Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 1C31116G04 |
| Manufacturer | Westinghouse |
| Product Category | Analog Input Module |
| Operating Voltage | 24V DC |
| Input Channels | 8 channels |
| Input Signal Types | Voltage (0-10V), Current (4-20mA), Temperature (Thermocouples, RTDs) |
| Communication Protocols | Modbus/TCP, PROFIBUS, EtherNet/IP, HART |
| Operating Temperature Range | -20°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (L×W×H) | 175 mm × 120 mm × 60 mm |
| Weight | Approx. 0.5 kg |
| Protection Level | IP65 |
| Certification | API 670, ISO 10817, Eex ib IIC T6/T4 (Explosion-proof) |
Westinghouse 1C31116G04
Product Introduction
The Westinghouse 1C31116G04 is a high-performance analog input module designed for industrial automation systems. It is part of the Westinghouse Ovation series and is engineered to provide precise and reliable signal processing in demanding industrial environments. This module supports 8 channels of analog input, capable of handling various signal types such as voltage, current, and temperature (via thermocouples and RTDs). It features advanced communication capabilities, supporting protocols like Modbus/TCP, PROFIBUS, EtherNet/IP, and HART, ensuring seamless integration with SCADA, DCS, and other control systems.
Core Advantages and Technical Highlights
High-Precision Signal Processing: The 1C31116G04 offers high accuracy (+/- 0.2% of full scale) and supports a wide range of input signals, making it suitable for applications requiring precise measurement and control.
Advanced Communication Capabilities: With integrated Ethernet (10/100 Mbps) and optional RS-232/RS-485 interfaces, the module facilitates easy integration into modern industrial networks.
Robust and Reliable Design: The module is designed to operate reliably in harsh industrial environments, with an operating temperature range of -20°C to +70°C and a storage temperature range of -40°C to +85°C. It also features industrial-grade protection (IP65) against dust and water ingress.
Real-Time Monitoring and Diagnostics: The 1C31116G04 includes built-in pulse detection mechanisms to monitor external line disconnections or short circuits in real-time. It also provides real-time fault diagnosis logs, supporting remote access and data backup to reduce downtime.
Flexible Integration: The module supports flexible installation options, including DIN rail or panel mounting, and is compatible with various industrial controllers.
Westinghouse 1C31116G04
Typical Application Scenarios
The Westinghouse 1C31116G04 is widely used in industries such as power generation, chemical processing, manufacturing, and infrastructure control. In power plants, it monitors critical parameters like shaft displacement and vibration in turbines and boilers. In manufacturing facilities, it integrates into automated production lines to optimize energy efficiency and equipment status monitoring. Its ability to handle multiple signal types and provide precise control makes it essential for high-precision process control applications.
Related Model Recommendations
-
1C31125G02: A digital output module with similar communication capabilities, suitable for applications requiring precise control of actuators and other devices.
-
1C31129G03: An upgraded module with enhanced diagnostic features, ideal for applications requiring advanced monitoring and troubleshooting.
-
1C31124G01: A digital input/output module offering versatile control options for industrial automation.
-
1C31116G03: A variant with additional features such as extended temperature range and higher load capacity, suitable for harsh industrial environments.
-
1C31122G01: A digital output module with high-frequency signal processing capabilities, ideal for real-time control applications.
Installation, Commissioning, and Maintenance Instructions
Installation Preparation: Before installing the Westinghouse 1C31116G04, ensure the environment meets the specified temperature and humidity requirements. Prepare the necessary tools, such as a screwdriver and multimeter, and ensure the installation area is free from dust and moisture. Follow the provided installation manual carefully to ensure proper grounding and connection of the module. Always disconnect the power source before starting the installation process to avoid electrical shock.
Maintenance Suggestions: Regularly inspect the 1C31116G04 for signs of damage or wear, such as loose connections or corrosion. Clean the module periodically to remove dust and debris, which can affect performance and longevity. If any issues are detected, such as signal errors or communication failures, consult the troubleshooting guide or contact a professional for assistance. Replace any damaged components promptly to maintain optimal performance and reliability.
Service and Guarantee Commitment
The Westinghouse 1C31116G04 is backed by a comprehensive warranty, ensuring customer satisfaction and peace of mind. Our company guarantees the quality of the product, providing a refund or replacement for any manufacturing defects within the warranty period. We offer 24/7 technical support to assist with installation, troubleshooting, and maintenance. Our commitment to quality and customer service ensures that the 1C31116G04 will deliver reliable performance for years to come.
