Description
Product Specification for 5SHX1445H0001 3BHL000391P0101
5SHX1445H0001 3BHL000391P0101 is a high-speed digital input/output module designed for ABB’s industrial automation systems, specifically optimized for robotics and motion control applications. This module serves as a critical interface for real-time data exchange between the controller and field devices, ensuring precise synchronization and reliable operation in dynamic industrial environments.
The
5SHX1445H0001 module is engineered to handle high-frequency digital signals, supporting up to
32 channels of bidirectional I/O. Its compact design and rugged construction make it suitable for use in harsh industrial settings, including automotive assembly lines, material handling systems, and general manufacturing. The module integrates seamlessly with ABB’s
IRC5 controller and
RobotStudio software ecosystem.
| Parameter |
Specification |
| Voltage Input |
24 V DC ±10% |
| Signal Type |
Digital (TTL/24 V DC compatible) |
| Channel Count |
32 channels (16 inputs + 16 outputs) |
| Response Time |
≤100 µs (input), ≤200 µs (output) |
| Communication Protocol |
EtherCAT (real-time), Modbus TCP (optional) |
| Interface Type |
M12 connectors (X-coded for high-speed data) |
| Operating Temperature |
-40°C to +70°C |
| Dimensions (W×H×D) |
120 mm × 80 mm × 60 mm |
| Weight |
0.8 kg |
5SHX1445H0001 3BHL000391P0101
- High-Speed Performance: Supports EtherCAT communication with cycle times as low as 100 µs for deterministic control.
- Flexible Configuration: Configurable via RobotStudio for channel grouping, signal inversion, and safety interlocks.
- Diagnostic Capabilities: Onboard LED indicators for channel status and error codes.
- Safety Compliance: SIL 3-certified for safety-critical applications (when used with ABB’s safety-rated controllers).
- Modular Expansion: Stackable design allows daisy-chaining with other ABB I/O modules.
- Robotics: Coordinates end-effector signals (e.g., grippers, welding guns) in robotic arms.
- Automation Lines: Manages sensors, actuators, and safety devices in automotive assembly.
- Packaging Machinery: Controls high-speed packaging processes with precise timing.
- Material Handling: Synchronizes conveyor systems and robotic palletizing operations.
| Feature |
5SHX1445H0001 |
Competitor Models |
| Channel Density |
32 channels |
16–24 channels |
| Protocol Support |
EtherCAT + Modbus TCP |
Limited to proprietary protocols |
| Temperature Range |
-40°C to +70°C |
-20°C to +60°C |
| Safety Rating |
SIL 3 |
SIL 2 or non-rated |
5SHX1445H0001 3BHL000391P0101
- System Compatibility: Ensure compatibility with ABB’s IRC5 controller and EtherCAT network infrastructure.
- Signal Requirements: Verify voltage levels and response time needs for your application.
- Space Constraints: The compact design is ideal for space-limited installations.
- Installation: Use shielded cables to prevent EMI/RFI interference.
- Safety Wiring: Follow ABB’s safety guidelines for SIL-rated applications.
- Firmware Updates: Regularly update firmware via ABB’s official tools for compatibility with new controllers.
- Part Number: 3BHL000391P0101
- Replacement Part: Replaces obsolete 3BHL000390P0100
- Stock Availability: ABB warehouses in Europe and Asia-Pacific
- Minimum Order Quantity: 1 piece
