The ABB 5SHY4045L0004 is an advanced Integrated Gate Commutated Thyristor (IGCT) module designed for high-power industrial applications. Engineered for precision and reliability, the 5SHY4045L0004 combines the robustness of thyristors with the fast switching capabilities of Gate Turn-Off (GTO) devices. With a rated voltage of 4500 V and a nominal current of 4000 A, this module is ideal for applications such as motor drives, power grids, and renewable energy systems. Its press-pack design ensures uniform thermal distribution and mechanical stability, while integrated gate control technology minimizes switching losses. Part of ABB’s modular power portfolio, the 5SHY4045L0004 supports seamless integration into complex control systems, enabling efficient power management in high-voltage environments.
2. Product Parameters
Parameter
Specification
Brand
ABB
Model
5SHY4045L0004
Type
Integrated Gate Commutated Thyristor (IGCT)
Rated Voltage
4500 V (DC)
Nominal Current (IT(AV))
4000 A (at 85°C case temperature)
Peak Reverse Voltage
4500 V
Switching Frequency
Up to 10 kHz
Gate Control
Integrated driver (±15 V control voltage)
Package
Press-pack (ceramic-metal hybrid)
Thermal Resistance (Rth(j-c))
0.003 K/W
Mounting
Bolted or clamped assembly
5SHY4045L0004
3. Advantages and Characteristics
High Efficiency: IGCT technology reduces switching losses by 25% compared to traditional thyristors.
Fast Switching: 10 μs turn-off time enables high-frequency operation.
Reliability: Press-pack design with redundant cooling paths ensures 10+ years of service life.
Compact Design: 30% smaller than equivalent GTO modules with identical ratings.
Integrated Control: On-board gate driver simplifies system integration.
Certifications: Compliant with IEC 60747-5 and UL 1741 standards.
4. Application Fields and Application Cases
Industries: Power generation (thermal, hydro, nuclear), renewable energy (wind/solar inverters), industrial automation, and electric transportation. Use Cases:
Grid-Scale Energy Storage: Used in a 100 MW battery energy storage system (BESS) for fast frequency regulation, achieving 98.5% efficiency.
Steel Mill Drives: Integrated into a 5 MW electric arc furnace drive, reducing energy consumption by 18%.
Rail Traction: High-speed train propulsion systems, enabling regenerative braking with 95% energy recovery.
5. Competitor Comparison
Compared to similar high-power switching devices (e.g., traditional thyristors or GTOs), the 5SHY4045L0004 offers:
20% Higher Power Density: 4500 V/4000 A in a compact press-pack format.
30% Faster Switching: 10 μs turn-off vs. 30–50 μs for GTOs.
Lower Maintenance: No external snubber circuits required (vs. thyristors).
Higher Efficiency: 99% operational efficiency vs. 97% for competing IGCTs.
5SHY4045L0004
6. Selection Suggestions
Voltage/Current Matching: Ensure compatibility with system voltage (4500 V DC bus) and current requirements (≥3500 A continuous).
Cooling System: Use liquid cooling for full-load operation (recommended flow rate: 10–15 L/min).
Control Interface: Verify gate driver compatibility (±15 V input, isolated signal lines).
Redundancy Planning: For critical systems, deploy parallel modules with current sharing inductors.
7. Precautions
Thermal Management: Maintain case temperature ≤85°C; derate by 10% for ambient temperatures >40°C.
Surge Protection: Install transient voltage suppression (TVS) diodes for overvoltage protection.
Storage Conditions: Store in dry environments (≤50% humidity) with anti-static packaging.
声明: 山西鑫业达国际贸易有限公司 is your trusted partner for ABB 5SHY4045L0004 and other automation 备件. We provide certified IGCT modules, technical support, and a 2-year warranty. Visit our website www.xydcontrol.com or contact us for customized power control solutions.
