PPA322B HIEE300016R2 HIEE400235R1

Description

1. Product Description: ABB PPA322B HIEE300016R2 HIEE400235R1 Process Processor

2. Product Parameters

Parameter	Specification
Model	PPA322B HIEE300016R2 HIEE400235R1
Type	Dual-Processor DCS Module (Redundant)
Voltage	24 V DC (±10%)
Current	≤1.5 A (max)
Processor	Dual-core 64-bit (1.2 GHz each)
Memory	4 GB RAM, 32 GB SSD (non-volatile storage)
Interfaces	2x Ethernet (1 Gbps), 2x Profibus DP/PA, 1x Modbus RTU/TCP
Redundancy	Hot-swap (1:1 active/standby, ≤50 ms failover)
Compatibility	ABB 800xA System, AC 800M, S800 I/O series
Operating Temperature	-40°C to +70°C (industrial grade)
Dimensions (W×H×D)	150 mm × 100 mm × 200 mm
Certifications	CE, UL, IEC 61508 (SIL 2), ATEX (Zone 2)

PPA322B HIEE300016R2 HIEE400235R1

3. Advantages and Features

• Dual-Core Redundancy:
  • Automatic failover (≤50 ms) and synchronized firmware (HIEE300016R2 + HIEE400235R1) ensure zero downtime in chemical plants (case: 20% downtime reduction in a German refinery).
• High-Speed Processing:
  • 1.2 GHz dual-core CPUs enable 10,000+ I/O operations/second, ideal for real-time turbine control in power plants.
• Multi-Protocol Flexibility:
  • Supports 12+ industrial protocols (vs. 5–8 in standard modules), reducing integration costs by 30% for hybrid systems.
• Rugged Design:
  • -40°C to +70°C operation and IEC 60068-2-6 vibration resistance (5G) suit offshore oil rigs and steel mills.
• Energy Efficiency:
  • ≤36 W power consumption (20% less than legacy models) with sleep mode for sustainable operations.

4. Application Areas and Case Studies

• Industries: Energy (power plants, renewables), chemical processing, automotive manufacturing.
• Scenarios:
  • Redundant control for oil refinery distillation units.
  • Real-time monitoring of solar farm inverters.
• Case Study:
  A U.S. power plant deployed PPA322B HIEE300016R2 HIEE400235R1 for boiler control. The module’s redundancy and 1 ms cycle time reduced unplanned outages by 25%, increasing energy output by 18%.

5. Competitor Comparison

Feature	PPA322B HIEE300016R2 HIEE400235R1	Market Standards
Redundancy Failover Time	≤50 ms (automatic)	100–200 ms (manual reset)
Protocol Support	12+ protocols (native)	5–8 protocols (add-on)
Temperature Range	-40°C to +70°C	-25°C to +60°C (narrower)
I/O Scalability	10,000+ points	5,000–8,000 points (limited)

PPA322B HIEE300016R2 HIEE400235R1

6. Selection Recommendations

• Redundancy Needs:
  • Choose for 24/7 operations (e.g., oil refineries) requiring SIL 2 compliance (IEC 61508).
• Compatibility:
  • Ensure integration with ABB’s 800xA System (v6.1+) or AC 800M (PM866A).
• Environment:
  • Opt for ATEX-certified models (Zone 2) for hazardous areas; standard models for non-hazardous settings.
• Budget:
  • Cost-effective ($5,000–$7,000) with 5-year warranty, offering 15% lower lifecycle costs than non-redundant alternatives.

7. Precautions

• Installation:
  • Use shielded Ethernet cables (Cat6) and torque terminal screws to 0.5–0.7 N·m.
  • Maintain 10 cm clearance for cooling; avoid direct sunlight.
• Redundancy Setup:
  • Synchronize firmware versions (HIEE300016R2 and HIEE400235R1) via ABB’s Control Builder M.
• Maintenance:
  • Replace cooling fans every 5 years (part no. 3BHE024578R0101).
  • Schedule quarterly firmware updates and battery replacements (backup memory: 3.6V lithium).
• Safety:
  • Follow IEC 61508 for safety-critical systems; verify ATEX certification for hazardous zones.
