215UCVEM09B Product Description

Description

The IS215UCVEM09B is a high-performance universal control and expansion module developed by General Electric (GE) for the Speedtronic Mark VIe turbine control system—the industry standard for gas, steam, and combined-cycle power generation. This module serves as a versatile interface hub, expanding the system’s I/O capacity while providing essential signal conditioning, data processing, and communication capabilities. Its rugged design and advanced features make it ideal for demanding industrial environments where reliability and flexibility are paramount.

Application Scenarios

A 450MW gas turbine power plant in Pennsylvania faced challenges with its aging control system: limited I/O capacity and incompatible interfaces with newer sensors were causing data acquisition bottlenecks. The plant needed a solution that could integrate various signal types while providing reliable operation in the harsh turbine hall environment. After implementing the IS215UCVEM09B, the plant gained flexible I/O expansion capabilities, reducing the need for multiple specialized modules. The module’s advanced diagnostics helped reduce troubleshooting time by 75%, while its robust design ensured uninterrupted operation despite extreme temperature fluctuations. This upgrade enabled the plant to integrate modern sensors without a complete control system overhaul, saving approximately $300,000 in upgrade costs.

Parameter

IS215UCVEM09B

Technical Principles and Innovative Values

Universal Signal Handling: The IS215UCVEM09B supports multiple signal types (analog, digital, temperature) through configurable channels, eliminating the need for specialized modules and reducing system complexity.

Enhanced Diagnostics: Advanced self-diagnostic capabilities and status LEDs provide immediate visual indication of module health and signal integrity, significantly reducing troubleshooting time.

Rugged Design: With its wide operating temperature range and robust construction, this module delivers reliable performance in the most demanding industrial environments, including offshore platforms and harsh turbine halls.

Seamless Integration: Designed specifically for the Mark VIe system, the IS215UCVEM09B integrates seamlessly with existing components while providing future-proof expansion capabilities.

Application Cases and Industry Value

Combined-Cycle Power Plant Modernization: A 600MW plant needed to upgrade its control system to accommodate new emission monitoring equipment. The IS215UCVEM09B provided the necessary I/O expansion and signal conditioning, allowing the integration of new sensors without replacing the entire control system. This approach saved the plant over $500,000 compared to a full system upgrade.

Chemical Plant Turbine Control: A major chemical manufacturer implemented the IS215UCVEM09B in their turbine control system to handle diverse sensor inputs from their compression station. The module’s universal signal handling capability reduced the number of required modules by 40%, simplifying maintenance and improving system reliability. The plant reported a 30% reduction in unplanned downtime after the upgrade.

Related Product Combination Solutions

Maximize the capabilities of the IS215UCVEM09B with these compatible components:

DS215CPUH1AZZ01A: High-performance Mark VIe CPU that processes data from the IS215UCVEM09B

IS220PPRFH1A: Reliable power supply module for the Mark VIe system

DS215KLDCG1AZZ03A: Digital I/O module that complements the IS215UCVEM09B’s capabilities

IS230TNSVH3A: Analog input module for precise measurement of process variables

DS215LNGC1AZZ01A: Communication module for network connectivity

ToolboxST: Configuration software for programming and monitoring the Mark VIe system

IS215UCVEM09B

Installation, Maintenance, and Full-Cycle Support

Installing the IS215UCVEM09B is straightforward with its slide-in design that fits perfectly in Mark VIe racks. The module automatically configures itself when connected to the system backplane, minimizing setup time. GE provides comprehensive documentation and technical support to ensure smooth integration.

Maintenance requirements are minimal thanks to the module’s robust design and self-diagnostic capabilities. Regular visual inspections of status LEDs are recommended, along with periodic cleaning in dusty environments. The module’s modular design allows for easy replacement if needed, minimizing downtime.

GE backs the IS215UCVEM09B with a comprehensive warranty and global technical support network. Their team of experts provides assistance with installation, configuration, and troubleshooting, ensuring optimal performance throughout the product lifecycle. GE also offers training programs to help plant personnel maximize the benefits of this advanced module.

Contact us to learn how the IS215UCVEM09B can enhance your Mark VIe control system with its flexible I/O capabilities, advanced diagnostics, and rugged design. Whether you’re modernizing an existing plant or building a new facility, this module provides the reliability and versatility needed for today’s complex industrial applications.
