ABB 216BM61b HESG448267R1021 is a high-performance
power module designed for industrial automation systems, particularly within ABB’s advanced control architectures. As a critical component in power distribution and control networks, this module ensures reliable energy management and seamless integration with ABB’s PLC and DCS systems. The
216BM61b HESG448267R1021 is part of ABB’s premium power supply series, engineered to deliver stable voltage regulation and robust fault protection in demanding industrial environments.
Featuring advanced semiconductor technology, the 216BM61b HESG448267R1021 provides precise power conditioning for control modules, sensors, and actuators, minimizing downtime caused by power fluctuations. Its design prioritizes compactness without compromising on performance, making it suitable for space-constrained control cabinets while maintaining high-efficiency power conversion. The module serves as a cornerstone in industrial applications requiring continuous, reliable power, such as manufacturing lines, process control systems, and critical infrastructure. By combining durability with cutting-edge functionality, the 216BM61b HESG448267R1021 enhances system stability and operational efficiency, positioning it as a trusted choice for industrial automation professionals.
| Parameter Name |
Parameter Value |
| Product Model |
216BM61b HESG448267R1021 |
| Manufacturer |
ABB |
| Product Type |
Power Module |
| Input Voltage Range |
85–264 VAC (wide-range compatibility) |
| Output Voltage |
24 VDC ±1% |
| Output Current |
10 A continuous |
| Efficiency |
Up to 92% at full load |
| Operating Temperature |
-20°C to +70°C (with derating above 50°C) |
| Storage Temperature |
-40°C to +85°C |
| Dimensions (W×H×D) |
40 mm × 100 mm × 125 mm |
| Mounting Style |
DIN rail or panel mounting |
| Protection Features |
Over-voltage, over-current, short-circuit, and over-temperature protection |
| Compliance |
CE, UL 508, IEC 62305 (EMC/EMI standards) |
ABB 5SHX06F6004
Reliable Power Regulation: The 216BM61b HESG448267R1021 ensures stable 24 VDC output with tight voltage tolerance, critical for sensitive control components. Its advanced feedback control loop dynamically adjusts to input variations, maintaining consistent power delivery even in unstable grid conditions.
Compact and Versatile Design: With a slim form factor, this module optimizes space in control panels, ideal for retrofits or new installations. The DIN rail mounting option enables quick installation and easy maintenance, while the flexible input range supports global use across different voltage standards.
Robust Protection Mechanisms: Built-in multi-level protection safeguards against common power anomalies, including over-voltage spikes and short circuits. The module’s thermal design incorporates efficient heat dissipation, extending lifespan and reducing the risk of overheating in high-temperature environments.
High Efficiency and Low Noise: Achieving up to 92% energy efficiency, the 216BM61b HESG448267R1021 minimizes power loss and operational costs. Its low electromagnetic interference (EMI) design ensures compatibility with noise-sensitive equipment, making it suitable for applications requiring clean power, such as pharmaceutical manufacturing or precision robotics.
The 216BM61b HESG448267R1021 power module excels in diverse industrial sectors where reliable power is non-negotiable. In manufacturing, it powers PLCs, HMIs, and servo drives in assembly lines, ensuring uninterrupted production even during voltage fluctuations. In process industries like oil and gas or chemical plants, the module’s rugged design withstands harsh conditions, providing stable power to distributed control systems (DCS) and safety instrumented systems (SIS).
For renewable energy applications, such as solar or wind farms, the module supports control systems in remote locations, operating reliably across wide temperature ranges. It also serves critical roles in transportation infrastructure, such as metro control systems or airport baggage handling, where downtime must be minimized. Additionally, the module’s compliance with global safety standards makes it a preferred choice for international projects requiring cross-border regulatory approval. By addressing power reliability challenges across these sectors, the 216BM61b HESG448267R1021 enhances system uptime and operational resilience.
- ABB 216BM61b HESG448267R1010: Earlier revision with similar specs but limited to 8 A output current.
- ABB 216BM62b HESG448268R1021: Higher-power variant offering 15 A output for heavy-load applications.
- ABB 216BM51b HESG448266R1021: Lower-power model (5 A) for small-scale control systems.
- ABB PCD230A101: Compatible DIN rail power supply with redundant configuration support.
- ABB PS501U: Modular power system for scalable power distribution in large DCS setups.
- ABB 216BM61b HESG448267R1030: Latest version with enhanced EMC performance for high-noise environments.
MB510 3BSE002540R1
Pre-installation preparation: Ensure the mounting surface (DIN rail or panel) is securely grounded and free of debris. Verify input voltage matches the 216BM61b HESG448267R1021’s specifications (85–264 VAC). Connect input and output cables using appropriate wire gauges (recommended: 14–22 AWG), ensuring proper strain relief and insulation. Avoid installing the module in enclosed spaces without adequate ventilation, especially in high-temperature environments.
Maintenance recommendations: Regularly inspect the module for physical damage or loose connections. Clean dust and debris from the ventilation slots using a dry cloth or compressed air to maintain optimal heat dissipation. Monitor operating temperature and voltage levels via system diagnostics to detect early signs of performance degradation. While the module is designed for long-term reliability, replace it with an identical 216BM61b HESG448267R1021 unit if abnormal noise, overheating, or voltage instability occurs, ensuring system downtime is minimized.
ABB stands behind the 216BM61b HESG448267R1021 with a comprehensive quality assurance program, including rigorous testing at every stage of production. The module is backed by a standard 24-month warranty, covering defects in materials or workmanship. ABB’s global technical support team provides prompt assistance for installation, troubleshooting, and firmware updates, ensuring optimal performance throughout the product’s lifecycle. In the rare event of a fault, ABB offers expedited replacement services to minimize disruption. This commitment to quality and customer support reinforces the 216BM61b HESG448267R1021 as a dependable choice for mission-critical industrial applications, delivering peace of mind and long-term value.
