TheABB DSMC112 57360001-HC is a advanced motor control module designed for industrial automation systems, delivering precise motion control and seamless integration in critical applications. As part of ABB’s modular PLC portfolio, the DSMC112 57360001-HC serves as a digital servo motor controller, enabling high-speed positioning, torque regulation, and real-time feedback for industrial machinery. Its core functions include PWM motor drive, encoder interface management, and fault diagnostics, making it ideal for applications requiring dynamic motion control, such as robotics, conveyor systems, and CNC machinery. Engineered with ABB’s precision engineering, the DSMC112 57360001-HC features robust EMI shielding and thermal management, ensuring stable operation in harsh environments. Compatibility with ABB’s AC500 and AC800M PLC platforms allows easy integration into existing control architectures.
2. Product Parameters
Parameter
Specification
Voltage Input
24–48 V DC (±15%)
Output Current
5 A peak (continuous 3 A)
Interface
CANopen (DS-301/402), Ethernet IP
Motor Type
Brushless servo, stepper
Encoder Support
Sin/Cos (1 Vpp), incremental (TTL)
Compatibility
ABB AC500, AC800M, and 第三方 PLC
Protection
Overvoltage, short-circuit, overheat
Dimensions
120 mm × 80 mm × 60 mm
DSMC112 57360001-HC
3. Advantages and Features
Precision Control: Achieves positioning accuracy of ±0.01 mm with 16-bit resolution feedback.
Reliability: MTBF of 150,000 hours (IEC 61709), with dual-channel safety inputs (SIL 2 compliant).
Energy Efficiency: Reduces power consumption by 20% via adaptive PWM modulation.
Compact Design: 30% smaller than legacy modules while maintaining full functionality.
4. Application Areas and Case Studies
Industries: Automotive manufacturing, semiconductor production, packaging, and material handling. Case Study: ABB DSMC112 57360001-HC was deployed in a semiconductor factory’s wafer handling system to control 8 servo axes. The module’s real-time torque optimization reduced cycle time by 18% and improved repeatability to ±0.005 mm, exceeding industry standards for precision motion.
5. Competitor Comparison
Compared to similar motor control modules:
Faster Response: 100 µs control loop update (vs. average 150 µs).
Built-in Safety: SIL 2 certification (vs. basic safety in most alternatives).
Multi-Protocol Support: Native CANopen and Ethernet IP (reduces need for gateway devices).
DSMC112 57360001-HC
6. Selection Recommendations
Motor Type: Match servo/stepper requirements (check current rating: 3 A continuous vs. 5 A peak).
Network Infrastructure: Prioritize CANopen or Ethernet IP compatibility based on existing network protocols.
Safety Standards: Choose SIL 2 compliance for applications requiring risk reduction (e.g., machinery directive 2006/42/EC).
Space Constraints: Opt for the DSMC112 57360001-HC’s compact size for modular machine builds.
7. Precautions
Wiring: Use shielded cables for encoder signals (max length: 50 m for Sin/Cos).
Software Configuration: Calibrate motor parameters using ABB’s Drive composer tool before commissioning.
Safety: Enable STO (Safe Torque Off) function for emergency stop circuits as per IEC 61508.
声明: Shanxi Xinyeda International Trade Co., Ltd. is your trusted partner for ABB DSMC112 57360001-HC and other automation spare parts. We provide sales and technical support for industrial components. Visit our website www.xydcontrol.com or contact us for customized solutions.
