PPD113-B03-10-150000

Description

1. Product Description

2. Product Parameters

Parameter	Specification
Brand	ABB
Model	PPD113-B03-10-150000
Terminal Type	Box-style (with optional barrier-style)
Maximum Current per Terminal	10 amps
Extra Tie-point Terminals	5 per module position (internally tied)
Power Terminals	Daisy-chain compatible for module power
Compatibility	ABB I/O modules (e.g., analog, discrete)
Label System	Snap-in labels (customizable via Weidmüller)
Auxiliary Terminals	Optional for analog/high-density modules

PPD113-B03-10-150000

3. Advantages and Characteristics

• Flexible Wiring: Five extra tie-point terminals per module allow grouping of signals or shared power connections, reducing cabling complexity.
• High Current Handling: 10 amps per terminal supports heavy-duty industrial applications.
• Modular Design: Daisy-chain power terminals and auxiliary blocks enable scalable configurations.
• Reliability: Isolated terminals and robust construction ensure immunity to electrical noise and mechanical stress.
• Ease of Installation: Snap-in labels and intuitive layout minimize setup time.
• Warranty: Backed by a one-year warranty for guaranteed performance.

4. Application Fields and Application Cases

• Factory Automation: Integrating discrete I/O signals in a automotive assembly line, reducing downtime through quick module replacement.
• Power Generation: Managing analog signals from sensors in a power plant’s turbine control system, ensuring stable voltage regulation.
• Case Study: A chemical plant upgraded its control system with PPD113-B03-10-150000, reducing wiring errors by 30% and improving maintenance efficiency.

5. Competitor Comparison

Compared to generic terminal blocks, the PPD113-B03-10-150000 offers superior current handling (10A vs. 8A typical) and a higher number of tie-point terminals (5 vs. 3), enabling more complex signal grouping. Its modular auxiliary blocks and compatibility with ABB’s ecosystem provide a seamless integration advantage over standalone solutions.

PPD113-B03-10-150000

6. Selection Suggestions

• Compatibility: Ensure alignment with ABB I/O modules (e.g., IC 670 CHS series).
• Current Requirements: Verify load currents do not exceed 10A per terminal.
• Installation Space: Consider auxiliary blocks for high-density modules.
• Budget: Balance upfront costs with long-term reliability (e.g., reduced maintenance).

7. Precautions

• Current Limits: Avoid exceeding 10A per terminal to prevent overheating.
• Grounding: Ensure proper grounding of auxiliary terminals for analog applications.
• Static Protection: Use anti-static equipment when handling terminals.
• Maintenance: Inspect connections annually for corrosion or loose wires.
