UAC383AE01 HIEE300890R0001

Description

ABB UAC383AE01 HIEE300890R0001 Product Overview

Key Features

1. Design and Functionality
   • Modular UPS System: Likely part of a larger UPS architecture (e.g., ABB’s Industrial UPS Series), allowing for scalable power solutions and easy maintenance.
   • Double-Conversion Technology: Provides true online UPS functionality, isolating the load from input power disturbances by converting AC to DC and back to AC, ensuring clean, regulated output.
   • High Efficiency: Optimized for low power losses during normal operation, reducing energy consumption and heat generation.
2. Technical Specifications (Typical for ABB Industrial UPS Modules)

   Parameter	Description
   Model	UAC383AE01
   Part Number	HIEE300890R0001
   Product Type	UPS Inverter Module / Power Supply Module
   Input Voltage	Typically 100–240 V AC (single-phase) or 380–480 V AC (three-phase), depending on the system.
   Output Voltage	Stable 230 V AC or 400 V AC (adjustable, depending on application).
   Power Rating	Likely ranges from 1–10 kVA (exact capacity depends on the UPS system it integrates into).
   Battery Support	Compatible with lead-acid or lithium-ion batteries for backup power.
   Communication	Built-in interfaces for remote monitoring (e.g., RS-485, Modbus, Ethernet) via optional modules.
   Mounting	Rack-mountable or panel-mountable, designed for industrial control cabinets.
   Environmental Rating	Operating temperature: -10°C to +50°C; humidity: 5–95% (non-condensing).

1. • 1.

        UAC383AE01 HIEE300890R0001

     2. Reliability and Protection
        • Fault Tolerance: Includes overload protection, short-circuit protection, and thermal shutdown to prevent damage during faults.
        • Redundancy Support: May support parallel operation for N+1 redundancy, enhancing system reliability in critical applications (e.g., data centers, process control).

     Common Applications

     1. Industrial Automation
        • Powers PLCs, HMIs, drives, and other control devices in manufacturing lines, ensuring uninterrupted operation during power outages.
        • Critical in industries like oil & gas, pharmaceuticals, and food & beverage, where downtime risks safety or product quality.
     2. Power Generation and Distribution
        • Supports control systems in substations, power plants, and renewable energy facilities (e.g., wind farms, solar plants) to maintain grid stability and monitoring during transient faults.
     3. Data Centers and IT Infrastructure
        • Provides clean, regulated power to servers, networking equipment, and storage systems, preventing data loss or service interruptions.
     4. Medical and Healthcare Facilities
        • Powers life-critical equipment (e.g., MRI machines, operating room systems) where uninterrupted power is non-negotiable.


          UAC383AE01 HIEE300890R0001

     .

Installation and Integration

1. System Integration
   • The UAC383AE01 is typically installed as part of a complete UPS system, which may include battery cabinets, static switches, and monitoring units.
   • Requires professional installation to ensure proper wiring, grounding, and compliance with electrical codes (e.g., IEC 62040 for UPS systems).
2. Configuration and Monitoring
   • Use ABB’s UPS management software (e.g., ABB Ability™ Energy and Asset Manager) to configure settings, monitor battery health, and track power quality metrics.
   • Alerts for battery discharge, overloads, or input power issues can be sent via email, SMS, or SCADA systems.
3. Maintenance
   • Regular battery checks (e.g., voltage, capacity) to ensure backup readiness.
   • Firmware updates to address security patches or performance improvements.
   • Replacement of wear components (e.g., capacitors, fans) as recommended by ABB.

Related Products

• ABB Industrial UPS Series
  • Full UPS systems (e.g., MODULUS, TPS) that integrate modules like the UAC383AE01 for scalable power solutions.
• ABB Battery Solutions
  • Lead-acid or lithium-ion battery packs designed for long runtime and fast recharge.
• ABB Power Distribution Units (PDUs)
  • Complementary products for load distribution and circuit protection in UPS systems.
• ABB Monitoring and Control Modules
  • Accessories like communication gateways (e.g., SNMP cards) for remote management.
