The BENTLY NEVADA 136188-02 is a high-performance communication gateway module designed for the 3500 Series Machinery Protection System. It bridges the gap between rotating machinery (e.g., turbines, compressors) and industrial automation systems by enabling real-time data exchange via Ethernet TCP/IP and RS485 Modbus protocols. This module processes vibration, temperature, and displacement signals from sensors, transmitting them to control platforms like SCADA or DCS for predictive maintenance and operational optimization. With a compact design and dual-protocol support, the 136188-02 ensures seamless integration in industries requiring reliable machinery health monitoring.
2. Product Parameters
Parameter
Specification
System Compatibility
BENTLY NEVADA 3500 Series Monitoring System
Communication Protocols
Ethernet TCP/IP, RS232/RS422/RS485 Modbus
Power Supply
18–36 VDC (via 3500 rack)
Data Rate
Ethernet: 10/100 Mbps; RS485: Up to 115.2 kbps
Input Channels
12 channels (expandable via modular design)
Operating Temperature
-30°C to +65°C (-22°F to +149°F)
Weight
0.44 kg (0.96 lb)
Mounting Style
Rack-mounted (3500 Series compatible)
3. Advantages and Features
Dual-Protocol Flexibility: Supports both Ethernet and serial communication, adapting to diverse industrial networks.
High-Speed Data Transfer: 100 Mbps Ethernet ensures rapid transmission of critical machinery data.
Built-in Signal Conditioning: Reduces external hardware needs by filtering noise and amplifying signals.
Case Study: A power plant using the 136188-02 achieved 25% faster fault detection in steam turbines, cutting maintenance costs by $150,000 annually.
4. Application Areas and Use Cases
Industries: Oil & gas, power generation, manufacturing, chemical processing.
Key Applications:
Vibration monitoring of rotating machinery.
Integration of machinery data into enterprise asset management systems.
Remote diagnostics in offshore platforms.
5. Competitor Comparison
The 136188-02 outperforms alternatives with:
Native System Integration: Pre-configured for BENTLY’s 3500 Series, eliminating compatibility challenges.
Wide Temperature Range: Operates in extreme conditions (-30°C to +65°C).
Modular Scalability: Expandable to 12 channels for large-scale installations.
6. Selection Recommendations
Communication Requirements: Choose this module if your system requires both Ethernet and serial connectivity.
System Expansion: Ideal for retrofitting existing 3500 Series setups.
Data Volume: Opt for Ethernet mode for high-frequency data transmission in complex machinery.
7. Precautions
Configuration: Use BENTLY’s 3500 Framework Software to set protocol parameters (e.g., baud rate).
EMI Protection: Shield cables and ensure proper grounding to prevent signal interference.
Firmware Updates: Regularly update firmware to access new features and security patches.
