Honeywell 2MLP-ACF2

Description

Honeywell 2MLP – ACF2 Product Description

1. Detailed Parameter Table

Honeywell 2MLP-ACF2

2. Product Introduction

The Honeywell 2MLP – ACF2 is a high – efficiency power supply module designed to meet the power conversion needs of various industrial and automation applications. Engineered with precision, this module is capable of handling a wide input voltage range, making it suitable for use in different regions around the world. It converts the incoming alternating current (AC) to a stable direct current (DC) output, ensuring reliable power delivery to connected devices.

This power supply module is a popular choice for industrial control systems, process control units, and automation platforms. Its ability to provide a consistent 5 VDC output at 6 A makes it suitable for powering a variety of electronic components, such as microcontrollers, sensors, and actuators. Whether it’s in a factory setting, a power generation plant, or a building automation system, the 2MLP – ACF2 can be relied upon to deliver the necessary power.

3. Core Advantages and Technical Highlights

3.1 High – Efficiency Power Conversion

The 2MLP – ACF2 is engineered to achieve an efficiency of over 85%. This high efficiency ensures that a large portion of the input power is converted into useful output power, minimizing power losses in the form of heat. In industrial applications where energy consumption is a concern, this power – saving feature can lead to significant cost savings over time. Additionally, reduced heat generation means less stress on the internal components of the power supply module, contributing to its long – term reliability.

3.2 Wide Input Voltage Range

With an input voltage range of 100 – 240 VAC, the 2MLP – ACF2 can be used in different countries and regions without the need for additional voltage converters. This makes it an ideal choice for global industrial applications. Whether the input power source is 110 VAC in the United States or 220 VAC in Europe, the power supply module can adapt and provide a stable 5 VDC output. This flexibility simplifies the design and deployment of industrial control systems, as engineers do not have to worry about customizing the power supply for different input voltages.

3.3 Compact and Durable Design

Measuring 7.5 x 3.5 x 4 inches and weighing 2.5 lbs, the 2MLP – ACF2 has a compact form factor that allows for easy integration into various industrial setups. Its small size does not compromise on performance or durability. The module is built with high – quality materials and components, ensuring it can withstand the harsh operating conditions often found in industrial environments. Whether it’s exposed to vibrations, temperature variations, or electrical interference, the 2MLP – ACF2 is designed to continue operating reliably.

3.4 Passive Cooling

The power supply module utilizes passive cooling, which means it does not require a fan or other active cooling components. This not only reduces the complexity of the design but also eliminates the risk of fan – related failures, such as fan motor burnout or clogging of the fan blades with dust. Passive cooling also makes the 2MLP – ACF2 a quieter option, which can be beneficial in applications where noise is a concern, such as in control rooms or near sensitive equipment.

3.5 Protection Features

The 2MLP – ACF2 is equipped with overvoltage protection, overcurrent protection, and short – circuit protection mechanisms. These protection features safeguard the connected devices from potential damage due to abnormal power conditions. In the event of an overvoltage situation, the module will limit the output voltage to prevent damage to the sensitive electronics. Similarly, if an overcurrent or short – circuit occurs, the protection circuitry will activate to isolate the power supply and prevent further damage. This ensures the safety and reliability of the overall system.

4. Typical Application Scenarios

4.1 Industrial Automation Systems

In industrial automation, the 2MLP – ACF2 can be used to power Programmable Logic Controllers (PLCs), sensors, and actuators. For example, in a manufacturing plant, it can supply power to the PLC that controls the operation of conveyor belts, robotic arms, and other automated machinery. The stable 5 VDC output ensures that the PLC functions properly, and the sensors accurately detect the position and status of the products on the production line. The actuators, such as solenoid valves and motors, can also be powered by the 2MLP – ACF2 to perform their respective tasks, such as opening and closing valves or moving mechanical parts.

4.2 Building Automation Systems

In building automation, the power supply module can be used to power various components, including building management system (BMS) controllers, temperature sensors, and lighting control modules. For instance, it can provide power to the BMS controller that monitors and controls the heating, ventilation, and air – conditioning (HVAC) system in a commercial building. The temperature sensors, which are crucial for maintaining a comfortable indoor environment, can also be powered by the 2MLP – ACF2. Additionally, it can supply power to the lighting control modules that regulate the brightness and operation of the lights in different areas of the building, contributing to energy savings.

4.3 Process Control Systems

In process control systems, such as those used in chemical plants, oil refineries, and water treatment facilities, the 2MLP – ACF2 can be used to power the control panels and instrumentation. The control panels, which house the controllers and monitors for the process, require a stable power supply to ensure accurate control of the process variables. The instrumentation, such as flow meters, pressure sensors, and level sensors, also need a reliable power source to function properly. The 2MLP – ACF2’s ability to provide a consistent 5 VDC output makes it an ideal choice for powering these components in process control applications.

Honeywell 2MLP-ACF2

5. Related Model Recommendations

5.1 Honeywell 2MLP – AC23

Differences: The 2MLP – AC23 has a rated input voltage of 200 – 240 VAC, which is a more narrow range compared to the 2MLP – ACF2’s 100 – 240 VAC. It has an output current of 8.5 A, higher than the 2MLP – ACF2’s 6 A. The efficiency of the 2MLP – AC23 is 65% or more, which is lower than the 2MLP – ACF2’s > 85%.

Suitable Applications: The 2MLP – AC23 may be more suitable for applications where a higher output current is required and the input voltage is within its specified range. For example, in some industrial applications where there are power – hungry components that need a stable 5 VDC supply with a higher current capacity.

5.2 Honeywell STT850 (with conductivity option)

Differences: The STT850 is a smart transmitter with a conductivity option, which is a completely different product category compared to the 2MLP – ACF2 power supply module. The STT850 is used for conductivity measurement and pre – processing of sensor signals, while the 2MLP – ACF2 is for power conversion.

How They Can Be Used Together: In an industrial process where conductivity measurement is important, the 2MLP – ACF2 can power the STT850. The stable power supply from the 2MLP – ACF2 ensures that the STT850 functions accurately in measuring and transmitting conductivity data.

5.3 Honeywell LG1093AC01

Differences: The LG1093AC01 is an advanced process controller, while the 2MLP – ACF2 is a power supply module. The LG1093AC01 is used for closed – loop control of complex processes, and the 2MLP – ACF2 provides the power for the controller and other components in the process control system.

How They Can Be Used Together: The 2MLP – ACF2 can supply power to the LG1093AC01, enabling it to perform its control functions. The controller can then use the power – supplied sensors and actuators (also potentially powered by the 2MLP – ACF2) to control the process based on the measured data.

6. Installation, Commissioning and Maintenance Instructions

6.1 Installation Preparation

Mount the 2MLP – ACF2 in a location that is free from excessive heat, moisture, and vibration. Ensure that the mounting surface is flat and secure.

Connect the input power cable to the appropriate AC power source within the specified voltage range (100 – 240 VAC). Use a cable with the appropriate gauge to handle the input current (1.5 A).

Connect the output cables to the devices that require power. Make sure the connections are tight and secure to prevent electrical arcing or disconnection.

Verify that the installation environment meets the requirements for the certifications (CE, FCC, UL) of the 2MLP – ACF2.

6.2 Commissioning and Maintenance

Before powering on the 2MLP – ACF2, double – check all the connections to ensure they are correct.

Power on the module and use a multimeter to measure the output voltage. It should be 5 VDC within the specified tolerance.

Monitor the module during initial operation for any signs of overheating, abnormal noise, or incorrect output voltage.

Periodically inspect the module for any signs of physical damage, such as cracks or loose connections. Check the ventilation openings (if applicable) for any blockages.

Although the 2MLP – ACF2 has a passive cooling system, ensure that the surrounding area is well – ventilated to aid in heat dissipation.

If there are any issues with the power supply module, refer to the Honeywell technical documentation or contact their support team for troubleshooting assistance.

7. Service and Guarantee Commitment

The Honeywell 2MLP – ACF2 comes with a 12 – month warranty against manufacturing defects. Honeywell’s dedicated support team is available to provide technical assistance and answer any questions regarding the product. In the event of a failure within the warranty period, Honeywell will repair or replace the module free of charge, subject to the terms and conditions of the warranty.
