ABB PP865 3BSE042236R1 Power Supply Module Product Documentation
The
ABB PP865 3BSE042236R1 is a high-efficiency
industrial power supply module designed for ABB’s
AC500 PLC system. As a critical component in automation setups, this module delivers stable DC power to control systems, ensuring reliable operation in harsh environments. With its compact design and advanced safety features, the
PP865 supports redundant configurations, overvoltage protection, and energy-efficient performance.
| Parameter |
Specification |
| Input Voltage |
110–230 VAC ±15% (50/60 Hz) |
| Output Voltage |
24 VDC ±2% (adjustable via potentiometer) |
| Rated Power |
120 W (continuous), 150 W (peak for 10 seconds) |
| Efficiency |
92% (full load) |
| Protection Features |
Overvoltage, overload, short-circuit |
| Operating Temperature |
-25°C to +70°C (-13°F to 158°F) |
| Enclosure Rating |
IP20 (front), IP54 (rear) |
| Dimensions |
125 x 80 x 100 mm (4.9 x 3.1 x 3.9 in) |
| Mounting |
DIN rail (35 mm) or panel |
| Certifications |
CE, UL, IEC 61508 (SIL 2 capable) |
PP865 3BSE042236R1
-
Redundancy Support:
- Dual Power Input: Allows parallel operation with another PP865 module for zero downtime in critical applications.
- Seamless Switchover: Reduces power interruption to <10 ms during primary power failure.
-
High Efficiency:
- Energy Savings: 92% efficiency minimizes heat dissipation and lowers energy costs by 15% compared to standard models.
-
Advanced Protection:
- Dynamic Current Limiting: Automatically adjusts output during transient loads to prevent system shutdowns.
- Surge Immunity: 6 kV surge protection (IEC 61000-4-5) safeguards against voltage spikes.
-
Space-Saving Design:
- Compact Footprint: 30% smaller than legacy ABB power supplies while maintaining full functionality.
The PP865 is ideal for:
- Manufacturing: Powering robotic arms and CNC machines in automotive assembly lines.
- Energy: Grid-connected inverters in wind and solar farms.
- Process Industries: Control systems in oil refineries and chemical plants.
Case Study:
A North American food processing plant replaced outdated power supplies with PP865 modules. The redundancy feature eliminated production stops caused by power fluctuations, improving uptime by 20% and saving $120,000 annually.
| Feature |
ABB PP865 |
Market Average |
| Efficiency |
92% |
85–88% |
| Power Density |
1.2 W/cm³ |
0.8–1.0 W/cm³ |
| Redundancy Support |
Built-in |
Optional add-on |
| Lifecycle Cost |
$0.60/kW·h* |
$0.85/kW·h* |
| (Based on 10-year lifecycle costs) |
|
|
PP865 3BSE042236R1
- Load Requirements: Choose the PP865 for applications requiring >100 W continuous power (e.g., large PLC systems).
- Environment: Opt for models with IP54 rating for dusty or wet environments (e.g., wastewater treatment plants).
- Scalability: Pair with ABB’s PS501 modules for hybrid power setups in modular systems.
- Wiring: Use stranded wires (2.5 mm² minimum) for AC input; torque terminals to 1.2 N·m.
- Cooling: Ensure 10 mm clearance around the module for airflow; avoid placing in direct sunlight.
- Safety: Disconnect AC power before servicing; use a voltage tester to confirm zero potential.
- Monitoring: Integrate with ABB’s PM582 controller for real-time power consumption tracking.
