The PROSOFT ILX56-PBM is a ControlLogix in-chassis communication module designed to facilitate seamless integration between Rockwell Automation’s ControlLogix PLCs and PROFIBUS DP networks. It operates as either a PROFIBUS DPV1 Master (initiating communication with slave devices) or a Multi-Slave (emulating multiple PROFIBUS DP nodes), providing flexible connectivity for industrial automation systems.
Architectural Role
The module is installed in a 1756 ControlLogix chassis (Purdue Model Level 2–3) and acts as a gateway between the PLC’s backplane and the PROFIBUS DP network. It interfaces with:
-
Upstream: ControlLogix controllers (e.g., 1756-L7x) via the chassis backplane, using ControlLogix’s native I/O communication protocol.
-
Downstream: PROFIBUS DP field devices (e.g., Siemens ET200 series, Schneider Lexium drives) via a RS-485 interface, supporting both DPV0 (cyclic data exchange) and DPV1 (acyclic data, alarms, diagnostics) protocols.
Operational Principle
The ILX56-PBM operates on a client-server model (master mode) or peer-to-peer model (slave mode):
-
Master Mode: The module polls PROFIBUS slave devices at configurable intervals (minimum 4 ms), exchanging cyclic I/O data (e.g., process variables, control commands). It also supports DPV1 acyclic services (e.g., parameter read/write, alarm acknowledgment) for device configuration and diagnostics.
-
Slave Mode: The module emulates up to 10 PROFIBUS DP slaves, allowing a PROFIBUS master (e.g., Siemens S7-1500) to read/write data from/to the ControlLogix PLC. This mode is useful for integrating ControlLogix into existing PROFIBUS networks as a “virtual” slave device.
The module uses Add-On Profile (AOP) and Add-On Instructions (AOI) for seamless integration with Studio 5000/RSLogix 5000, enabling users to configure the module and map data tags directly from the PLC programming environment.
Core Technical Specifications
|
Parameter
|
Specification
|
|---|---|
|
Communication Protocols
|
PROFIBUS DP V0/V1 (master/slave), ControlLogix backplane (I/O)
|
|
Master Mode
|
Up to 125 slaves, 5000-byte cyclic I/O data, 9.6 kbps–12 Mbps baud rate
|
|
Slave Mode
|
Emulates 10 slaves, 2440-byte cyclic I/O data, DPV0/DPV1 support
|
|
Data Exchange
|
Cyclic (DPV0) and acyclic (DPV1) data, alarm/diagnostic collection
|
|
Interface
|
RS-485 (PROFIBUS), 1756 backplane (ControlLogix)
|
|
Power Supply
|
450 mA @ 5 VDC (from ControlLogix backplane), 2 mA @ 24 VDC (auxiliary)
|
|
Operating Temperature
|
0°C to +60°C (ambient)
|
|
Protection Rating
|
IP20 (dust-protected, for indoor use)
|
|
Certifications
|
CE, UL/cUL, ATEX (Zone 2), Class I Div 2
|
|
Dimensions
|
Standard 1756 single-slot module (233.35 mm × 160 mm × 41 mm)
|
|
Weight
|
~0.32 kg (0.7 lbs)
|
Customer Value & Operational Benefits
1. Seamless ControlLogix Integration
The ILX56-PBM uses AOP/AOI for Studio 5000/RSLogix 5000, eliminating the need for custom code to map data between the PLC and PROFIBUS network. This reduces commissioning time by up to 50% compared to traditional gateway solutions.
2. Flexible Master/Slave Operation
The module’s ability to operate as a master or slave provides backward compatibility with existing PROFIBUS networks. For example, a ControlLogix PLC can act as a master to control legacy PROFIBUS devices or as a slave to integrate with a Siemens S7 master.
3. High Data Throughput
With a 5000-byte cyclic I/O capacity (master mode) and 12 Mbps baud rate, the module supports high-speed data exchange for demanding applications like process automation (e.g., chemical reactors, power plants) and manufacturing (e.g., robotic assembly lines).
4. Advanced Diagnostics
The module includes PROFIBUS packet capture (via the PLX50 tool) and event logging to troubleshoot communication faults. It also provides real-time status LEDs (e.g., RUN, FB, OK) for quick visual diagnosis of module health.
Field Engineer’s Notes (From the Trenches)
When installing the ILX56-PBM, always verify the PROFIBUS cable termination—use a 120-ohm terminating resistor at both ends of the bus (unless the last device is already terminated). I once spent hours troubleshooting a “no communication” fault only to find the resistor was missing.Check the ControlLogix backplane power—the module draws 450 mA @ 5 VDC from the backplane. Use a multimeter to measure the backplane voltage (should be 4.75–5.25 VDC) before installation. Low voltage can cause the module to reset intermittently.Update the firmware (via ProSoft’s website) after installation—firmware updates often fix bugs and improve compatibility with new PROFIBUS devices. I recommend checking for updates every 6 months, especially if you’re using the module for critical applications.
Real-World Applications
1. Oil & Gas: Pipeline Monitoring
A pipeline operator uses the ILX56-PBM to connect a ControlLogix PLC to PROFIBUS DP flow meters and pressure sensors. The module acts as a master, polling the sensors every 10 ms to collect data on pipeline flow and pressure. This data is sent to the PLC for real-time monitoring and control, ensuring safe and efficient pipeline operation.
2. Manufacturing: Robotic Assembly Line
A car manufacturer uses the ILX56-PBM to integrate a ControlLogix PLC with PROFIBUS DP robotic arms. The module acts as a slave, allowing a Siemens S7 master to send commands to the robots (e.g., “pick part,” “place part”). The ControlLogix PLC processes the commands and sends feedback to the master, ensuring precise robotic movement.
3. Power Generation: Turbine Control
A power plant uses the ILX56-PBM to connect a ControlLogix PLC to PROFIBUS DP turbine governors. The module acts as a master, exchanging data with the governors (e.g., turbine speed, fuel flow) every 5 ms. This data is used to adjust the turbine’s fuel supply, maintaining grid frequency (50/60 Hz) within strict limits.
