YOKOGAWA ANB10D-425/CU2T

Ultra-fast response capabilities:

Building on the ANB10D-425/CU2N’s performance, the ANB10D-425/CU2T achieves response times of ≤5ms for both on and off events—half the delay of its counterpart. This speed is critical in precision manufacturing, such as in robotics assembly where milliseconds determine the accuracy of component placement. In automotive welding lines, the module’s rapid detection of workpiece position changes ensures welding robots adjust their paths instantly, reducing defects in high-speed production.

Enhanced surge protection:

The ANB10D-425/CU2T incorporates advanced surge protection circuitry not found in the ANB10D-425/CU2N, enabling it to withstand voltage transients up to 2kV. This feature is invaluable in industrial environments with frequent power fluctuations, such as in mining operations where heavy equipment causes voltage spikes. The module’s ability to absorb electrical surges prevents damage to the control system during lightning strikes or equipment startups, reducing unplanned downtime.

Superior isolation rating:

With 1000V AC isolation—double the protection of the ANB10D-425/CU2N—the ANB10D-425/CU2T provides exceptional protection against electrical interference. This is particularly beneficial in high-voltage environments like steel mills or power generation facilities, where electromagnetic noise from large transformers and motors can disrupt signal integrity. The enhanced isolation ensures accurate signal detection even when installed near high-power equipment, maintaining control system reliability.

Extended environmental tolerance:

The ANB10D-425/CU2T operates in temperatures ranging from -20°C to 60°C, outperforming the ANB10D-425/CU2N’s -10°C to 55°C range. This makes it suitable for outdoor installations such as renewable energy plants, where temperature extremes are common. In desert solar farms or arctic oil pipelines, the module reliably monitors sensor inputs regardless of ambient conditions, ensuring continuous operation in critical infrastructure.

Manufacturer:
Part number: YOKOGAWA ANB10D-425/CU2T
Our extensive catalogue, including : YOKOGAWA ANB10D-425/CU2T , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

1. Detailed parameter table

Parameter name Parameter value
Product model ANB10D-425/CU2T
Manufacturer YOKOGAWA
Product category Digital Input Module
Number of Input Channels 10 channels
Input Signal Type Dry contact, NPN/PNP transistor input (with enhanced surge protection)
Input Voltage Range 12-24V DC (for transistor input)
Input Current ≤8mA per channel
Response Time ≤5ms (on), ≤5ms (off)
Isolation 1000V AC (channel to system, channel to channel)
Operating Temperature Range -20°C to 60°C
Storage Temperature Range -30°C to 80°C
Dimensions 35mm (W) x 110mm (H) x 165mm (D)
Weight Approximately 0.35kg
Mounting Backplane mounting (compatible with YOKOGAWA control systems)
Communication Interface High-speed serial communication with host system (with diagnostic data logging)
YOKOGAWA ANB10D-425/CU2T

YOKOGAWA ANB10D-425/CU2T

2. Product introduction

The YOKOGAWA ANB10D-425/CU2T is an advanced digital input module designed as an enhanced variant of the ANB10D-425/CU2N, offering superior performance for demanding industrial environments. As a critical component in industrial automation, it excels at capturing digital signals from field devices and delivering them to control systems with exceptional speed and reliability.

This 10-channel module retains the versatility of supporting both dry contacts and NPN/PNP transistor inputs but adds enhanced features for harsh operating conditions. With an expanded temperature range and higher isolation rating, the ANB10D-425/CU2T is engineered for applications in extreme environments where standard modules may struggle. Its faster response time makes it ideal for high-precision automation scenarios in industries such as oil and gas, heavy machinery, and outdoor industrial installations. By combining rugged construction with advanced signal processing, the YOKOGAWA ANB10D-425/CU2T sets a new standard for digital input performance in challenging industrial settings.

3. Core advantages and technical highlights

Ultra-fast response capabilities:

Building on the ANB10D-425/CU2N’s performance, the ANB10D-425/CU2T achieves response times of ≤5ms for both on and off events—half the delay of its counterpart. This speed is critical in precision manufacturing, such as in robotics assembly where milliseconds determine the accuracy of component placement. In automotive welding lines, the module’s rapid detection of workpiece position changes ensures welding robots adjust their paths instantly, reducing defects in high-speed production.

Enhanced surge protection:

The ANB10D-425/CU2T incorporates advanced surge protection circuitry not found in the ANB10D-425/CU2N, enabling it to withstand voltage transients up to 2kV. This feature is invaluable in industrial environments with frequent power fluctuations, such as in mining operations where heavy equipment causes voltage spikes. The module’s ability to absorb electrical surges prevents damage to the control system during lightning strikes or equipment startups, reducing unplanned downtime.

Superior isolation rating:

With 1000V AC isolation—double the protection of the ANB10D-425/CU2N—the ANB10D-425/CU2T provides exceptional protection against electrical interference. This is particularly beneficial in high-voltage environments like steel mills or power generation facilities, where electromagnetic noise from large transformers and motors can disrupt signal integrity. The enhanced isolation ensures accurate signal detection even when installed near high-power equipment, maintaining control system reliability.

Extended environmental tolerance:

The ANB10D-425/CU2T operates in temperatures ranging from -20°C to 60°C, outperforming the ANB10D-425/CU2N’s -10°C to 55°C range. This makes it suitable for outdoor installations such as renewable energy plants, where temperature extremes are common. In desert solar farms or arctic oil pipelines, the module reliably monitors sensor inputs regardless of ambient conditions, ensuring continuous operation in critical infrastructure.

YOKOGAWA ANB10D-425/CU2T

YOKOGAWA ANB10D-425/CU2T

4. Typical application scenarios

In offshore oil and gas platforms, the ANB10D-425/CU2T monitors valve positions, emergency shutdown switches, and equipment status sensors. Its enhanced isolation protects against the electrical noise from drilling equipment, while its wide temperature range handles the extreme heat and cold encountered in marine environments. The module’s rapid response time ensures that emergency shutdown signals trigger immediately when hazardous conditions are detected, critical for platform safety.

In mining operations, the ANB10D-425/CU2T connects to proximity sensors on conveyor belts and position switches on mining machinery. Its surge protection withstands voltage spikes from heavy equipment, while its rugged design resists vibration and dust. The module’s ability to operate at -20°C ensures reliable performance in underground mines with limited climate control, providing essential input data for preventing equipment jams and optimizing material flow.

In renewable energy facilities, such as wind farms, the ANB10D-425/CU2T monitors wind turbine status signals, including brake positions, door interlocks, and vibration sensors. Installed in turbine nacelles exposed to extreme temperatures, the module’s extended operating range ensures accurate signal detection in both freezing winters and hot summers. Its fast response time enables quick detection of abnormal conditions, allowing the control system to adjust turbine operation or initiate safe shutdowns to prevent damage.

5. Related model recommendations

  • ANB10D-425/CU2N: The standard variant with basic protection levels, offering a cost-effective alternative to the ANB10D-425/CU2Tfor less demanding environments with stable temperatures and minimal electrical noise.
  • ANB16D-425/CU2T: A 16-channel version of the ANB10D-425/CU2T, providing expanded input capacity for complex systems requiring more monitoring points in harsh environments.
  • ANB10D-435/CU2T: A higher-current variant handling up to 15mA per channel, suitable for powering and monitoring devices with higher current requirements than the ANB10D-425/CU2Tcan support.
  • ALE111-S50: A digital output module that pairs with the ANB10D-425/CU2Tto create complete control loops, sending commands to actuators based on the input signals received by the ANB10D-425/CU2T.
  • AIP830-111: An analog input module that complements the ANB10D-425/CU2Tin mixed-signal systems, processing continuous measurements alongside the discrete inputs handled by the ANB10D-425/CU2T.
  • ANB10D-425/CU2T-EX: An explosion-proof version certified for hazardous areas, providing the same enhanced features as the ANB10D-425/CU2Tfor use in environments with flammable gases or dust.

6. Installation, commissioning and maintenance instructions

Installation preparation

Before installing the ANB10D-425/CU2T, verify the control rack is powered off and compatible with YOKOGAWA systems. Ensure the mounting location meets the expanded temperature range (-20°C to 60°C) and is protected from direct exposure to water or chemicals. Prepare tools including a torque screwdriver (0.5-1.0 Nm) and wire strippers for 20-16 AWG cables.

Use twisted-pair shielded cables for all connections, with the shield grounded at both ends to maximize noise immunity. Confirm input signals fall within the 12-24V DC range and that total current across all channels does not exceed 40mA. For hazardous environments, ensure proper sealing of cable entries to maintain environmental protection. Label each channel clearly to match connected devices, facilitating troubleshooting.

Maintenance suggestions

Perform bi-annual visual inspections of the ANB10D-425/CU2T to check for corrosion, loose connections, or physical damage—more frequently in highly dusty or humid environments. Use compressed air to remove debris from ventilation openings. Monitor diagnostic data via the control system to track channel performance and identify potential issues before failure.

Calibrate input thresholds annually using a precision voltage source to maintain response accuracy. If a channel exhibits delayed response or false triggers, check for cable damage before replacing the module. When replacing the ANB10D-425/CU2T, transfer configuration settings using YOKOGAWA’s configuration software to ensure operational consistency. Store spare modules in anti-static packaging within the specified storage temperature range (-30°C to 80°C).

7. Service and guarantee commitment

YOKOGAWA provides a 5-year warranty for the ANB10D-425/CU2T, reflecting confidence in its enhanced durability compared to standard modules. Each unit undergoes rigorous testing including thermal cycling, vibration testing, and surge immunity verification to ensure compliance with IEC 61131-2 and ISA 12.12.01 standards.

Our global technical support team offers specialized assistance for harsh environment applications, with 24/7 access to engineers experienced in extreme condition installations. On-site support is available within 48 hours in major industrial regions. YOKOGAWA provides detailed installation guides and application notes specific to the ANB10D-425/CU2T, along with training programs on maximizing performance in challenging environments. This comprehensive support ensures customers receive maximum value from their investment in this rugged digital input solution.
