BENTLY 3500/54-03-00 Transient Data Interface & Power Supply Module
1. Product Description
The BENTLY 3500/54-03-00 is a dual-function module designed for critical machinery protection and data management in industrial environments. As part of the BENTLY 3500 Series, it combines a transient data interface (TDI) for real-time monitoring with a redundant power supply, ensuring reliable operation even in harsh conditions. The TDI supports high-speed data transfer to System 1 software for predictive analytics, while the power supply offers dual AC/DC inputs for redundancy, making it ideal for mission-critical applications like turbines, compressors, and pumps.
2. Product Parameters
| Parameter | Specification |
|---|---|
| Input Signal | -10 VDC to +10 VDC (analog) |
| Power Supply | AC: 85–264 V / DC: 12–30 V (dual redundant) |
| Power Consumption | 7.7 W |
| Communication | Proprietary TDI protocol, USB, Ethernet |
| Weight | 0.82 kg (1.8 lb) |
| Dimensions | 241 × 24.4 × 242 mm (9.5 × 0.96 × 9.52 in) |
| Operating Temperature | -20°C to +70°C (-4°F to 158°F) |
| Safety Compliance | CE, RoHS |
3. Advantages and Features
- Dual Redundancy: Independent AC/DC power inputs eliminate single points of failure.
- Wide Voltage Range: Supports global power grids without adapters.
- Real-Time Monitoring: Integrates with System 1 for predictive maintenance and alarm management.
- Self-Monitoring: Built-in diagnostics ensure output stability and alert operators to faults.
- Case Study: A European power plant reduced downtime by 30% using this module to monitor turbine overspeed events.
4. Application Areas and Use Cases
- Industries: Power generation, oil and gas, manufacturing.
- Key Applications:
- Overspeed protection for rotating machinery.
- Condition monitoring of pumps and compressors.
- Data logging for vibration and temperature analysis.
5. Competitor Comparison
The 3500/54-03-00 outperforms alternatives with:
- Integrated Redundancy: Combines power supply and TDI in a single unit.
- Flexible Connectivity: Supports USB for local configuration and Ethernet for remote access.
- Robust Design: IP65-rated enclosure for dust and water resistance.
6. Selection Recommendations
- Redundancy Needs: Choose this model for systems requiring backup power.
- Data Integration: Pair with BENTLY System 1 for advanced analytics.
- Environment: Opt for IP65-rated variants in extreme conditions.
7. Precautions
- Installation: Ensure proper grounding and ventilation.
- Software Updates: Regularly update firmware for compatibility with new sensors.
- Safety: Disconnect power before module replacement to avoid electrical hazards.
Shanxi XinyeDa International Trade Co., Ltd. specializes in BENTLY 3500/54-03-00 modules and automation solutions. Visit www.xydcontrol.com or contact us for sales, technical support, and customized monitoring systems.
