Product Overview
The Woodward 9905-895 is a digital synchronizer and load control (DSLC) module designed for industrial power systems, primarily used to enable seamless parallel operation of generator sets. As a legacy product, it belongs to Woodward’s portfolio of precision control solutions for power generation, marine propulsion, and industrial facilities. Its core function is to match the frequency, phase, and voltage of offline generators to online systems (e.g., utility grids or other generators) and distribute load evenly across paralleled units, ensuring stable power output and preventing electrical faults (e.g., phase mismatch, frequency deviations).
The 9905-895 is part of Woodward’s DSLC family, which has been widely adopted in industries where reliable power synchronization is critical—such as power plants, marine vessels, and oil & gas facilities. Although now obsolete, it remains a recognizable solution for its reliability and is often referenced in upgrade projects (replaced by the newer DSLC-2 series).
Key Technical Specifications
The 9905-895’s technical parameters are tailored for harsh industrial environments and high-precision control, with insights from Woodward DSLC series documentation and industrial supplier listings:
-
Input Voltage: 18–40 V DC (nominal 24 V DC) – compatible with global industrial power systems.
-
Control Modes:
-
Automatic Synchronization: Matches generator frequency (±0.1 Hz tolerance) and phase (±10° tolerance) to the online system.
-
Load Control: Supports droop (load-dependent speed adjustment), baseload (fixed load output), and isochronous (constant speed) modes for flexible operation.
-
-
Protection Features: Built-in reverse power relay to prevent back-feeding into the grid, ensuring safety during parallel operation.
-
Communication Interfaces: RS-232, Ethernet – supports Modbus protocol for integration with plant DCS/SCADA systems.
-
Operating Temperature: -25°C to +70°C (-13°F to +158°F) – suitable for extreme industrial environments (e.g., power plants, marine vessels).
-
Dimensions: Compact form factor (typical: ~280 mm × 210 mm × 90 mm) – fits standard industrial cabinets.
-
Weight: ~4.0 kg (8.8 lbs) – lightweight for easy handling during maintenance.
WOODWARD 9907-164
Field Application & Problem Solved
In industrial power systems, improper generator synchronization (e.g., frequency mismatch, phase difference) and uneven load distribution (across parallel generators) can lead to:
-
Electrical faults (e.g., short circuits, equipment damage).
-
Grid penalties (e.g., fines for frequency deviations).
-
Downtime (e.g., generator tripping, process interruptions).
The 9905-895 addresses these challenges through:
-
Precision Synchronization:It uses phase-locked loop (PLL) algorithms to match the offline generator’s frequency and phase with the online system within tight tolerances (±0.1 Hz, ±10°), ensuring compliance with grid requirements and preventing phase mismatch faults.
-
Automatic Load Sharing:In parallel operation (droop mode), the 9905-895 distributes load evenly across generators (±1% accuracy), reducing equipment wear and optimizing energy transfer efficiency.
-
Flexible Mode Switching:The module supports isochronous (constant speed) and droop (load-dependent speed) modes, allowing it to adapt to different operational requirements (e.g., standalone backup power vs. parallel grid-connected operation).
Typical Applications:
-
Power Generation: Synchronizing standby generators to the utility grid during peak demand or outages.
-
Marine Propulsion: Synchronizing shipboard generators for auxiliary power generation with load sharing.
-
Industrial Facilities: Balancing electrical load in cogeneration plants (combined heat and power) or industrial parks with multiple generator sets.
Installation & Maintenance Pitfalls (Expert Tips)
To ensure optimal performance and reliability of the 9905-895, follow these best practices:
-
Verify Power Supply Compatibility:
-
Confirm that the input voltage (18–40 V DC) matches the module’s rating. Mismatched voltage can damage the internal circuitry—use a multimeter to check the input voltage before installation.
-
-
Calibrate Speed Sensors:
-
Use a precision tachometer to calibrate the prime mover’s speed sensor (e.g., magnetic pickup) before installing the 9905-895. Incorrect sensor calibration can lead to synchronization errors—verify with a multimeter.
-
-
Test Synchronization Logic:
-
After installation, test the synchronization logic using a signal generator to simulate frequency/phase changes. Verify that the module correctly adjusts the generator’s speed and sends a synchronization signal when the conditions are met.
-
-
Perform Regular Maintenance:
-
Inspect the 9905-895 annually for signs of wear (e.g., cracked casings, loose connections). Clean the module’s connectors with isopropyl alcohol to remove dirt and debris, which can cause communication failures.
WOODWARD 9907-164
-
Technical Deep Dive & Overview
The 9905-895 operates on Woodward’s DSLC algorithm, which combines:
-
Frequency Measurement: The module measures the online system’s frequency using a phase-locked loop (PLL) circuit.
-
Speed Adjustment: It sends a control signal to the generator’s actuator (e.g., fuel valve) to adjust the generator’s speed until it matches the online system’s frequency.
-
Phase Matching: Once the frequency is matched, the module aligns the generator’s phase with the online system’s phase using a phase comparator.
-
Load Distribution: In parallel operation, the module uses droop control to adjust the generator’s speed based on load, ensuring even distribution across units.
What sets the 9905-895 apart is its balance of precision and simplicity. Unlike modern digital controllers, the analog platform eliminates the need for complex programming, making it easy to install and maintain—critical for 24/7 operations like power plants.
Final Notes
The Woodward 9905-895 is a legacy digital synchronizer and load control module that played a key role in industrial power systems. While it is no longer in production (replaced by the DSLC-2 series), its design principles (e.g., precision synchronization, load sharing) remain foundational to modern Woodward products.
For current applications, Woodward recommends upgrading to the DSLC-2 series, which offers enhanced features (e.g., improved communication protocols, better diagnostics) and better compatibility with modern industrial networks. If you are maintaining a system with a 9905-895, consult Woodward’s legacy support team for assistance with spare parts and technical guidance.
