NI SCXI-1300

Description

NI SCXI-1300 Product Description

Detailed Parameter Table

NI SCXI-1300

Product Introduction

The NI SCXI-1300 is a general-purpose terminal block designed to provide a convenient and secure connection interface between NI SCXI modules and external signals. As an essential accessory in the SCXI system, it simplifies the wiring process, ensuring reliable signal transmission between various sensors, actuators, and other external devices and the corresponding SCXI modules.

This terminal block features a 50-pin D-sub connector that mates perfectly with compatible SCXI modules, along with 50 screw terminals for easy connection of external wires. Its robust construction and thoughtful design make it suitable for a wide range of industrial, laboratory, and research applications where efficient and secure signal connectivity is required.

Core Advantages and Technical Highlights

Versatile Compatibility: The SCXI-1300 is compatible with a wide range of SCXI modules, including SCXI-112x, SCXI-114x, SCXI-116x, and many others. This versatility allows it to be integrated into various SCXI systems, eliminating the need for multiple types of terminal blocks and reducing inventory complexity. Whether used with analog input modules, digital I/O modules, or other specialized SCXI modules, the SCXI-1300 provides a consistent and reliable connection solution.

Secure and Reliable Connections: Equipped with high-quality screw terminals, the SCXI-1300 ensures secure wire connections. The nickel-plated brass terminals resist corrosion and provide excellent electrical conductivity, minimizing signal loss and ensuring stable signal transmission. The screw terminals can accommodate a range of wire sizes (up to 16 AWG for power and 22 AWG for signals), making it suitable for different wiring requirements in various applications. This secure connection feature is crucial in environments where vibration or temperature fluctuations might otherwise loosen connections.

Simplified Wiring and Maintenance: The SCXI-1300’s design simplifies the wiring process, allowing engineers and technicians to quickly connect and disconnect external signals. The clear labeling of terminals corresponds to the pins of the SCXI module’s connector, reducing the risk of wiring errors. This ease of wiring not only speeds up system setup but also simplifies maintenance and troubleshooting. When modules need to be replaced or reconfigured, the terminal block can remain wired, saving time and effort in rewiring.

Durable Construction: Built to withstand industrial environments, the SCXI-1300 has a rugged housing that protects internal components from dust, moisture, and physical damage. It operates within a temperature range of 0 °C to 55 °C and can be stored at temperatures from -20 °C to 70 °C, ensuring reliable performance in various climatic conditions. This durability makes it suitable for use in both laboratory settings and harsh industrial environments.

Typical Application Scenarios

Industrial Data Acquisition Systems: In industrial data acquisition systems, the SCXI-1300 is used to connect SCXI modules to various sensors and transducers. For example, in a manufacturing plant, it can interface an SCXI-1125 analog input module with temperature sensors, pressure transducers, and flow meters distributed throughout the production line. The terminal block provides a secure connection point, ensuring that the signals from these sensors are accurately transmitted to the module for processing and analysis. This enables real-time monitoring of industrial processes and helps in maintaining quality control.

Laboratory Testing Setups: In laboratory environments, the SCXI-1300 facilitates the connection between SCXI modules and experimental equipment. For instance, in a physics lab, it can connect an SCXI-1140 digital I/O module to various switches, relays, and detectors used in experiments. The easy wiring and secure connections provided by the terminal block allow researchers to quickly set up and modify experimental configurations, saving valuable time and ensuring accurate data collection.

Process Control Systems: In process control systems, the SCXI-1300 plays a key role in connecting SCXI modules to actuators and control devices. For example, in a chemical processing plant, it can link an SCXI-1160 relay module to valves, pumps, and heaters. This allows the control system to send signals to these devices, regulating the chemical processes as needed. The reliable connections ensure that control signals are transmitted accurately, preventing process disruptions and ensuring safe operation.

NI SCXI-1300

Related Model Recommendations

NI SCXI-1322: A terminal block specifically designed for SCXI-1122 and SCXI-1124 modules. It offers similar features to the SCXI-1300 but is optimized for the 16-channel analog input modules, providing a more tailored connection solution for applications using these specific modules.

NI SCXI-1349: A terminal block with built-in signal conditioning components, suitable for use with thermocouple modules such as the SCXI-1180. It provides cold-junction compensation and filtering, enhancing the accuracy of temperature measurements. For applications involving thermocouple sensors, the SCXI-1349 is a better choice than the SCXI-1300.

NI SCXI-1000 Chassis: The SCXI-1000 is a 10-slot chassis that houses SCXI modules and provides power and communication backplane. When using the SCXI-1300 terminal block with SCXI modules, the SCXI-1000 chassis forms the core of the SCXI system, allowing multiple modules to be integrated and controlled as a single unit.

Installation, Commissioning and Maintenance Instructions

Installation Preparation: Before installing the SCXI-1300, ensure that the compatible SCXI module is properly installed in the SCXI chassis. Power off the chassis to avoid electrical hazards. Gather the necessary tools, such as a screwdriver for tightening the terminal screws, and the appropriate wires for connecting external signals.

Commissioning: Align the 50-pin D-sub connector of the SCXI-1300 with the corresponding connector on the SCXI module and firmly press to mate them. Secure the connection using the screws on the connector to prevent accidental disconnection. Connect the external wires to the screw terminals of the SCXI-1300, ensuring that each wire is securely fastened and that the correct terminal is used according to the wiring diagram. Power on the SCXI chassis and verify that signals are being transmitted correctly using NI Measurement & Automation Explorer (MAX) or other monitoring software.

Maintenance Suggestions: Regularly inspect the SCXI-1300 for loose connections, corrosion on the terminals, or physical damage. Tighten any loose terminal screws to ensure secure wire connections. If corrosion is found, clean the terminals with a dry cloth or appropriate cleaning agent. Avoid exposing the terminal block to excessive moisture, dust, or extreme temperatures. When disconnecting wires, loosen the terminal screws completely to prevent damage to the wires or terminals. Periodically check the compatibility of the terminal block with the connected SCXI module and ensure that the wiring is correct to maintain reliable signal transmission.

Service and Guarantee Commitment

NI provides a standard warranty for the SCXI-1300 terminal block, typically covering manufacturing defects for a period of 1 year from the date of purchase. Technical support is available through NI’s official channels, including online resources, user forums, and direct contact with the support team. In case of any issues with the terminal block, users can refer to the NI documentation, which includes installation guides and troubleshooting tips. If the terminal block is found to be defective within the warranty period, NI will repair or replace it free of charge.
