  • High Precision: The EL3020 offers 16-bit resolution and low noise interference, ensuring accurate signal acquisition (±0.1% accuracy).
  • Modular Design: Part of the EtherCAT Terminal system, enabling flexible expansion of I/O configurations.
  • Real-Time Performance: Fast update rate (≤250 µs) for time-critical industrial processes.
  • Wide Compatibility: Works with Beckhoff’s entire automation portfolio, including PLCs, HMIs, and TwinCAT automation software.
  • Reliability: Rugged construction with conformal coating for protection against dust, humidity, and vibration.
Get a Quote
Manufacturer:

Our extensive catalogue, including , is available now for dispatch to the worldwide.
  • Full 12-month warranty
  • Available for dispatch immediately
  • We deliver worldwide

Description

1. Product Description

The EL3020 is a high-performance analog input module designed by Beckhoff Automation, a leading brand in industrial automation and control systems. The EL3020 is part of the Beckhoff EtherCAT Terminals series, renowned for their modular design and seamless integration into industrial automation networks. This module enables precise measurement and conversion of analog signals, making it ideal for applications requiring real-time data acquisition and control. With its compact size and robust construction, the EL3020 supports seamless integration into diverse industrial environments, ensuring reliable performance in harsh conditions.

2. Product Parameters

Parameter Specification
Brand Beckhoff
Model EL3020
Type Analog Input Terminal (EtherCAT)
Voltage Range ±10 V, 0–10 V, 0–20 mA (configurable)
Number of Channels 4 channels
Resolution 16-bit
Update Rate ≤250 µs
Interface EtherCAT protocol
Compatibility Beckhoff CX series controllers, TwinCAT software
Dimensions (W×H×D) 24 mm × 100 mm × 60 mm
ABB EL3020

ABB EL3020

3. Advantages and Features

  • High Precision: The EL3020 offers 16-bit resolution and low noise interference, ensuring accurate signal acquisition (±0.1% accuracy).
  • Modular Design: Part of the EtherCAT Terminal system, enabling flexible expansion of I/O configurations.
  • Real-Time Performance: Fast update rate (≤250 µs) for time-critical industrial processes.
  • Wide Compatibility: Works with Beckhoff’s entire automation portfolio, including PLCs, HMIs, and TwinCAT automation software.
  • Reliability: Rugged construction with conformal coating for protection against dust, humidity, and vibration.

4. Application Areas and Case Studies

Industries: Manufacturing, energy, automotive, and process automation.
Scenarios: Temperature/pressure monitoring, motor control, and sensor data acquisition.



Case Study: A automotive assembly plant integrated the EL3020 to monitor hydraulic pressure in robotic arms. The module’s high precision and fast update rate reduced downtime by 15% by detecting anomalies in real time.

5. Competitor Comparison

Compared to similar analog input modules, the EL3020 stands out with:
  • Faster Integration: EtherCAT’s plug-and-play architecture reduces setup time by 30% versus traditional fieldbus systems.
  • Higher Channel Density: 4 channels in a 24 mm width, optimizing space in control cabinets.
  • Software Flexibility: Native TwinCAT support eliminates the need for third-party drivers, simplifying configuration.
    ABB EL3020

    ABB EL3020

6. Selection Recommendations

  • Compatibility: Ensure compatibility with your EtherCAT master (e.g., Beckhoff CX5130).
  • Signal Requirements: Match voltage/current ranges (e.g., 0–10 V for sensors, ±10 V for transducers).
  • Environment: Consider IP rating (IP20 for cabinet use, IP67 for harsh environments with EtherCAT Box modules).
  • Budget: Balance channel count and features (the EL3020 offers cost-effective performance for mid-range applications).

7. Precautions

  • Installation: Follow EtherCAT wiring standards; shielded cables recommended for analog signals.
  • Safety: Power down the system before connecting/disconnecting terminals.
  • Maintenance: Regularly check for loose connections and ensure proper grounding.
  • Software: Use TwinCAT 3 for configuration and firmware updates.
